- Page 1 Stem Pro 1 1/8" A-Head Stem INSTALLATION + OPERATING INSTRUCTIONS...
-
Page 2: Table Of Contents
MTBs, pedelecs and e-bikes. TABLE OF CONTENTS Page The Stem Pro SDS is designed for use on bicycles, Usage approval pedelecs and e-bikes up to 45 km/h. It is NOT suitable for extreme loads that occur in downhill, dual slalom or 2. -
Page 3: Safety Instructions
We strongly recommend that you check your bike in gen- in breakage or damage. Handlebar bags or baskets eral, and the operational safety of the Stem Pro SDS in must not weigh more than 8 kg including load. particular, before each ride. -
Page 4: Scope Of Delivery
3. SCOPE OF DELIVERY 5. FUNCTION / FEATURES · 1 1/8“ A-Head Stem Pro Super Strong SDS The Stem Pro SDS allows to adjust the angle of the stem by using an adjustment joint. To change the angle, the built-in · Instruction manual robust adjustment joint is loosened, brought into the desired position and locked again. -
Page 5: Components / Exploded View
Installation + Operating Instructions by,schulz Stem Pro SDS 05/20 6. COMPONENTS 4. Angle adjustable stem element (exploded view) with internal toothing 1. Central element with internal toothing 5. SDS Front Cap 2. Clamping screw M6 with washer 6. Screws M5 with washers... -
Page 6: Installation Requirements
06/20 Installation + Operating Instructions by,schulz Stem Pro SDS 7. INSTALLATION REQUIREMENTS ing suitable spacer rings (risers) underneath. · Metal A-Head fork shaft 1 1/8“ (threadless) · An A-head claw (starnut) with an M6 thread or a compa- outer diameter 28,6 mm. The use of the stem with a carbon fork rable device must be placed in the fork shaft approx. - Page 7 31.8 to 25.4 mm. For mounting, the open one-piece aluminum sleeve is pushed over the han- dlebar center and bent closed. Suitable for all by,schulz stems. The Stem Pro SDS handlebar clamp has a width of 41mm. Available widths: 41 and 43 mm Threaded...
-
Page 8: Mounting The Stem
1. Loosen the M6 clamping screws of the central element of the stem. 2. Push the Stem Pro SDS onto the end of the fork shaft so that the central element rests directly on the headset or spacer ring (riser). - Page 9 Installation + Operating Instructions by,schulz Stem Pro SDS 09/20 A-Head screw Distance A-Head cap Central element to fork shaft A-Head claw approx. 1 mm Angle adjustable G-G ( 2 : 1 ) stem element with internal toothing Connector/adjustable joint with external...
-
Page 10: Installing The Handlebar
10/20 Installation + Operating Instructions by,schulz Stem Pro SDS 8.2 Installing the handlebar Continuation: Mounting stem / base clamp part 1. Loosen the four M5 clamping screws with washers of the SDS front cap counterclockwise. After removing the screws, remove the front cap. (Fig. 8.2.1+ 8.2.2) Fig. - Page 11 Installation + Operating Instructions by,schulz Stem Pro SDS 11/20 3. Reattach the SDS front cap using the screws. Tighten 5. The handlebar can now be centered and rotated to the them evenly and lightly in a clockwise direction cross- desired grip position. (Fig. 8.2.6) wise.
-
Page 12: Angle Adjustment
12/20 Installation + Operating Instructions by,schulz Stem Pro SDS Continuation: Installing the handlebar 8.3 Angle adjustment 1. To change the stem angle, loosen the screw in the ad- justment joint counterclockwise and turn it out approx. 8 complete turns. (Fig. 8.3.1) Fig. - Page 13 To do so, follow the steps of the handlebar assembly (page 10-11). The grips, brake levers and gearshift may need to be re- aligned as required. 7. The Stem Pro SDS is now ready for use. Fig. 8.3.5...
-
Page 14: Sds System
9. SDS SYSTEM The SDS Link is pushed from the outside into the socket The by,schulz Stem Pro SDS is equipped with the forged of the SDS front cap when the handlebar is mounted and aluminum SDS front cap for the Stem Docking System. - Page 15 Installation + Operating Instructions by,schulz Stem Pro SDS 11/16 SDS Link SDS Link 10 M5 - U SDS Link 10 B6 SDS Link 7 M5 Mounting width 10mm Mounting width 10mm Mounting width 7mm Sleeve Ø 6mm Thread Ø 5mm Thread Ø...
- Page 16 16/20 Installation + Operating Instructions by,schulz Stem Pro SDS SDS Link Pro SDS Link-Pro SDS Link-Pro SDS Link-Pro SDS Link-Pro SDS Link-Pro 10 B6 10 M5 GPS GM-1 Kiox Mounting width 10mm + Mounting width 10mm + e.g. for GoPro ®...
-
Page 17: Maintenance / Care
At every annual bike inspection (at least every 1000km), and usability of the product. the play of the headset and Stem Pro SDS should be pro- Please keep the proof of purchase. Your dealer or your fessionally checked. - Page 18 Germany. For by,schulz products purchased abroad, the warranty conditions issued by our respective country 3. The person who mounts the by,schulz Stem Pro SDS representative shall apply. You can request these from the bears full responsibility for the assembly, compatibility and dealer from whom you purchased the product.
- Page 19 Installation + Operating Instructions by,schulz Stem Pro SDS 19/20 by,schulz components : · Stem SDS 8° · Handlebar Sport SuperStrong Ø31.8mm · SDS Link-Pro with GPS-GM1 for Garmin® GPS NOTIZEN:...
- Page 20 © 2023 No reprints, translations or copies of any kind allowed without the prior written approval of by.schulz GmbH. Subject to technical alterations, errors and misprints excepted. Used photos can vary from the original product. by,schulz GmbH, Saarbrücken/Germany...
