DAEWOO
Domestic Dishwasher
SERVICE MANUAL
Models
W60B3A401L-A
W60B4A401L-A
Page 1/ 25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W60B3A401L-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo W60B3A401L-A

Summary of Contents for Daewoo W60B3A401L-A

  • Page 1 DAEWOO Domestic Dishwasher SERVICE MANUAL Models W60B3A401L-A W60B4A401L-A Page 1/ 25...

  • Page 2: Table Of Contents

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Contents 1. FEATURES ......................3 2. SAFETY PRECAUTION ................. 4 3. WASH CYCLE TABLE ..................6 4. HOW TO KEEP YOUR DISHWASHER IN SHAPE ......7 5. FAULT FINDING ..................... 8 6. MAINTENANCES SERVICES AND TROUBLE SHOOTING ..12 7.

  • Page 3: Features

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A 1. Features 1.1 A++ grade for energy consumption of European standard 1.2 A grade for washing efficiency of European standard 1.3 A grade for drying efficiency of European standard 1.4 Electronic control, delay washing 1.5 Water softening function is provided which can prevent incrustation forming 1.6 Conceal heater and avoid heater turf burning.

  • Page 4: Safety Precaution

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A 2. Safety precaution At time of delivery --Check packaging and dishwasher immediately for signs of transport damage. If the appliance is damaged, do not put it into use but contact your supplier or customer service without delay.
  • Page 5 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A --Do not touch the heating element during or after a wash cycle. --Fundamental rules to follow when using the appliance: -- Never touch the dishwasher when barefoot or with wet hands or feet; --We discourage the use of extension cords and multiple sockets;...

  • Page 6: Wash Cycle Table

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Wash Cycle Table W60B3A401L-A、W60B4A401L-A Cycle Selection Description Detergent Running Time Water Program Energy(Kwh) Information of Cycle Pre/main (min) For the heaviest soiled Pre-wash loads, such as pots, pans, Main wash (60℃) casserole dishes and dishes...

  • Page 7: How To Keep Your Dishwasher In Shape

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A 4. How to keep your dishwasher in shape After Every Wash After every wash, turn off the water supply the appliance and leave the door slightly ajar so that moisture and odors are not trapped inside.

  • Page 8: Fault Finding

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A 5. Fault finding Resolving minor problems yourself Experience has shown that you can resolve most problems that rise during normal daily usage yourself, without having to call out a service engineer.Not only does this save costs,but it also means that the appliance is available for use again that much sooner.
  • Page 9 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A dishwasher has enough water. Softener Press “delay” button The softener work 90 seconds Drain Press” Programme” button The drain pump work about 1 minute The buzzer emits 1 signal and the display Press “delay” button...
  • Page 10 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A --Water supply has been interrupted. Knocking sound can be heared while washing is taking place A spray arm is knocking against the dishes inside the appliance. Rattling sound can be heared while washing is taking place Crockery has not been stacked properly inside the appliance.
  • Page 11 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A --Selected programme did not include drying function. --Amount of rinse-aid was set too low. --Items were removed from dishwasher too soon. Glasses have a dull appearance --Amount of rinse-aid was set too low. Tea stains or traces of lipstick have not been completely removed --Detergent does not have a sufficient bleaching effect.

  • Page 12: Maintenances Services And Trouble Shooting

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A 6. Maintenances Services and Trouble Shooting 6.1 maintenances services With the aid of the following guide, minor problems can be easily corrected Without calling for the assistance, saving you both time and money. Before Calling for Service Reviewing the charts on the following pages may make you be free of calling for service.
  • Page 13 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A To remove spots from glassware: Take out all metal utensils out of the Extremely hard water dishwasher. Low inlet Do not add detergent. temperature Choose the longest cycle. Overloading the Start the dishwasher and allow it to run for...
  • Page 14 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Be careful not to overfill the rinse aid dispenser. Overfill dispenser or rinse aid Spilled rinse aid could cause oversudsing and Dishwasher spills lead to overflowing. Wipe away any spills with a leaks damp cloth.

  • Page 15: Malfunction Diagnostic

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A 7. Malfunction Diagnostic Wiring Diagram Salt Rinse Diverter_switch Flow Meter Pressure switch Door Pressure switch Door Door Page 15 / 29...
  • Page 16 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A 7.1 Connector of PCBA Dishwasher Strip Circuits The following individual circuits are for use in diagnoses. Do not continue with the diagnoses of the appliance if a fuse is blown, a circuit breaker is tripped, or if there is less than a 230 volt power supply at the wall outlet.
  • Page 17 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Washing Motor CN3-1 PCBA 150 ℃ thermostat MOTOR CN1-1 door switch Motor relay 75-90W/230V/50Hz main winding 240±5 ohm auxiliary winding 116±5 ohm Heater Element PCBA 229 ℃ 98 ℃ Heater Heating element self-reset Heater relay...
  • Page 18 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Dispenser CN3-1 PCBA CN2-4 Dispenser door switch relay Dispenser valve 220-240V/50Hz softener Softener CN3-1 PCBA CN2-3 Softener softener valve door switch relay Diversion water system water diversion system CN3-1 PCBA CN2-5 diverter motor diverter motor relay...

  • Page 19: Trouble Shooting Guide

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Trouble shooting guide Water inlet malfunction E2 Malfunction tap is open? Replace Pressure Pressure switch is switch CN3-3 short Power on and open circuit? Flower Replace meter is Flower meter CN4-1 and Replace CN4-3 short or...
  • Page 20 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Water drainage malfunction Power on The drain pipe is blocked? Replace control CN3-10 wire drain pump short or open circuit? Replace The drain drain pump is pump Replace pressure pressure switch is Power on switch...
  • Page 21 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Temperature malfunction Page 21 / 29...
  • Page 22 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Overflow Malfunction Water leakage malfunction Page 22 / 29...
  • Page 23 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Page 23 / 29...
  • Page 24 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Heating element malfunction CN1 short or open cuicrit ? Replace The heater heater control wire is Power on Replace PCB Maintenance record Page 24 / 29...
  • Page 25 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Water diversion system malfunction Replace diverter motor motor is ok? The control wire is OK? Replace control wire Power on Replace PCB Maintenance record Page 25 / 29...
  • Page 26 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A Specifications Electrical Supply: Lower Spray Arm Rotation:25±5 rpm (Under load) 50Hz,220-240VAC Supply Water Flow Rate: Upper Spray Arm Rotation: 22±5 rpm To fill about 4.0L in 1 minute Page 26 / 29...

  • Page 27: Net Dimension

    Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A 9. Net dimension W60B3A401L-A Technical data Width 60.0cm Depth 60.0cm Height 84.5cm Capacity 12/14 standard place settings Mains water pressure 0.04-1.0MPa Power voltage 220-240V~ 50Hz Total absorbed power 1850W Maximum current intensity Page 27 / 29...
  • Page 28 Dishwasher Edition: 2013-11 Model: W60B3A401L-A、W60B4A401L-A W60B4A401L-A Technical data Width 59.6cm Depth 57.8cm Height 81.5cm Capacity 12/14 standard place settings Mains water pressure 0.04-1.0MPa Power voltage 220-240V~ 50Hz Total absorbed power 1850W Maximum current intensity Page 28 / 29...
