CB2 charlie Quick Start Manual

charlie
Thank you for purchasing the Charlie Wardrobe. This
page lists all the contents included in the box. Please take
the time to identify the hardware as well as the individual
components to this product. As you unpack and prepare
for assembly, place the contents on a carpeted or padded
area to protect them from damage.
Note: 2 people are recommended to safely assemble this product.
components
1 - top 1 - bottom
panel panel
2 - side panels
(1 left, 1 right)
tools required
(We recommend the use of hand tools instead of power tools)
Made in Vietnam - r05
WARDROBE
1 - top
fixed shelf
1 - back
panel
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
assembly hardware
30 - wood 36 - hinge
dowels screws
4 - cams 4 - cam 6 - hinges
screws
mounting hardware
4 - large 4 - small 4 - plastic
screws screws anchors
Missing hardware?
Please call 800.606.6387 for replacements.
2 - adjustable 1 - bottom
shelves fixed shelf
2 - door
panels
9 - small 19 - large
bolts bolts
8 - shelf 2 - back
pins screws
2 - wall 4 - mounting
straps brackets
1 - bottom back
crossbar
1 - partition
1 - top back 2 - shelf
crossbar crossbars
phillips head screwdriver
Page 1 of 6
