  • Page 1 MODEL 77096-4 owner s manual ’...

  • Page 2: Table Of Contents

    BASIC TUNING ADJUSTMENTS Thank you again for going with Traxxas. We work hard every day to assure you receive the highest level of customer satisfaction MAINTAINING possible. We truly want you to enjoy your new model!

  • Page 3: Before You Proceed

    Traxxas service needs. Maintenance and replacement Traxxas, Ready-To-Race, Ready- & CROSS-REFERENCES parts may be purchased directly from Traxxas by phone or online To-Win, X-Maxx, Velineon, and Throughout this manual, you’ll notice warnings and helpful hints ProGraphix are trademarks or at Traxxas.com.

  • Page 4: Safety Precautions

    14 years of age. and common sense are required. This model must be treated with If you as the user do not accept liability of ownership, Traxxas requests respect and caution to ensure the safety of yourself and others that you do not use this product.
  • Page 5 • ONLY use a Traxxas iD charger to charge Traxxas iD batteries. • DO NOT expose the charger to water or moisture. For indoor • DO NOT let any exposed battery contacts or wires touch each ONLY use a Lithium Polymer (LiPo) balance charger with use only.
  • Page 6 • Use Traxxas High-Current Connectors: Do not change the battery • Do not drive the model close to you where a mistake or loss of and motor connectors. Improper wiring can cause fire or damage to control could cause the model to collide with you or any spectator.

  • Page 7: Tools, Supplies, And Required Equipment

    (part #2890X, sold separately) • Side cutters and/or needle nose pliers 2 LiPo batteries with Traxxas • Phillips screwdriver High-Current Connectors Traxxas Power Cell LiPo iD® batteries are Traxxas Power Cell Batteries strongly recommended for maximum EZ-Peak Live ™ (part #2914,...

  • Page 8: Anatomy Of The X-Maxx

    ANATOMY OF THE X-MAXX Lower Suspension Arm Motor with Cooling Fans Stub Axle Carrier Battery Hold-Down Caster Block (C-hub) Upper Battery Compartment Suspension Traxxas High- Current Connector Accessory Power Panel Chassis Steering Servo Receiver Gear Cover (Under chassis) Access Plug...

  • Page 9: Quick Start: Getting Up To Speed

    QUICK START: GETTING UP TO SPEED The following guide is an overview of the procedures for getting your model running. Look for the Quick Start logo on the bottom corners of Quick Start pages. The Quick Start Guide is not intended to replace the 1.

  • Page 10: Tq Radio And Velineon Power System

    TRAXXAS TQ RADIO & VELINEON POWER SYSTEM INTRODUCTION with each other. The VXL-8s electronic speed control is optimized Your model includes the latest Traxxas TQi 2.4GHz transmitter with to virtually eliminate cogging. Applying the Decals Traxxas Link Model Memory. The transmitter’s easy-to-use design ™...
  • Page 11 TRAXXAS TQ RADIO & VELINEON POWER SYSTEM batteries offer high current handling and much greater resistance Thermal Shutdown Protection - Temperature sensing electronics to the “memory” effect. NiMH batteries generally allow higher used in the VXL-8s electronic speed control detect overloading To prevent loss of radio range capacity than NiCad batteries.
  • Page 12 VXL-8s Electronic Speed Control Traxxas High-Current Connector (Male) to Battery EZ-Set Button Power Switch Battery Compartment (On/Off Button) ** Accessory sensor expansion port for use with the Telemetry Expander Module (see Traxxas.com and included materials for more information) 12 • X-MAXX...
  • Page 13 Make certain you choose the correct type of charger for the 31 to identify the code. 4. Turn on the transmitter and check the status LED for a solid green batteries you select. Traxxas recommends you choose a genuine light. Traxxas EZ-Peak iD charger for safer charging and maximum If the status LED flashes red, the transmitter batteries may be weak, battery life and performance.
  • Page 14 Secure, long-lasting, and easy to grip, the Traxxas connector is engineered to extract all the power your battery has to give. 14 • X-MAXX...
  • Page 15 (center) point of the steering channel. are operating your model, determine the reason for Note: Traxxas Stability Management (TSM) must be completely signal loss and resolve the turned off while adjusting steering trim. See page 17 for TSM RADIO SYSTEM RULES problem before operating adjustments.
  • Page 16 TRAXXAS TQ RADIO & VELINEON POWER SYSTEM USING THE RADIO SYSTEM 4. Operate the controls on the transmitter once again to be sure The TQi Radio System has been pre-adjusted at the factory. The that the model responds correctly. To turn the model off, unplug adjustment should be checked before running the model in case of 5.
  • Page 17 Recommended setting The recommended (default) SELF RIGHTING setting for TSM is to rotate the Your model is equipped with Traxxas Self Righting that will allow you to knob to the 12:00 position (the automatically return it to an upright zero mark on the dial).

  • Page 18: Adjusting The Electronic Speed Control

    4. When the LED blinks RED ONCE, pull the throttle status LED is green, indicating that Low Voltage Detection is activated to Traxxas High-Current trigger to the full throttle position and hold it there prevent over-discharging of LiPo batteries. LiPo batteries are intended only Connector (B).
  • Page 19 Contact Traxxas Customer Service. error accessories, such as LED light kits or additional cooling fans (see Traxxas.com for additional information). Always be sure to keep the panel cover installed when accessories are not being used to protect the pins from damage.
  • Page 20 • Voltage LED (V) Slow Blinking Red: The VXL-8s has functioning or programming error. Disconnect the entered Low Voltage Protection, Stage 2. When the batteries and contact Traxxas Customer Service for battery voltage attempts to fall below the minimum assistance.

  • Page 21: Driving Your Model

    DRIVING YOUR MODEL Now it’s time to have some fun! This section contains instructions on margin of space in all directions around the model in order to driving and making adjustments to your model. Before you go on, prevent collisions. here are some important precautions to keep in mind.
  • Page 22 After Running Your Vehicle in Wet Conditions • The Traxxas TQi transmitter is not water resistant. Do not subject it 1. Drain the tires by spinning the tires at high speed to “sling” the to wet conditions such as rain.
  • Page 23 4. Apply a small bead of silicone grease used for an extended period of time (such as a week or longer). (Traxxas part #1647) to the wire clamp. This additional maintenance is needed to prevent any trapped 5. Install the wire clamp and tighten the moisture from corroding internal steel components.

  • Page 24: Basic Tuning Adjustments

    BASIC TUNING ADJUSTMENTS Once you become familiar with driving your model, you might need Centering Your Servo Gearing Compatibility Chart: The chart below shows recommended to make adjustments for better driving performance. If you have removed the servo horn from your X-Maxx’s steering gear combination ranges for your model.
  • Page 25 BASIC TUNING ADJUSTMENTS Note: The new cartridge must be assembled on the shock shaft. DO Fine Tuning the Shocks NOT attempt to assemble the cartridge separately and slide it onto The four GTX shocks greatly influence handling. Periodic the shaft. This may damage the shaft O-ring and cause a leak. maintenance may be required to maintain optimal performance.

  • Page 26: Maintaining Your Model

    If the bottom of the shock is leaking, then it is time 4. Check the wiring for any frayed wires or loose connections. for a rebuild. The Traxxas rebuild kit for two shocks is part #7762. High performance vehicles 5.
  • Page 27 MAINTAINING YOUR MODEL Removing the front suspension module 4x25mm 1. Remove the two 3x20mm cap screws from the front of the chassis 4x14mm brace. 2. Remove the 3x15mm button-head cap screw from the steering link. 3. Remove the four 4x25mm button-head cap screws from the top of the chassis.

  • Page 28: Advanced Tuning Adjustments

    ADVANCED TUNING ADJUSTMENTS Roll Center Note: If you place the front X-Maxx has provisions for adjusting the roll center geometry of the links in the bottom position (not stock), then the pivot balls front and rear suspension. Roll center refers to the virtual axis around in the steering will need to be which the chassis will roll when subjected to cornering forces.
  • Page 29 Refer to the X-Maxx Front Assembly in the Service and Support Guide From the factory, the differentials are sealed to maintain consistent included with your model, or online at Traxxas.com/support for the long-term performance. Changing the oil in the differential with 4x20mm complete differential assembly.

  • Page 30: Tq Advanced Tuning Guide

    (set to The Multi-Function knob can be set to control Throttle Sensitivity. Starting Over: Traxxas Stability Management (TSM) by default, see page 17). Accessing Throttle Sensitivity works the same way as Steering Sensitivity, but Restoring Factory Defaults the programming menu is done by using the menu and set buttons on applies the effect to the throttle channel.
  • Page 31 This is especially handy if you operate multiple vehicles equipped with a built-in failsafe This allows you to fine-tune the servo settings to prevent binding with a single transmitter via Traxxas Link Model Memory. ™ function that returns the throttle...
  • Page 32 Model Lock 7. Press SET. The LED will blink rapidly green. The memory is now locked. The Traxxas Link Model Memory feature can store up to thirty models Press and hold MENU to return to driving mode. (receivers) in its memory. If you bind a thirty-first receiver, Traxxas Link Note: To unlock a memory, press SET twice at step 5.
  • Page 33 Transmitter is restored to default Press C onfirm Deletion Delete Model Two Blinks Green One Blink Red *Torque Control is a feature designed only for use with the power system in the Traxxas Funny Car Race Replica (Model #6907).
  • Page 34 ADVANCED TUNING GUIDE MENU TREE FORMULAS Set Multi-Function knob for STEERING Press/hold MENU Press SET Press SET to confirm Press/hold MENU SENSITIVITY (Expo) To select functions and make adjustments to the TQi transmitter without green LED blinks red LED blinks green LED blinks (x8) returns to driving mode referencing the Menu Tree, turn your transmitter on, find the function in the...
  • Page 35 Traxxas Link Real-Time Telemetry For more information The powerful Traxxas Link app (available in the Apple App Store℠ or on about the Traxxas Link When you equip your model Google Play™) gives you complete control over the operation and tuning...
  • Page 36 ’ 6250 TRAXXAS WAY, McKINNEY, TEXAS 75070 1-888-TRAXXAS 240313 77096-4-OM-EN-R00...
