CB2 CHARLIE Assembly Instructions

charlie
Thank you for purchasing the Charlie Cabinet. This page
lists all the contents included in the box. Please take the
time to identify the hardware as well as the individual
components to this product. As you unpack and prepare
for assembly, place the contents on a carpeted or padded
area to protect them from damage.
Note: 2 people are recommended to safely assemble this product.
components
1 - top
panel
2 - side panels
(1 left, 1 right)

tools required

(We recommend the use of hand tools instead of power tools)
Made in Vietnam - r07
CABINET
1 - bottom
panel
1 - top back
crossbar
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
assembly hardware
16 - wood
dowels
2 - cams
mounting hardware
4 - large 4 - small
screws screws
Missing hardware?
Please call 800.606.6387 for replacements.
1 - fixed
shelf
1 - bottom back
crossbar
1 - back
panel
18 - hinge 2 - small
screws bolts
2 - cam 3 - hinges
screws
4 - plastic 2 - wall
anchors straps
2 - adjustable
shelves
1 - door
panel
phillips head screwdriver
13 - large
bolts
8 - shelf
pins
4 - mounting
brackets
Page 1 of 5
