- Page 1 VO LT 6 0 0 Model: 801600, 801600T, 801601 LIT. #: 11-14...
- Page 2 INTRODUCTION The Simmons Laser Rangefinder delivers accurate range performance to +/- one yard. Range to a deer as far as 200 yards/182 meters out, or to a tree 400 yards/366 meters away for a reference point. The single button operation allows outdoor enthusiasts to easily measure distance with confidence.
-
Page 3: Operational Summary
OPERATIONAL SUMMARY While looking through the monocular, depress the power button once to activate the inview display system (LCD). Aim the SIMMONS LASER RANGEFINDER at a target at least 10 yards away, depress and hold the power button down until range reading is displayed. Release the power button. -
Page 4: Specifications
SPECIFICATIONS OPTICAL DESIGN – The SIMMONS LASER RANGEFINDER features a fixed focus monocular optical system for viewing your target. A liquid crystal display (LCD) is mounted within the optical system and when activated, displays a reticle for targeting, yards, and low battery indicators. Inherent in the manufacturing process are small black spots that appear in the optical system. -
Page 5: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY Your Simmons product is warranted to be free of defects in materials and workmanship for one year after the date of purchase. In the event of a defect under this warranty, we will, at our option, repair or replace the product, provided that you return the product postage prepaid. This warranty does not cover damages caused by misuse, improper handling, installation, or maintenance provided by someone other than a Simmons Authorized Service Department. -
Page 6: Troubleshooting Table
IN U.S.A. Send To: IN CANADA Send To: Attn.: Service Department Attn.: Service Department 9200 Cody 25A East Pearce Street, Unit 1 Overland Park, Kansas 66214 Richmond Hill, Ontario L4B 2M9 For products purchased outside the United States or Canada please contact your local dealer for applicable warranty information. In Europe you may also contact: Bushnell Germany GmbH European Service Centre Mathias-Brüggen-Str. - Page 7 There is no reset button to clear last range reading before ranging another target: • The last range reading does not need to be cleared before ranging another target. Simply aim at the new target using the LCD’s reticle, depress the power button and hold until new range reading is displayed. If target range cannot be obtained: •...
-
Page 8: Fcc Note
FCC NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 9 ©2014 B.O.P. • SIMMONS, ®, TM DENOTES TRADEMARK OF B.O.P...
