Adjusting Settings

Right-click an input, output, or processing block to access the following options:
Channel Settings
Setting
Copy / paste
Mute / unmute
Enable / disable
Edit
Right-click in a blank area to access global settings:
• Mute/unmute all input channels
• Mute/unmute all output channels
• Close all open dialogs

Customizing the Workspace

Create a custom environment to monitor and control a set of inputs, outputs, and processing blocks from a single screen.
There are 2 ways to break out dialogs:
Right-click > Edit
•
• Double-click the input, output, or processing block.
Open as many dialogs as you need to keep important controls available.

Metering and DSP Blocks

A meter appears underneath each input and output to indicate signal levels (dBFS).
DSP blocks have a color when they are turned on. When off, they are gray. Use these tools to troubleshoot audio signals and
verify connections and levels.

Matrix Mixer

The matrix mixer routes audio signals between inputs and outputs for simple and flexible routing:
• Send a single input channel to multiple outputs
• Send multiple input channels to a single output

Crosspoint Gain

Crosspoint gain adjusts the gain between a specific input and output, to create separate submixes without changing input or
output fader settings. Select the dB value at any crosspoint to open the gain adjustment panel.
Function
Copy and paste settings between items. For example, set
the equalizer curve on the USB output, and then use the
same setting for the analog output. Or, copy the gain and
mute status from one input channel to several others.
Mutes or activates the channel
Turns processing on or off (does not apply to matrix mixer or
automixer)
Opens the dialog to adjust parameters. You can also double-
click a block to edit it.
