- Page 1 Instruction Guide 40475GL Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@holman.com 20240115R1 DATE: ________________...
- Page 2 • Any previously installed flooring must be removed prior to installing Holman flooring. • Floor must be assembled in vehicle. • 40475HW hardware kit may be necessary to install some accessories to Holman flooring. (40475HW sold separately). • 40477G threshold kit must be installed when installing Holman flooring. (40477G sold separately).
- Page 3 Instructions – 40475GL Parts List For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 2...
- Page 4 Instructions – 40475GL Hardware For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 3...
- Page 5 • If re-installing OEM D-Rings, remove OEM bolt from D-Ring. • Using M10 x 50mm hex head bolt, M10 lock washer, OEM D-Ring (if desired) and 3/8” fender washer, bolt through Holman floor at OEM D-Ring locations. GO BACK AND TIGHTEN ALL M10 Lock HARDWARE.
- Page 6 1-1/8” drill bit. • In the center of each hole, install a plus nut using the instructions below. • Use 1” x 3/8” plastic spacer (Holman p/n 40501) in each hole as needed to attach accessories to steel van floor.
- Page 7 Instructions – 40475GL Install Plus Nuts DO NOT drill beyond depth of floor or upper installation surface. Always check for wires, fuel tanks and lines, brake lines and other important vehicle functionality items prior to drilling and installing all products.
