Peavey UNITY 2002 Operating Manual page 4

EFFECTS A (7)
Adjusts the level of the channel signal added into the EITects A mix. This control is post fader.
EFFECTS B (8)
AdjustMhe level of the channel signal added into the EfTecis B mix. This conux>l is post fader.
PAN (9)
Assigns the channel to any position in the Left-Right stereo field. For mono operation, the channel should be
assigned lo the Left or Right mix,
CUP LED (10)
Indicates that die channel is nearing the clipping point. It jiliiminates atapproxim^ely +12 dBV and signals tliat
the input Gain (1) should be reduced. There is approximately 6 dBV of headroom at this point.
CHANNFX LEVEL (FADER) (11)
Sets the level of the channel to the Left and Right mixes. The calibration i.s in dR, and the recommended sening is
at the 0 dB (unity gain) mark to assure an optimum balance between noise and headroom.
LED METER ARRAYS (12)
Fotir twelve point LED arrays are provided to visually Indicate the levels of the Left and Right mixes and the
Monitor A and Monitor B mixes. The clip LED lights when the levels reach +12 dBV, 6 dBV below the actual
clip level, as a warning of loss of headroom.
PHANTOM POWER (13)
Press to enable 415 V phantom mic power to all input XLR connectors.
POWER SWITCH and LED (14)
Press toward LED to turn on. LED will illuminate when power is on.
EFFECTS A MASTFZR (15)
Sets the overall Effects A mix level sent to the Effects A output jack.
STEREO RETURN A TO MON A (16)
Adjusts the level of the Stereo Return A that i.s assigned to ihe Monitor A mix.
STEREO RETURN A TO MON B (17)
Adjusts the level of the Stereo Return A that Is as.signed to the Monitor B mix,
STEREO RETURN A LEVEL (18)
Adjusts the level of the Stereo Return A that is added into the Lcft-Righl mix.
STEREO RETURN A RAN (19)
Detennines the baJaiice of the Stereo Reluin A Into the Left-Right mix. If ihc Stereo Return A signal is mono, it
lUc Left-Rlgln position.
MONITOR A MASTER FADER (20)
Sct^ the overall Monitor A mix level ienl to the Monitor A output Jack.
EFFECTS B MASTER (21)
Sets the overall Effects B mix level sent to the Effects B output jack.
STEREO RETURN B TO MON A (22>
Adjusts the level of the Stereo Return B that if; assigned to the Monitor A mix,
STEREO KE1 LiRN B TO MON B (23)
Adjusts the level ot the Stereo Return B that is assigned to the Monitor B mix.
STEREO RETURN B I-EVEL (24)
Adjusts the level of the Stereo Return B that is added into the Left-Right mix.
