Dishwasher / User Manual
DA238FW7RS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA238FW7RS and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo DA238FW7RS

Summary of Contents for Daewoo DA238FW7RS

  • Page 1 Dishwasher / User Manual DA238FW7RS...
  • Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1 SAFETY INSTRUCTIONS ................3 1.1 General Safety Warnings ....................3 1.2 Installation Warnings .....................4 1.3 During Usage........................5 2 INSTALLATION ....................8 2.1 Machine Positioning .......................8 2.2 Water Connection ......................8 2.3 Water Inlet Hose ......................8 2.4 Drain Hose (Model Depending) ..................9 2.5 Electrical Connection .....................9 2.6 Fitting The Machine Undercounter ................10 3 TECHNICAL SPECIFICATIONS ..............

  • Page 4: Safety Instructions

    1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.

  • Page 5: Installation Warnings

    There may be some residue left in the machine after washing. Keep children away from the machine when it is open. 1.2 Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine.

  • Page 6: During Usage

    Always use the coated plug supplied with your machine. If the electrical cable is damaged, it should only be replaced by a qualified electrician. • Connect the hose directly to the water inlet tap. The pressure supplied by the tap should be a minimum of 0.03 MPa and a maximum of 1 MPa.
  • Page 7 Do not open the door while the machine is in operation, hot water may spill out. Safety devices ensure the machine stops if the door is opened. The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position.
  • Page 8 Pull the plug to disconnect the machine from the mains, never pull on the cord. EN - 7...

  • Page 9: Installation

    2 INSTALLATION 2.3 Water Inlet Hose 2.1 Machine Positioning When positioning the machine, place it in an area where dishes can be easily loaded and unloaded. Do not put the machine in an area where the ambient temperature falls below 0°C. Read all warnings located on the packaging before removing the packaging and positioning the machine.

  • Page 10: Drain Hose (Model Depending)

    2.4 Drain Hose (Model Depending) 2.5 Electrical Connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. Connect the product to a grounded outlet protected by a fuse complying with the values in the...

  • Page 11: Fitting The Machine Undercounter

    2.6 Fitting The Machine Undercounter If you wish to fit your machine undercounter, there must be sufficient space to do so and the wiring-plumbing must be suitable to do so (1). If the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration (2).

  • Page 12: Technical Specifications

    3 TECHNICAL SPECIFICATIONS 3.2 Technical Specifications 15 place Capacity settings Dimensions Height 850(mm) Width 598(mm) Depth 598(mm) Net weight 47 kg Operating 220-240V voltage / 50 Hz frequency Total current 10(A) Total power 1900(W) Maximum: Water supply 1 (Mpa) pressure Minimum: 0.03 (Mpa) 3.1 General Sppearance...
  • Page 13 RECYCLING • Some machine components and packaging consist of recyclable materials. • Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. ) • The cardboard parts consist of recycled paper. They can be put into waste paper containers for recycling. •...

  • Page 14: Before Using The Appliance

    4 BEFORE USING THE 4.3 Fill The Salt (IF AVAILABLE) APPLIANCE To add softener salt, open the salt compartment cap by turning it counter 4.1 Preparing Your Dishwasher For First clockwise. (1) (2) At first use, fill the compartment with 1 kg salt and water (3) until it is almost overflowing.

  • Page 15: Test Strip

    4.4 Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) second munite munite NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.

  • Page 16: Detergent Usage

    4.8 Detergent Usage 4.10 Using Combined Detergents Only use detergents specifically designed These products should be used according for domestic dishwashers. Keep your to the manufacturer’s instructions. detergents in cool, dry places out of reach Never put combined detergents into the of children.

  • Page 17: Filling The Rinse-Aid And Setting

    4.12 Filling The Rinse-aid And Setting Level Brightener Dose Indicator Rinse-aid not r1 is shown on the To fill the rinse aid compartment, open dispensed display. the rinse-aid compartment cap. Fill the 1 dose is r2 is shown on the compartment with rinse aid to the MAX dispensed display.

  • Page 18: Loading Your Dishwasher

    5 LOADING YOUR DISHWASHER 5.1 Recommendations Remove any coarse residue on dishes For best results, follow these loading before placing the dishes in the machine. guidelines. Start the machine with full load. Loading the household dishwasher up to the capacity indicated by the manufacturer will contribute to energy and water savings.
  • Page 19 Four Folding Racks Height Adjustment The folding racks are designed so that The upper basket includes a mechanism large items, such as pots and pans, can which enables the height of the basket to be adjusted up (1) or down (2) without be easily placed in the dishwasher.
  • Page 20 Height Adjustable Rack (peg type) Upper Cutlery Basket The foldable racks in the upper basket The upper cutlery basket is designed for enable the placement of large items such the placement of large and small cutlery as pots and pans. Each section can be folded separately.

  • Page 21: Alternative Basket Loads

    5.2 Alternative Basket Loads Unsuitable Items For Dishwashing Lower Basket • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials. • Forks, spoons and knives with wooden, bone, ivory or nacrecoated handles; glued items, items soiled with abrasive, acidic or base chemicals. •...

  • Page 22: Programme Table

    EN - 21...
  • Page 23 • The program duration may change according to the amount of dishes, the water temperature, the ambient temperature and selected additional functions. • Values given for programmes other than the eco programme are indicative only. • Eco programme is suitable to clean normally soiled tableware, that for this use, it is the most efficient programme in terms of its combined energy and water consumption, and that it is used to assess compliance with the EU ecodesign legislation.

  • Page 24: The Control Panel

    7. CONTROL PANEL program by 1-2...24 hours before it starts. Time Delay Indicator (3.1) turns on. If you want to change (9) (8) (a) (b) (c) (d) (10) (15) (17) (11) (16) the delay time, press the Start/ Pause key and then press the Time Delay Key to select the new delay time.
  • Page 25 When the rinse aid level is low, the NOTE: If you have used one of rinse aid indicator will turn on. In the extra options in the last washing this case, you will need to fill the program, this option will be enabled rinse aid compartment.
  • Page 26 once on the Remaining Time Indicator (4). NOTE: To store a program as your favorite program, press Press the Start/Pause key for 3 seconds. Program (2) and Confirm (7) keys at the same time for 1 second. To End light will flash during the cancellation process.
  • Page 27 Option (6) and Confirm (7) keys thanks to the Ion Technology. It simultaneously for 3 seconds. works as an independent program. 2. When the sound setting is To enable this function, press detected, a long warning sound the Option key (6) for 3 seconds will be heard and the machine will in ready state.
  • Page 28 1. Launch the app Veezy on your Remote Access indicator (17) will smart device, sign up to create a turn on. new user account and then sign in. Remote control Wifi Connection Follow the on-screen instructions to indicator indicator select product type and display. 2.
  • Page 29 • When the wireless connection between your machine and your home network is cut off, the Wi- Fi Connection (16) and Remote Access (17) indicators will flash until connection is restored. When the home network is restored, the Wi-Fi connection will automatically be established on your machine.

  • Page 30: Cleaning And Maintenance

    8 CLEANING AND MAINTENANCE To remove and clean the filter combination, turn it counter clockwise and remove it by Cleaning your dishwasher is important to lifting it upwards (1).Pull the coarse filter out maintain the machine’s service life of the micro filter (2).Then pull and remove Make sure that the water softening setting the metal filter (3).Rinse the filter with lots of (If available) is done correctly and correct...

  • Page 31: Drain Pump

    8.3 Drain Pump Large food residues or foreign objects which were not captured by the filters may block the waste water pump. The rinsing water will then be above the filter. Warning Risk of cuts! When cleaning the waste water pump, ensure that you do not injure yourself on p ieces of broken glass or pointed implements.

  • Page 32: Troubleshooting

    9 TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 33 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
  • Page 34 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
  • Page 35 https://daewooelectronics.com/ https://daewooelectronics.com/service...
