PARTS LIST

REF. NO. PART NO. DESCRIPTION
Hitch Clevis Assembly
1 R-2251-10
R-2254-10 Tow Tube
2
R-2270-10 Lift Handle
3
4 B-7063 Caution Label
5 B-7009 Logo Decal
Carriage Bolt, ¼" x ½"
6 11M0808P
2M1012P Hex Bolt, 5/16" x ¾"
7
8 B-1673P Hex Lock Nut, ¼"
9 B-4786 Nylon Insert Lock Nut, 5/16"
Lower Pivot Assembly
10 R-2415-10
Bearing Assembly
11 R-2288
R-2289 Bearing Retainer
12
13 R-2293-1 Inner Dust Shield
14 R-2416 Lift Link
Self-Taping Screw #12x3/8"
15 R-2321
F-577 "E" Ring, 5/8"
16
R-2205 Brush Section
17
18 50M0624P Cotter Pin, 3/16" x 1-1/2"
Brush Holder
19 R-2281
Brush Axle
20 R-2259
R-2261 Dowel Pin
21
22 R-2262 Washer, 5/8" I.D. x 1-3/8
23 R-2263 Washer, 5/8" I.D. x 7/8"
Drive Pinion, Left Hand
24 R-2279-LH
R-2279-RH Drive Pinion, Right Hand
25
B-4768 5/8" Machinery Bushing
26
27 R-2265-CC Wheel, 12" x 3" Bar Trd.
28 R-2280 Drive Gear, 60 Tooth
Outer Gear Cover
29 R-2293-2
R-2306-01 Wheel Axle
30
31 R-2413-10 Brush Housing Assembly
32 45M1111P 5/16" Flat Washer
Vinyl Cap, 1" dia.
33 B-4107
R-2296-10 Hamper Stop Assembly
34
R-2290-10 Upper Frame Assembly
35
36 B-3805 Spring
37 2M1024P Hex Bolt, 5/16" x 1-1/2"
Hex Bolt, 5/16" x 1-3/4"
38 2M1028P
30M1000P Hex Nut, 5/16"
39
40 40M1000P Lock Washer, 5/16"
41 B-3861 Hitch Pin, ½" dia.
Hairpin Cotter, Large
42 D-146P
Flat Grip
43 R-1882
B-3307-S Lock Pin
44
45 2M1040P Hex Bolt, 5/16" x 2-1/2"
46 30M1200P Hex Nut, 3/8"
Lock Nut, 3/8"
47 B-1675P
B-983 Hairpin Cotter, Small
48
R-2303 Clevis Pin, 5/16" x 1-3/8"
49
50 R-2304 Hamper Pull Rope
Special Washer, 5/16"
51 R-618
Lower Tube
52 R-1806-10
R-2194-10 Rear Tube
53
54 R-2195 Hamper Stop Rod
55 R-2426 Hamper/Wind Screen
Hamper Side Tube, Upper
56 R-2300-10
R-2301-10 Hamper Mount Tube
57
R-2307 Hamper Spring Rod
58
59 R-2320 External Retaining Ring, 5/8"
61 R-2257 Set Screw, 1/4"
Carriage Bolt,5/16"x 1-1/2"
62 11M1024P
2M1036P Hex Bolt, 5/16" x 2-1/4"
63
64 R-2463 Adjustment Label
65 L-1744-4 Serial Number Label
QTY
1
2
1
1
1
6
4
6
9
1
2
55
2
2
1
4
6
6
4
4
1
2
2
2
1
1
4
2
2
2
2
1
3
2
1
1
1
1
53
1
1
1
1
1
1 58
1
2
2
56
2
2
2
1
4
2
2
45
1
1
2
2
52
2
2
2
47
4
2
1
1
50
56
58
53
52
33
9
51
57
54
46
5.
L-1788-CC-B
