Summary of Contents for Fortinet FortiWiFi 50G DSL

  • Page 1 QuickStart Guide FortiWiFi 50G DSL FWF-50G-DSL FWF-50G-DSL-QSG-20240430.indd 1 FWF-50G-DSL-QSG-20240430.indd 1 4/30/2024 2:34:17 PM 4/30/2024 2:34:17 PM...
  • Page 2 FortiGate Cloud Experience simplified cloud provisioning, security analytics, remote access, hosted log retention and reporting at https://fortigate.forticloud.com FortiExplorer Go Rapidly provision, deploy and manage your Fortinet Security Fabric Platform, free on iOS and Android: https://docs.fortinet.com/product/fortiexplorer-go/ FWF-50G-DSL-QSG-20240430.indd 2 FWF-50G-DSL-QSG-20240430.indd 2 4/30/2024 2:34:18 PM...
  • Page 3: Package Contents

    Package Contents FortiWiFi 50G DSL FWF-50G-DSL 1x FortiWiFi Device 1x QuickStart Guide 3x AC Adapter Plugs 1x DC Power Adapter (US, EU, UK) 3x Antennas 1x Ethernet Cable 1x DSL Cable FWF-50G-DSL-QSG-20240430.indd 3 FWF-50G-DSL-QSG-20240430.indd 3 4/30/2024 2:34:20 PM 4/30/2024 2:34:20 PM...
  • Page 4 Setup FortiExplorer Go Install Enable Follow the on-screen FortiExplorer Go Bluetooth instructions Port 1 If Static IP: 192.168.1.1/24 Ethernet Cable FWF-50G-DSL-QSG-20240430.indd 4 FWF-50G-DSL-QSG-20240430.indd 4 4/30/2024 2:34:20 PM 4/30/2024 2:34:20 PM...
  • Page 5 None (available for purchase) Flow Control: None Console Port FortiGate Cloud Login to https://fortigate.forticloud.com using your Fortinet Credentials, then click Add FortiGate and enter the Cloudkey Internet Ethernet Cable WAN port FWF-50G-DSL-QSG-20240430.indd 5 FWF-50G-DSL-QSG-20240430.indd 5 4/30/2024 2:34:20 PM 4/30/2024 2:34:20 PM...
  • Page 6 Front FWF-50G-DSL FortiWiFi 50G DSL LINK/ACT STATUS xDSL WIFI BLE/RESET Signed Firmware BLE / RESET Press to enable BLE; press and hold for system reset Blue: BLE connected Flashing Blue: BLE in discovery Off: BLE not connected Signed Firmware BIOS Security Level Controlled by Signed Firmware Switch, see Admin Guide at https://docs.fortinet.com...
  • Page 7 LINK/ACT LINK/ACT xDSL WIFI SPEED LINK/ACT Green: DSL connected Green: Power detected Green: DSL activity Flashing Off: Power not detected Off: DSL not connected STATUS xDSL Green: VDSL connection Green: Operating normally Amber: ADSL connection Green: Booting up Flashing Off: No DSL connection Off: Device is off WIFI Green: WiFi is on...
  • Page 8 Rear FWF-50G-DSL WIFI WIFI Signed Firmware Power Input 12V DC, 100-240V AC, 50/60Hz adapter USB 3.0 Port (USB-A) CONSOLE Port (RJ-45) CLI management Signed Firmware Switch FWF-50G-DSL-QSG-20240430.indd 8 FWF-50G-DSL-QSG-20240430.indd 8 4/30/2024 2:34:21 PM 4/30/2024 2:34:21 PM...
  • Page 9 WIFI WIFI DSL Port (RJ-11) Ports (5x RJ-45) WAN, A – FortiLink, 3, 2, 1 Antenna Connector (3x SMA) FWF-50G-DSL-QSG-20240430.indd 9 FWF-50G-DSL-QSG-20240430.indd 9 4/30/2024 2:34:21 PM 4/30/2024 2:34:21 PM...
  • Page 10: Cautions And Warnings

    Cautions and Warnings Environmental specifications Ambient operating temperature: 0°C to 40°C Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature, Storage Temperature, Humidity, and Altitude) Référez à la Fiche Technique de ce produit pour les caractéristiques environnementales (Température de fonctionnement, température de stockage, humidité et l’altitude). Safety Battery –...
  • Page 11: Regulatory Notices

    REN without a decimal point (e.g., 03 is a REN of 0.3). If you experience trouble with this equipment, for repair or warranty information, please refer to Fortinet’s End-User License Agreement which set forth the terms and limitation of Fortinet’s product warranty and contact the following address and phone number for additional information.
  • Page 12 The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits specified for point-to-point and non-point-to-point operation as appropriate. Le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5725-5850 MHz) doit se conformer à...
  • Page 13 EU or countries that have implemented the EU Directives and/or spectrum regulation. Any Fortinet products not obtained directly from Fortinet or Fortinet’s authorized partners may not comply with EU Directives and Fortinet makes no assurances for such products.
  • Page 14 Denna produkt överensstämmer med direktiv 2014/53/EU. Note: The full Declaration of Conformity for this product is available in the link below: https://site.fortinet.com/ProductRegulatory/EU The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range in the following countries:...
  • Page 15 This product is in compliance with Statutory Instrument 1206 Radio Equipment Regulations 2017 The full Declaration of Conformity for this product is available in the link below: https://site.fortinet.com/ProductRegulatory/UK The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range in the following countries: FWF-50G-DSL-QSG-20240430.indd 15...
  • Page 16 Copyright © 2024 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet, Inc., and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All other product or company names may be trademarks of their respective owners.
