OPERATING INSTRUCTIONS
ENOITALIA s.r.l.
50050 CERRETO GUIDI (FI)
Tel.+39 0571 588031 - fax +39 0571/588080
WWW.ENOITALIA.NET INFO@ENOITALIA.NET
ATTENTION:
This manual must be leave near the machine in a dry place.
The user of the machine and the maintance staff must be sure of the location of this manual.
AND TECHNICAL MANUAL
DESTALKING – CRUSHING
MACHINE MODEL JOLLY
60 REVERSE
ENGLISH
Advertisement
Table of Contents
Related Manuals for Enoitalia JOLLY 60 REVERSE
Summary of Contents for Enoitalia JOLLY 60 REVERSE
- Page 1 AND TECHNICAL MANUAL DESTALKING – CRUSHING MACHINE MODEL JOLLY 60 REVERSE ENGLISH ENOITALIA s.r.l. 50050 CERRETO GUIDI (FI) Tel.+39 0571 588031 - fax +39 0571/588080 WWW.ENOITALIA.NET INFO@ENOITALIA.NET ATTENTION: This manual must be leave near the machine in a dry place.
-
Page 2: Table Of Contents
1. CONTENTS OF THE MANUAL................3 EC DECLARATION OF CONFORMITY………………………………………………….4 2. SAFETY RULES ....................5 2.1. ADVICES ....................... 5 3. STICKERS ON THE MACHINE AND SAFETY PROTECTION ......6 4.TECHNICAL DRAWING ..................8 5. USE OF THE MACHINE ..................9 6. -
Page 3: Contents Of The Manual
1. CONTENTS OF THE MANUAL This volume contains information accompanied drawings and/or diagrams necessary for installation, operation and maintenance of the crusher-destemmer. It also establishes safety standards that staff must respect the machine. This volume is intended for: the establishment or department managers, staff involved with the installation, the machine operator staff, maintenance personnel It is forbidden operation and repair of the machinery by persons who have read... -
Page 4: Ec Declaration Of Conformity
Via Prov. Pisana, 162 Cerreto Guidi (Fi) P.iva 03987590480 declares, in sole responsibility, that the following product: JOLLY 60 REVERSE YEAR OF CONSTRUCTION: 2023 Referred to in this declaration conforms with the following directives and standards • 2006/42/CE and subsequent amendments and national provisions implementing •... -
Page 5: Safety Rules
4. Use of the machine by not qualified operator 5. Not allowed modification to the machine The only use of the machine is the one indicate in this manual. Enoitalia srl decline all the responsibility for any different use of the machinery 2.1 DESCRIPTION... -
Page 6: Stickers On The Machine And Safety Protection
maintenance manual to allow you to make the best use of the machine thus extending its service life. 3. STICKERS ON THE MACHINE AND SAFETY PROTECTION Label with name and serial numeber The machine is provided with protections for the motors and for all the gears, to avoid the direct contact with harm or fingers. - Page 7 To crush or top Loading screw Don’t remove the safety protection cut harm and Destemmer shaft Stop the machine and disconnect the motor’s plug by the net before fingers Transmission to start any repair or maintenance. gears Don’t repair the machine while it is working To crush leg and Fall down of the Use safety shoes...
-
Page 8: Technical Drawing
4.TECHNICAL DRAWING Screw loading setting Stem exit Couple of rollers Crushing setting Panel control General switch Driving gears for basket and shaft Control to switch off rollers Start and stop of destemming Emergency stop Destemming speed setting... -
Page 9: Use Of The Machine
5. USE OF THE MACHINE The machine you have purchased, Model JOLLY 60 REVERSE , is designed exclusively for the purpose of destalking and crushing grapes. The constructor cannot be held responsible for any damage to the electrical or mechanical parts of the machine caused during transportation. -
Page 10: Installation And Cleaning
7. INSTALLATION AND CLEANING 7.1 FIRST CONTROL The destemmer JOLLY 60 REVERSE is supplied on pallet. Inside there is : n°1 manual instruction; n°1 assembled destemmer crusher with motor The hopper safety protection is supplied in a separate cartoon . -
Page 11: Cleaning
7.2 CLEANING Remove machine from packaging and dispose of the latter in compliance with law regulations. Adjust the legs height by the telescopic system. Screw for height setting Wash machine thoroughly to eliminate any residue and any dust on its surface. Take care of the engine, cord and plug. - Page 12 First to proceed with the next points see the attach n°1 OPENING AND REMOVE OF BASKET AND SHAFT 3. Pull out the shaft without any rotation 4. take out the destemming basket: move up a little to separate by the 2 plastic wheels, and turn the basket making care the screw is driven trough the opening like in the next photo : 5.
-
Page 13: Function
8. FUNCTION The machine is designed to destalk the bunches of grapes that are loaded into the loading hopper. A screw feeder conveys the bunches towards the rotating cage were the destalking takes place. The speed of loading can be adjust by using the gear speed variator install on the hopper . ATTENTION: do not use the wheel of the speed-adjustment drive unit when the engine is off as this would cause the wheel to break). - Page 14 Before start-up remember to check the oil level of the speed-adjustment drive unit and to top it up if necessary. It is important that this unit never runs dry as this would cause it break. To start the machine, proceed with the electrical connection which must be carried out by a qualified technician.
-
Page 15: Washing And Maintenance
11. WASHING AND MAINTENANCE After using the machine and in any case at the end of each working day, unplug the machine and wash thoroughly to eliminate any residue To perform a daily washing, the machinery is equipped with a system of internal rinsing which is accessed by connecting the water network to the quick coupling installed on the top of the machine: once the connection is initiated and open the water supply, the destemmer must start and leave running as long as the output water is without of processing residues... -
Page 16: Possible Causes Of Malfunction
POSSIBLE CAUSES OF MALFUNCTION PROBLEM REMEDY The machine has difficulty in starting.. Check that machine is receiving the correct line voltage. Do not use extension leads that are too short as this could cause a voltage reduction. Check the tension of the transmission belts with the register provided. -
Page 17: General Prevention Rules
GENERAL PREVENTION RULES 1. The user must scrupulously follow the accident prevention regulations in force in the various countries and the instructions contained in this manual. 2. During maintenance and repair operations, remember to interrupt the electrical power connection by switching off the mains and by unplugging the machine. This operation must be carried out to avoid accidentally starting the machine which could cause injuries to people and damage to the machine. -
Page 18: Conditions Of Guarantee
We decline our obligations in case the payment conditions agreed are not respected. Any complaint should be made in writing by the buyer to ENOITALIA Srl within 8 days from the date of purchase. -
Page 19: Shaft
ORDER TO SIMPLIFY THE REMOVAL OF THE WHEEL ITSELF BY ELIMINATING THE NEED TO USE THE KEY the seat. The wheels must not be removed INSIDE THIS OPERATION MUST BE AGREED WITH ENOITALIA TECHNICAL DEPARTMENT Rotate the basket till the complete extraction... -
Page 20: Attached 1: Lubrication And Routine Maintenance
INTEGRATION: Selection and refinement rollers The JOLLY REVERSE destemmer in the 820 configuration is equipped with a motorized roller table in PVC with differentiated spacing, which has the function of perfecting the cleaning of the destemmed product, selecting the grains and eliminating the green (part of stem, seeds, leaves). The destemming machine is installed on a stainless steel frame with telescopic legs: to adjust the height at which to position the destemmer, it is necessary to lift the machine using the special lifting eyebolts (see paragraph 7.1 ) and adjust the legs with the special key tool included with the... - Page 21 The first part of the roller group is equipped with a removable collection tray with a filtration grid. Connect a suitable flexible pipe to the outlet of the fitting to collect the product deposited in the tray Hopper filtration connection Collection tray Liquid outlet fitting Filtration grid...
-
Page 22: Integration: Automatic Sorting Table
The machine is supplied ready for use. Check that the destemmer discharge outlet is positioned on the first part of the selection group (area with filtration rollers). if necessary, move the group using the appropriate handle Selection rollers Filtration rollers Push handles Leg adjustment Scroll support... - Page 23 During use, the possibility of adjusting the rotation speed of the rollers allows to optimize the cleaning and efficiency of the machinery. Ensure that berries don’t run over the middle part of the sorting roller. If there are parts of greenery at the grape discharge, the rotation speed must be increased.
