◦ MXA310 and MXA mute button: Settings > Logic control > Mute control function > Logic out
Designer's auto route process configures all necessary mute sync and logic settings for you.
Compatible Shure Logic Devices
• P300 (Also mutes supported soft codecs
• ANIUSB-MATRIX (Also mutes
• IntelliMix Room software (Also mutes
• MXA901
• MXA902
• MXA910
• MXA920
• MXA710
• MXA310
• Network Mute Button
• ANI22-BLOCK
• ANI4IN-BLOCK
• Logic-enabled MX microphones connected to ANI22-BLOCK or ANI4IN-BLOCK
◦ MX392
◦ MX395-LED
◦ MX396
◦ MX405/410/415
For help with specific mute sync implementations,

Use Call Status

Designer's call status feature uses microphone LEDs to show if you're in a videoconferencing call or not. This is a room-level
feature, so it applies to all microphones in the same Designer room.
To use call status:
1. Put all microphones and processors (ANIUSB-MATRIX, IntelliMix Room, or P300) in the same Designer room.
2. Select Auto route to create audio and mute control routes. You can also route audio manually.
3. Go to [Your room] > Settings > Call status to turn on call status.
When call status is on:
• Microphone LEDs off = Not in a call
• Microphone LEDs on = In a call
Call status is compatible with the following codecs:
• Microsoft Teams
• Microsoft Teams Rooms
• Zoom Client for Meetings
• Zoom Rooms
Note: If your codec is running on a computer with a Chrome operating system, call status will not work.
connected by USB)
supported soft codecs connected by USB)
supported soft codecs
see our FAQs.
connected by USB)
