STANDBY/ON switch ................................. 15
w
MASTER VOLUME control ........................ 15
e
DEMO button ............................................. 15
r
RECORD button ................. 17, 25, 78, 92, 96
t
DIRECT ACCESS button ..................... 21, 24
y
DSP button ................................................. 49
u
FAST/SLOW button ................................... 49
i
TOUCH button ......................................... 120
o
SUSTAIN button ......................................... 30
!0
HARMONY/ECHO button .......................... 50
!1
BACK button, NEXT button ........................ 17
!2
LCD display ................................................ 16
!3
VOICE CHANGE button ............................. 75
MIXER button ............................................. 76
!4
TRACK 1 - 16 buttons .......................... 37, 70
!5
FUNCTION button ........................ 17, 77, 118
A5 B5 C6
93 94 95 96
!6
SONG button .................................. 17, 25, 68
!7
STYLE button ................................. 17, 25, 32
!8
VOICE L button .......................................... 28
!9
VOICE R1 button ....................................... 27
@0
VOICE R2 button ....................................... 27
@1
ACMP ON/OFF button ......................... 25, 33
@2
FINGERING button .................................... 38
$5
PHONES/OUTPUT jack ............................. 13
$6
FOOT SWITCH jack ................................... 13
$7
TO HOST connector ................................ 107
$8
HOST SELECT switch ............................. 110
$9
MIDI IN/OUT connectors .......................... 107
%0
DC IN 10-12V jack ..................................... 12

Top Panel Controls

Rear Panel Controls

Panel Controls and Terminals
@3
TEMPO/TAP button .................................... 36
@4
TRANSPOSE button .................................. 30
@5
ACMP/SONG VOLUME button ............ 37, 70
@6
PART ON/OFF
VOICE L button ..................................... 28
VOICE R1 button .................................. 27
VOICE R2 button .................................. 27
@7
Number buttons
[1]-[0], [-/NO], [+/YES] ........................... 20
@8
EXIT button ................................................ 17
@9
Data dial ..................................................... 20
#0
DISK LOAD button ............................... 17, 62
#1
DISK SAVE button ............................... 17, 60
#2
DISK UTILITY button ..................... 17, 64, 67
#3
SYNC STOP button ................................... 41
#4
SYNC START button .................................. 33
#5
START/STOP button ............................ 32, 69
#6
INTRO button ............................................. 34
#7
MAIN/AUTO FILL A button ......................... 34
#8
MAIN/AUTO FILL B button ......................... 34
#9
ENDING/rit. button ..................................... 34
$0
REGISTRATION MEMORY buttons ........... 54
$1
ONE TOUCH SETTING buttons ................ 42
$2
MULTI PAD buttons .................................... 43
$3
Disk Drive ................................................... 58
$4
PITCH BEND wheel ................................... 30
