ENOITALIA S.r.l.
User instructions and technical manual
Semi-automatic filling machine for Bag in box
The company Enoitalia S.r.l. with registered office and operating headquarters in the borough of
Cerreto Guidi (FI) village of Pieve a Ripoli, in via Prov. Pisana 162 operating in the wine trade as the
manufacturer and vendor of the machines:
SEMI-AUTOMATIC FILLING MACHINE BB10
at its own responsibility that the product in question conforms to the provisions of the following
community regulations, including the latest modifications to such, and to the relative national
legislation implementing such:
2006/42EEC, 73/23EEC, 89/336EEC, 89/366EEC, 2000/14 EEC
Cerreto Guidi , 02/02/2008
INTRODUCTION
WARNING!
Before installation carefully read the instructions given below, since this manual constitutes an
essential part of the machine.
This machine is recommended for filling bags in plastic material with liquids destined for human
consumption such as: WINE, MILK, WATER.
It is not suitable for pumping inflammable liquids or for use in environments with petrol,
concentrated acids or solvents.
The Manufacturer declines all responsibility for damage deriving from improper use of the
machine, or from failure to observe the instructions provided in this manual.
"BB 20"
EC DECLARATION OF CONFORMITY
DECLARES
Enoitalia srl
Falorni Fabio
Advertisement
Related Manuals for Enoitalia BB 20
Summary of Contents for Enoitalia BB 20
- Page 1 “BB 20” EC DECLARATION OF CONFORMITY The company Enoitalia S.r.l. with registered office and operating headquarters in the borough of Cerreto Guidi (FI) village of Pieve a Ripoli, in via Prov. Pisana 162 operating in the wine trade as the...
- Page 2 1. DESCRIPTION The machine is composed of the following components (photo no.1): • Main control panel (A), with programme display and master switch (H) • Stainless steel pump with rubber impeller (B) • Electric compressor(C) • Flow sensor (D) • Filling head (E) composed of a pincer for extracting and inserting caps, and by a filling cylinder fitted with pneumatic valve (F) and predisposition for air extraction and nitrogen injection system) (see photo no.3).
- Page 3 replaced by means of a stainless steel pincer, manoeuvred manually by the operator, without the need to move the bag. The electronic system makes it possible to manage the functioning of the pump, compressor, sealing valve, air extraction and nitrogen injection valves so that all the operations take place in the right order and with the right timing.
- Page 4 Open the valve or the tap which the decanting tube is connected to, so as to enable the tubes to fill up partially. 2.4 TURNING ON AND USING THE CONTROL PANEL. The panel has the following components: 1) Mains switch (I ON – O OFF ) 2) Start button (starts programme) 3) Stop/ Reset button (stops programme and resets) 4) Display with touch screen.
- Page 5 Use the “Menu” button to move on to PAGE 2. The second page contains the following parameters to be set (Fig. 3): MENU’ MENU PARAMETRI SALVA PARAMETERS SAVE CONTATORI COUNTERS CONFIG. ESC. CONFIG. EXIT • “PARAMETERS”: to set the filling parameters on page 3. •...
- Page 6 This page shows the following parameters: “VACUUM TIME”: gives the value in seconds of the vacuum to be applied to the bags. If • set at 0 the vacuum phase of the bags is disabled, to enter or modify this value just touch the display where the numerals appear, to access the enter data page 10.
- Page 7 INESISCI CODICE : INSERT CODE : ITALIANO ITALIAN CONTRASTO CONTRAST EXIT This page shows the following parameters: • “0”: upon request an access code to the testing/servicing and programming mode may be provided, touch the screen here to enter the code enter mode. •...
- Page 8 • “CONTRAST” touch here to change the contrast of the screen. • “BRIGHTNESS”: touch here to change the brightness of the screen. • “EXIT”: to exit the page and go back to page 1. Use the “SAVE” button to move on to PAGE 7. SALVA ? SAVE ? ESC.
- Page 9 SALVA DOVE ? SAVE WHERE? 5 LITRI 5 LITRES 10 LITRI 10 LITRES ESC. EXIT This page enables you to name and number the programme-settings you wish to save and call up the programme when needed. Subsequently, when a number of programmes have been entered, call them up using the ↑ ↓ keys to Load the programme and repeat the instructions for saving.
- Page 10 One of the standard fittings installed on the pump is a hose connection fitting for tubes of d.20; upon request the pump can be supplied with a hose connection fitting of d.30. The use of decanting tubes of dimensions other than those indicated is not recommended in that they might impair the proper functioning of the machine.
- Page 11 This WASHING operation must be repeated at the moment of putting the machine away in storage, or whenever it has not been used for long periods of time. In this case the application of a few drops of glycerine inside the pump body is recommended to keep the rubber impeller inside lubricated. 4.2 FILLING.
- Page 12 Set the quantity of liquid to be filled, the seconds of depression and if applicable the seconds of nitrogen injection on the electronic display. Do not change the adjustment parameter values. Make sure that the compressor is working as indicated in the INSTALLATION section. Turn on the machine by pressing the START button.
- Page 13 5. POSSIBLE CAUSES OF MALFUNCTIONING WARNING All repairs must be carried out directly by Enoitalia srl or by qualified and specialised staff In the case of any repair operations use original spare parts only by contacting the retailer or manufacturer directly.
- Page 14 • Read this manual carefully and thoroughly before using the machine and keep it to hand for any future reference. • Enoitalia S.r.l. is not responsible for any damage deriving from modifications made to the machine by third parties. • Enoitalia S.r.l. reserves the right to make manufacturing modifications at any moment without being under any requirement to communicate such.
