PRO-UNI33 Bracket
(1)
1.
Make sure the Pro Enclosure cable is plugged
into the tablet and routed through the back of the Pro
Enclosure.
PRO-UNI33
REV A
PARTS INCLUDED
B
#10-32 x 1/4" Pan Head Screws
(2)
ASSEMBLY
ASSEMBLY INSTRUCTIONS
Double Sided Adhesive Pads
2.
Route the card reader charging cable (purchased
separately) through the back of the Pro Enclosure.
C
(2)
