- Page 1 SolarEdge TerraMax Inverter Quick Installation Guide PN: SE330K-xxxxxxxxx Scan for full Installation Guide For North America Version 1.2...
-
Page 2: Handling And Safety Instructions
SAVE THESE INSTRUCTIONS – This guide contains important instructions for Before installation, read the SolarEdge TerraMax Inverter that should be followed during installation and HANDLING AND SAFETY INSTRUCTIONS maintenance. Using this equipment in a manner not specified in this guide by... -
Page 3: Fcc Compliance
FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Installing The Power Optimizers
Installing the Power Optimizers 4 5 6 Use SolarEdge Designer Create a new site in Monitoring Download SolarEdge Mapper Platform and import PV layout to map string Power Optimizers to create and design SE system from SolarEdge Designer https://designer.solaredge.com... - Page 5 Installing the Power Optimizers Install the H1300 Power Optimizer Scan QR code using Mapper ¼” / M6 0.4“ / 10 mm Stainless steel 84 lb*in / 9.5 N*m 0.5” / 12.7 mm 0.4“ / 10 mm 0.4“...
- Page 6 Connecting the Power Optimizers CAUTION! Do not sharply bend the DC cables. Keep proper bending radius to avoid cable break. Do not use stretched cabling. Using only MC4 connectors compatible with the Power optimizer. MAN-01-01059-1.2 MAN-01-00XXX-1.0...
- Page 7 Connecting PV Strings Combiner Box When connecting three or more H1300 strings to a combiner box, it is recommended to use a 30A fuse for each individual string. However, be sure to check local electrical codes and regulations to determine the proper fuse sizing for your specific installation. Turn off switches and check string polarity.
- Page 8 Maintaining Clearance Keep 7.87” / 20 cm where annual average high temperature Min Indoor Side By Side Clearance equals or below 77˚F / 25˚C. For maintenance and future 19.7" / removal, It is recommended to keep at least 15.75” / 40 cm 39.4“...
- Page 9 Mounting 40.39“ / 1026 mm 386 lb 175 KG 36.46" / 926 mm Ø 1/2“ / 13 mm Optional MAN-01-00XXX-1.0 MAN-01-01059-1.2...
- Page 10 Removing Covers, Drilling Holes, and Grounding Conduits WARNING DISCONNECT POWER BEFORE REMOVING COVERS P 1 0 CAUTION! Remove panels from inverter before drilling holes Use center drill guides on panels WARNING! Connect PE wiring 1.9 lb*ft if a metal conduit is used MAN-01-01059-1.2 MAN-01-00XXX-1.0...
- Page 11 Connecting the PV Arrays and Protective Earth (PE) Max thickness 0.51” / 13 mm Max width 1.77” / 45 mm Ø ½” / 12 mm 143.85 lb*in/ Optional 16.27 N*m Bellville Spring Washer 315 lb*in / 35 N*m Heat shrink insulation Max: 600 kcmil / 300 mm PV Array 1...
- Page 12 Connecting AC and Protective Earth (PE) Max thickness 0.51” / 13 mm Max width 1.77” / 45 mm Ø ½” / 12 mm Optional Bellville Spring Washer 315 lb*in / 35 N*m Heat shrink insulation Brown Orange Yellow Max: 600 kcmil / 300 mm Ø...
- Page 13 Accessing the Communication Compartment 34.5 lb*in / 3.9 N*m MAN-01-00XXX-1.0 MAN-01-01059-1.2...
-
Page 14: Connecting Communication
Connecting Communication CAN Bus (for connection between inverters) IMPORTANT! DO NOT connect inverters other than the SE330K. Up to 13 Inverters per CAN Bus Rotate the First Inverter Last Inverter connector and IMPORTANT! Move the CAN Switch of the first plug-in CAN Switch ON CAN Switch ON... - Page 15 Unlocking Relays and Installing the Covers Move switch to Operation mode Shipment / Operation 31 lb*in / 3.5 N*m MAN-01-00XXX-1.0 MAN-01-01059-1.2...
- Page 16 Commissioning (Part 1) Commissioning when connected to AC from Grid Download Start & follow SetApp Switch ON DC Switch ON AC SolarEdge SetApp Start Download Commissioning when connected only to DC from PV Array Switch ON DC Start & follow SetApp Start MAN-01-01059-1.2...
- Page 17 Commissioning (Part 2) Protocol SolarEdge SolarEdge Leader Commissioning Protocol SolarEdge Follower Detect Country & Grid Pairing Site Communication Tap to simultaneously commission all Follower Inverters Status MAN-01-00XXX-1.0 MAN-01-01059-1.2...
-
Page 18: Led Indications
LED Indications For detailed Status and System Performance LED Indications: https://www.solaredge.com/leds POWER COMM FAULT Green Blue System is producing Power AC is connected but the system is not producing power Inverter is communicating with the Monitoring platform System error MAN-01-01059-1.2... - Page 19 Support Contact Information If you have technical problems concerning SolarEdge products, please contact us: https://www.solaredge.com/service/support Subject to change without notice. Copyright © SolarEdge Inc. All rights reserved. March 2024.
