Do not allow material to remain in the hamper for extended periods of
time. Clean the hamper using a water hose and allow to dry prior to
storage.
Check all moving parts for wear and freedom of movement.
Routine lubrication of the pinion and dowel pin is required. We
recommend in the fall before storage as a minimum. Remove,
cleanand lubricate the dowel pin (21) inside the drive pinions (24 &25)
with a light oil such as WD40, 3in1, or similar. Do not use motor oil or
grease.
Check the drive pinions for wear. These are considered normal wear
parts. Contact our Customer Service Department to purchase
replacement drive pinions (Part Numberts R-2279-RH and R-2279-LH).
Lubricate the wheels annually with multipurpose grease.
Check all fasteners for tightness.
Inspect for rust on painted surfaces. Sand lightly and touch up
damaged areas with enamel paint.
Drive Pinion Reference
Lightly oil, no grease
24 25
23
59
16
20
21
22

SERVICE

SPECIFICATIONS

Maximum Towing Speed ................................. 5 mph
Hamper Capacity ............................................. 15 cu.ft.
Maximum Hamper Weight .............................. 120 lbs.
Empty Weight ................................................... 87 lbs.
Maximum Towed Weight ................................. 207 lbs.
GETTING QUALITY SERVICE
Quality Continues with Quality Service
We provide a process to handle your questions or problems.Follow the steps
below to get answers to any questions you mayhave about your product.
1. Refer to your attachment and machine operator manuals.
2. In North America or Canada, call 1-866-288-6084 and provide product serial
number and model number.
Wheel axle oil/grease annually
12
11
Right Side
NOTE: Pinion is marked "R" or "L" on
the back side. "R" indicates RH and
must be installed on the right hand
side of the unit shown below.
Left Side
15.
