Domestic Dishwasher SERVICE MANUAL Model DDW-G1213E Features A grade for energy consumption of European standard A grade for washing efficiency of European standard A grade for drying efficiency of European standard Electronic control, delay washing Water softener for descaling Super-capacity for 12 settings...
Dishwasher Edition: 2011-12 Model: DDW-G1213E 1. Features 1.1. A grade for energy consumption of European standard 1.2. A grade for washing efficiency of European standard 1.3. A grade for drying efficiency of European standard 1.4. Delay washing 1.5. Water softening function is provided which can prevent incrustation forming 1.6.
Dishwasher Edition: 2011-12 Model:DDW-G1213E 2. Safety precaution At time of delivery --Check packaging and dishwasher immediately for signs of transport damage. If the appliance is damaged, do not put it into use but contact your supplier or customer service without delay.
Page 5
Dishwasher Edition: 2011-12 Model: DDW-G1213E appliance could tip forward. --The water inside the dishwasher is not suitable for drinking. --Do not use solvents of any kind inside your dishwasher. They could cause an explosion danger. --Open the door very carefully if the dishwasher is operating. There is a risk of water squirting out.
Dishwasher Edition: 2011-12 Model: DDW-G1213E 3. Wash Cycle Table DDW-G1213E Cycle Selection Description Detergent Running Program Time(min) Energy(KW/h) Water(L) Information of Cycle Pre/main For the heaviest soiled loads, Pre-wash such as pots, pans, casserole Pre –wash Intensive dishes and dishes that have Wash (60 ℃)
Page 7
Dishwasher Edition: 2011-12 Model: DDW-G1213E DDW-G1213E Detergent Running Cycle Selection Description Energy(KW/h) Water(L) Program Pre/main Time(min) Information of Cycle For the heaviest soiled loads, Pre-wash such as pots, pans, casserole Main wash (60 ℃) Intensive dishes and dishes that have...
Dishwasher Edition: 2011-12 Model: DDW-G1213E 4. How to keep your dishwasher in shape After Every Wash After every wash, turn off the water supply the appliance and leave the door slightly ajar so that moisture and odors are not trapped inside.
Dishwasher Edition: 2011-12 Model: DDW-G1213E supply and leave the door of the appliance slightly ajar. This will help the seals last longer and prevent odors from forming within the appliance. 5. Fault finding Resolving minor problems yourself Experience has shown that you can resolve most problems that rise during normal daily usage yourself, without having to call out a service engineer.
Page 10
Dishwasher Edition: 2011-12 Model:DDW-G1213E Fill Press “child lock” button The inlet valve work about 1 minute Dispenser Press “3 in 1” button The dispenser work 60 seconds Motor Auto The washing pump work about 5 seconds Heater Auto The water will be heated up 64℃...
Page 11
Dishwasher Edition: 2011-12 Model:DDW-G1213E --Blockage or kind in drainage hose. --Pump is jammed. --Filters are blocked. --The programme is still running. Wait for the programme to end ..during washing Unusual amount of foam is creased --Normal washing up liquid has been poured into the rinse-aid container.
Page 12
Dishwasher Edition: 2011-12 Model: DDW-G1213E Plastic items are discoloured --Not enough detergent was added to dispenser. --Detergent has insuffcient bleaching properties. Use a detergent containing a chemical bleaching agent. White stains are left on crockery, glasses have a milky appearance --Not enough detergent was added to dispenser compartment.
Dishwasher Edition: 2011-12 Model: DDW-G1213E Amount of rinse-aid set too high. 6 Maintenances Services and Trouble Shooting 6.1 maintenances services With the aid of the following guide, minor problems can be easily corrected without calling for the assistance, saving you both time and money.
Page 14
Dishwasher Edition: 2011-12 Model:DDW-G1213E Use only the special dishwasher detergent to avoid suds. If this occurs, open the dishwasher and let suds evaporate. Improper detergent Add 1 gallon of cold water to the tub. Close and latch the Suds in dishwasher, then start the "soak"...
Page 15
Dishwasher Edition: 2011-12 Model:DDW-G1213E WARNING You have to wait for 20 minutes after a cycle to let the heating elements cool down before cleaning interior; otherwise, burns will surfaces happen. You have to call a water softener Iron deposits in water company for a special filter.
Page 16
Dishwasher Edition: 2011-12 Model: DDW-G1213E 6.2 Error Codes When some malfunctions happen, the appliance will display error codes to warn you. Codes Meanings Possible Causes The door is opened when the dishwasher is Door open operating Water inlet malfunction Water inlet...
Page 18
Dishwasher Edition: 2011-12 Model:DDW-G1213E 7.1Connector of PCBA...
Page 19
Dishwasher Edition: 2011-12 Model:DDW-G1213E 7.2 Dishwasher Strip Circuits The following individual circuits are for use in diagnoses. Do not continue with the diagnoses of the appliance if a fuse is blown, a circuit breaker is tripped, or if there is less than a 230 volt power supply at the wall outlet.
Page 20
Dishwasher Edition: 2011-12 Model: DDW-G1213E Fill and Over Flow power switch power switch PCBA CN2-1 CN3-1 inlet valve door switch Inlet relay Over Flow 30W max (Pin1 and Pin3 closes in 230V/50Hz normal position;Pin1 and Pin2 close when 3.5-4.0K ohm...
Page 22
Dishwasher Edition: 2011-12 Model:DDW-G1213E Water drainage malfunction...
Page 23
Dishwasher Edition: 2011-12 Model: DDW-G1213E Temperature malfunction E4 Malfunction CN5-6 and CN5-5 short or open circuit? Temperature short or open circuit? Replace control wire Replace TS Power on E4 ? Replace PCB Maintenance record...
Page 24
Dishwasher Edition: 2011-12 Model: DDW-G1213E Overflow Malfunction E5 Malfunction CN3-1 and CN3-2 Tilt the dishwasher short circuit? backward for 10° Leakage? Overflow floater be locked Replace the overflow switch Replace the leakage Reassemble the component overflow floater Power on Power on...
Page 25
Dishwasher Edition: 2011-12 Model: DDW-G1213E Water leakage malfunction...
Page 26
Dishwasher Edition: 2011-12 Model: DDW-G1213E Heating element malfunction CN1 short or open cuicrit? The heater ok? Replace heater The control wire Power on Replace PCB Maintenance record...
Page 27
Dishwasher Edition: 2011-12 Model: DDW-G1213E Warning Electrical Shock Hazard! Disconnect electrical power before installing dishwasher. Failure to do so can result in death or electrical shock. Specifications Electrical Supply: Lower Spray Arm Rotation:32 to42 rpm (Under load)50Hz,220-240VAC Supply Water Flow Rate: Upper Spray Arm Rotation:42 to 52 rpm To fill about 4.0L in 1 minute...
Dishwasher Edition: 2011-12 Model: DDW-G1213E 9. Net dimension Technical data Width 60 cm Depth 60 cm Height 85 cm Capacity 12 standard place settings Mains water pressure 0.04-1.0MPa Power voltage 220-240V~ 50Hz Total absorbed power 1850W Maximum current intensity...
