INSTALLATION + OPERATING INSTRUCTIONS
D.1
Ri
www.byschulz.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D.1 Ri and is the answer not in the manual?

Questions and answers

Related Manuals for by.schulz D.1 Ri

Summary of Contents for by.schulz D.1 Ri

  • Page 1 INSTALLATION + OPERATING INSTRUCTIONS www.byschulz.com...

  • Page 2: Table Of Contents

    5. Technical Data 04-05 3. Child seats, trailer couplings or luggage carriers must 6. Seatpost components / Exploded view 06-07 not be attached to a D.1 Ri seatpost as this can lead to 7. Installation requirements 08-09 breakage or damage. 8. Installation 8.1 / 8.2 Tools + preparation...

  • Page 3: Scope Of Delivery

    · D.1 Ri seatpost By means of a remote lever mounted on the handlebars the D.1 Ri allows a comfortable lowering and raising of the · D.1 Ri remote lever saddle position while riding or standing. This allows you to ·...

  • Page 4: Technical Data

    3 Nm D.1/D.2 Ri W-N-L-00001 Fig. 5.1 The D.1 Ri seatpost is shipped with a remote lever matching the seatpost model. You can recognize the correct version by the imprint on the underside or lever radius. (Fig. 5.1) Cable routing: ·...
  • Page 5 Installation + Operating Instructions D.1 Ri Seatpost 5/16 - Overall length - Adjustment range / travel - Min. extended body height - Max. extended body height - Ri Trigger unit Fig. 5.4...

  • Page 6: Seatpost Components / Exploded View

    4.2 by,schulz elastomer stop damper D.1 Ri TRIGGERING MECHANICS Ri / Aluminium 5.1 O-ring 5.2 Fixing screw M4x5,8; hexagon socket 2 mm 5.3 Release unit Ri 5.4 Cable retaining bolt Exploded view D.1 Ri - as of March 2023, subject to change without notice...
  • Page 7 Installation + Operating Instructions D.1 Ri Seatpost 7/16 1.2 1.3 DROPPER LEVER Ri / Aluminium CLAMP BASE : 1.1 Clamp with fine toothing (2x) 1.2 Clamp base / Aluminium 1.3 Adhesive elastomer pad 1.4 O-ring 1.5 Countersunk screw M4x8, Torx T20 1.6 Clamp band / Stainless steel, black anodized...

  • Page 8: Installation Requirements

    5 - 6 Nm 2. Before mounting, make sure that there is sufficient space in the bicycle frame for the installation of the D.1 Ri seatpost and that the seatpost does not collide with other Fig. 7.6.1 Fig.
  • Page 9 Dim. B - Min. installation height extended: 50 mm additional installation space is required below the T100 = approx. 160 mm D.1 Ri for the bending of the cable guide! T160 = approx. 220 mm Dim. C - Max. required installation depth: For further dimensions, see item 5.1 Technical data on...

  • Page 10: Installation

    To be noted before assembly: Measure and note the previously set saddle height. This will make it easier for you to adjust the mounted D.1 Ri 2. The clamp base can be positioned by moving it along seatpost later. Remove the existing seatpost and saddle.
  • Page 11 Installation + Operating Instructions D.1 Ri Seatpost 11/16 3. After you have fi nally chosen the position and alignment 6. The remote lever can be positioned closer or further of the clamp base, tighten the clamp screw fi rmly with the away from the handlebar.

  • Page 12: Routing The Cable

    3. Hold the cable slightly under tension so that it does not Fig. 8.4.2 unhook from the seatpost lever and push the D.1 Ri into the seat tube up to the previously determined seat height. At the same time, pull the complete cable guide back to- wards the handlebar (Fig.
  • Page 13 Installation + Operating Instructions D.1 Ri Seatpost 13/16 4. Hold the cable housing against the remote lever already 7. Pull the cable approx. 2/3 out of the cable housing and mounted on the handlebar and turn the handlebar 90° in shorten the housing to the previously marked length using both directions.
  • Page 14 Installation + Operating Instructions D.1 Ri Seatpost 14/16 11. Thread the inner cable through the adjustment screw of 13. Press the remote lever several times by hand. The cable the remote lever (Fig. 8.5.11.a). will be stretched and the cable hosing will settle slightly in the socket.

  • Page 15: 8.7 Saddle Installation / Adjustments

    Installation + Operating Instructions D.1 Ri Seatpost 15/16 8.6 Saddle assembly Check the correct alignment of the two clamping plates, as this is crucial for the assembly (Fig. 8.6). To adjust the saddle you need a 5 mm Allen key, preferably a torque wrench.

  • Page 16: Operating The Seatpost

    Finally, check the functions of the D.1 Ri seatpost. To ensure proper function and longevity, cleaning and care of the D.1 Ri seatpost should be performed regularly. While sitting on the saddle, operate the remote lever until the saddle starts to lower. Lower the saddle to the mini- If necessary, remove any dirt adhering to the outside, mum height by loading it with your body weight.

  • Page 17: Warranty / Guarantee

    If the defect becomes apparent within 6 months of delivery, it shall be presumed to be a To keep the warranty, the first service of the D.1 Ri is oblig- material or manufacturing defect. atory. Within Europe you only have to pay the costs for this.
  • Page 18 © 2023 No reprints, translations or copies of any kind allowed without the prior written approval of by.schulz GmbH. Subject to technical alterations, errors and misprints excepted. Used photos can varying from the original product. by,schulz GmbH, Saarbrü-...
