CSL UNITY F27B-ALS Manual page 27

1
+ Loudspeaker
12
2
Ven�la�on slots
2.5" SSD/HDD
3
Installa�on slot
4 RJ45 / LAN port
5 HDMI port
6 Power connector
3.5mm jack /
7
Microphone In
3.5mm jack /
8
headphone jack
9
USB 2.0/3.2 Gen 2 -
+
Connectors
10
SSD/RAM
11
Slot
13 microSD card reader
For the sound output of the All-in-One PC.
For the ven�la�on of the All-in-One PC.
In this expansion bay, 2.5" SSDs or hard disks
can be installed for memory expansion.
Via the network port it is possible to connect
the PC to your network with a LAN cable.
You can connect another monitor or TV to the
HDMI output. (out: max. 4K @ 60 Hz)
Power supply of the All-In-One PC:
DC 19V / 3A.
You can connect a microphone with a 3.5mm
jack plug to this port.
You can connect headphones or a sound system
with a 3.5mm jack to this port.
You can connect data storage devices such as a
USB flash drive or USB devices such as a USB
mouse/USB keyboard to these ports.
In this expansion bay, the SO-DIMM DDR4 RAM
can be configured individually. Furthermore, an
M.2 PCIe NVMe/ SATA 2242 can be installed.
This SD card reader offers you the possibility to
read and write SDXC and SDHC memory cards.
