In addition, certain controller modules provide SNMP management and the ability to record events in a file including date and time information for further analysis. The HLI3001C01 is a TL3000 terminal line module and can be housed in a three rack unit...
• Module control and supervision can be done remotely when the mounting frame is equipped with a communications controller module. • One UR3000 mounting frame can house up to 12 HLI3001C01 modules. If power supply redundancy is required and FA3000 or FA3001 modules are used then only 10 modules can be housed in the mounting frame.
Albalá Ingenieros | Manual HLI3001C01 2. SPECIFICATIONS SD/HD/3G-SDI digital video signal input Connector Impedance 75 Ω ± 1 % Return loss: Up to 3 GHz >10 dB Up to 1.5 GHz >15 dB Input Return loss when bypass is active: Up to 3 GHz >10 dB...
Page 10
Albalá Ingenieros | Manual HLI3001C01 Accepted formats 625i50, 525i59.94, 720p50, 720p59.94, 1080i50, 1080i59.94, 1080p25, 1080p29.97, 1080p50, 1080p59.94 Embedded audio format According to SMPTE 272M, SMPTE ST 299-1 standards Input to output delay: 270 Mbit/s 7.8 us aprox. 1.5 Gbit/s 1.7 us aprox.
ELECTROSTATIC DISCHARGE. Always use antistatic bags clearly identified with a high degree of shielding for storage and transportation. The HLI3001C01 module is composed of two parts: one main board and one rear board. Both parts must be installed in a UR3000 or UR3100 mounting frame following the instructions in the corresponding section of this chapter.
4 - Attach the rear board to the mounting frame with two M3 metric screws and tighten. 5 - Insert the board (main board of the HLI3001C01 module) into the front of the mounting frame. The edges of the card slide into two plastic guides inside the mounting frame.
Page 13
Albalá Ingenieros | Manual HLI3001C01 Details for installation of the module in 3 RU mounting frames Details for installation of the module in 1 RU mounting frames...
Albalá Ingenieros | Manual HLI3001C01 3.6. Interconnection The following figure shows the HLI3001C01 module rear board connector layout. Rear view of the HLI3001C01 The HLI3001C01 module provides an input (IN) and four outputs (OUT1-PGM(LOOP), OUT2-PGM, OUT1-PVW, OUT2-PVW) for 3G/HD/SD-SDI digital video. The connector marked OUT1-PGM (LOOP) corresponds to a signal output protected by a bypass relay that maintains the input signal during a loss of power or removal of the module.
All coaxial cable used must be Belden 1694A or similar. This type provides the greatest lengths because it is used to calculate the equalizers in the HLI3001C01. Cables carrying signal between the module and the devices should use single piece construction, avoiding spliced sections with double BNC female or barrel connectors.
Albalá Ingenieros | Manual HLI3001C01 specifications section. Never connect dangerous potentials to GPI inputs. 3.6.3. GPO connections The outputs GPO1-4 are used to indicate if logos 1-4 are being inserted into the program output. The outputs GPO5-8 are used to indicate if logos 1 to 4 are being inserted into the preview output.
Albalá Ingenieros | Manual HLI3001C01 4. OPERATION This section describes the significance of the front panel indicators of the HLI3001C01 module and their remote control and monitoring ability. 4.1. Front panel description The appearance of the front panel and the elements it contains are shown in the following illustration.
Page 18
Albalá Ingenieros | Manual HLI3001C01 In the STATUS box: VID. FAIL: Red. This LED lights up continuously when no signal is present at the input or when its format is unrecognized. It blinks when the input signal format is recognized but synchronization to it is not possible.
HLI3001C01 4.2. Functional description The HLI3001C01 allows the simultaneous insertion of up to four logos from a palette of 32 stored in non volatile FLASH memory. The HLI3001C01 has two logo insertion channels on the input signal, called program channel and preview channel. Logos selected in both channels and their positions in the image are the same at all times, but the inclusion of each logo on each channel can be enabled and disabled independently.
The possible configuration is: - 32 logos of up to 256 kB. The HLI3001C01 comes from the factory configured to operate with 32 logos of up to 256 KB each. This parameter only affects the memory occupied by the logos and does not affect the size of the image to be displayed, which is always a maximum of 1920x1080 pixels.
Albalá Ingenieros | Manual HLI3001C01 4.5. Module remote control and supervision The HLI3001C01 requires remote control for configuration. In order to perform remote configuration and supervision of the module an optional TL3000 family remote communications controller must be installed in the mounting frame.
- Preset definition and recall. 4.5.1. Details of the HLI3001C01 registers The HLI3001C01 module provides control and status registers that can be read and written by means of specific commands described in the communication control module user manuals.
Page 23
Albalá Ingenieros | Manual HLI3001C01 PGM_INS_LOGO_4 0x01 0x08 Allows inserting the logo in the program output (Logo 4) 0=No, 1=Yes PVW_INS_LOGO_1 0x01 0x10 Allows inserting the logo in the preview output (Logo 1) 0=No, 1=Yes PVW_INS_LOGO_2 0x01 0x20 Allows inserting the logo in the preview output (Logo 2)
Page 25
Albalá Ingenieros | Manual HLI3001C01 FADE_TOP_LOGO_1 0x00 0x0264 0xFF Fade max value logo 1 (Logo 1) FADE_TOP_LOGO_2 0x00 0x0265 0xFF Fade max value logo 2 (Logo 2) FADE_TOP_LOGO_3 0x00 0x0266 0xFF Fade max value logo 3 (Logo 3) FADE_TOP_LOGO_4 0x00...
Albalá Ingenieros | Manual HLI3001C01 5. GLOSSARY 3G/HD/SD-SDI 3G/HD/SD - Serial Digital Interface for high definition or standard definition digital television capable of transmitting bitrates of 2.970 Gbit/s, 2.967 Gbit/s, 1.485 Gbit/s, 1.483 Gbit/s and 270 Mbit/s. Ancillary Time Code. Ancillary data packet inserted into the digital video signal for transmission of VITC or LTC information.
Page 34
Albalá Ingenieros | Manual HLI3001C01 On Screen Display. A display of text or graphics overlayed on the actual television image being transmitted. Using the OSD information about the configuration and status of the OSD insertion module or about the signals passing through the module can be seen.
Albalá Ingenieros | Manual HLI3001C01 6. REGULATIONS SMPTE ST 259 (2008) SDTV Digital Signal/Data Serial Digital Interface. See also: ITU-R BT.656-5 SMPTE 272M (2004) Formatting AES/EBU Audio and Auxiliary Data into Digital Video Ancillary Data Space. SMPTE ST 292-1 (2011) 1.5 Gb/s Signal/Data Serial Interface.
