Enoitalia BB 20 User Instructions

Semi-automatic filling machine for bag in box
Hide thumbs Also See for BB 20:

Advertisement

Quick Links

Download this manual
User instructions and technical manual
Semi-automatic filling machine for Bag in box
The company Enoitalia S.r.l. with registered office and operating headquarters in the borough of
Cerreto Guidi (FI) village of Pieve a Ripoli, in via Prov. Pisana 162 operating in the wine trade as the
manufacturer and vendor of the machines:
SEMI-AUTOMATIC FILLING MACHINE BB20
at its own responsibility that the product in question conforms to the provisions of the following
community regulations, including the latest modifications to such, and to the relative national
legislation implementing such:
2006/42CEE, 95/2006/CE, 89/336CEE, 2004/108/CE, 2000/14 CEE
Cerreto Guidi , 01/01/2014
INTRODUCTION
WARNING!
Before installation carefully read the instructions given below, since this manual constitutes an
essential part of the machine.
This machine is recommended for filling bags in plastic material with liquids destined for human
consumption such as: WINE, MILK, WATER.
It is not suitable for pumping inflammable liquids or for use in environments with petrol,
concentrated acids or solvents.
The Manufacturer declines all responsibility for damage deriving from improper use of the
machine, or from failure to observe the instructions provided in this manual.
ENOITALIA S.r.l.
EC DECLARATION OF CONFORMITY
"BB 20"
DECLARES
Enoitalia srl
Falorni Fabio

Advertisement

loading
Need help?

Need help?

Do you have a question about the BB 20 and is the answer not in the manual?

Questions and answers

Related Manuals for Enoitalia BB 20

Summary of Contents for Enoitalia BB 20

  • Page 1 “BB 20” EC DECLARATION OF CONFORMITY The company Enoitalia S.r.l. with registered office and operating headquarters in the borough of Cerreto Guidi (FI) village of Pieve a Ripoli, in via Prov. Pisana 162 operating in the wine trade as the...
  • Page 2 1. DESCRIPTION The machine is composed of the following components (photo no.1):  Main control panel (A),made in pvc or stainless steel, with touch screen display, master switch (H), start and stop buttom, speed switch for frequency inverter (option)  Stainless steel pump with rubber impeller (B) ...
  • Page 3 compressor, sealing valve, air extraction and nitrogen injection valves so that all the operations take place in the right order and with the right timing. The filling machine has been designed for use by qualified personnel, given that it could constitute a source of danger to people.
  • Page 4 2.4 TURNING ON THE MACHINE AND FAMILIARISING WITH THE CONTROL PANEL The panel control is composed of: 1) General switch (I ON – O OFF ) 2) Start switch ( start the filling ) 3) Stop / Reset switch ( stop the machine and reset all the value) 4) Plc display Turn on the machine by switching the red switch on the control panel to position “1”.
  • Page 5 Select the option PARAMETRI on the first screen, and the following screen will appear with the values to be set: PARAMETRI CICLO DIS. 4 0.0 SEC GESTIONE BLOCCO 3 SEC GESTIONE VUOTO 0.0 SEC GESTIONE AZOTO 1 1.5 SEC GESTIONE AZOTO 2 AVANTI ESCI ...
  • Page 6  AUTOTUNING: This parameter allows you to automatically calibrate the instrument after a first filling. To access this section, the operator must first enter a password (see dis17). Then you must enter the value of the quantity actually filled and not the quantity required (for example, if you selected a quantity of 5 liters and after the first filling you get a value of 4,850, the operator has to type in the value of Autotuning 4,850).
  • Page 7 INGRESSI\USCITE USCITE INGRESSI FORZA CONTALITRI POMPA ON DIS. 8 ING. 2 EV. VINO ON START EV. BLOCCO ON STOP EV. VUOTO ON ING. 4 EV. AZOTO ON AVANTI ESCI ESCI LINGUA DIS. 9 ITALIANO LINGUA INGLESE FRANCESE SPAGNOLO TEDESCO ESCI ESCI...
  • Page 8 Select the option ALLARMI , and the following screen will appear with the values to be set: in this area it is possible to cancel the alarm connected no-liquid inside the machine ALLARMI DIS. 10 DISAB.ALLARME ERROR. CONTAL. RESET ESCI Select the option CONTATORI , and the following screen will appear with the values to be set: it display the number of the bags filled and the total of the liter CONTATORI...
  • Page 9 If prefer clearing with liquid select LAVAGGIO: he can use hot liquid or chemicals (i.e Percisan or Idrosan AEB). Press Start and the machine begin a washing cycle. The display indicate how many second is working LAVAGGIO DIS. 13 START ESCI If the user select VAPORE, the following screen will appear with the values to be set.
  • Page 10 Select the option RICETTE , and the following screen will appear with the values to be set : after the setting of all the previous parameter , it is possible store the values combining them with a recipe that can be recalled at a later time. DIS.
  • Page 11 The adjustment of the K factor depends on the size of error: only adjust this parameter if the error is more than ± 500 g. In these cases adjust the K value by 5 to 10 units, repeat the filling procedure and check the weight obtained.
  • Page 12 4.2 FILLING. Place the plastic bag on the prong with the cap inserted, as shown in photo no.4. N°5 N° 4 Adjust the height of the prong in relation to the shelf of the filling machine so that once the bag has been filled, the level of the liquid inside the bag reaches the plastic top of the same.
  • Page 13 Set the quantity of liquid to be filled, the seconds of depression and if applicable the seconds of nitrogen injection on the electronic display. Do not change the adjustment parameter values. Make sure that the compressor is working as indicated in the INSTALLATION section. Turn on the machine by pressing the START button.
  • Page 14 5. POSSIBLE CAUSES OF MALFUNCTIONING PULIZIA, MANUTENZIONE RIMESSAGGIO WARNING All repairs must be carried out directly by Enoitalia srl or by qualified and specialised staff In the case of any repair operations use original spare parts only by contacting the retailer or manufacturer directly.
  • Page 15  Read this manual carefully and thoroughly before using the machine and keep it to hand for any future reference.  Enoitalia S.r.l. is not responsible for any damage deriving from modifications made to the machine by third parties.  Enoitalia S.r.l. reserves the right to make manufacturing modifications at any moment without being under any requirement to communicate such.
  • Page 16 Via Prov. Pisana, 162 Cerreto Guidi (Fi) MODEL FILLING FOR BAG IN BOX BB 20 Year of manufacture: 2015 The undersigned company hereby DECLARES at its own responsibility that the machine which this declaration refers to complies with the provisions of : ...
