LED BOLLARD LIGHT INSTRUCTION MANUAL
SKU
LEDBOLL1000051601 - LG-SBLD-HS-14/19/24-CCT
IMPORTANT: Read all instructions prior to installation!
Keep instructions for future reference!
IMPORTANT SAFETY & NOTES WARNING
• Before installing, servicing, or performing routine maintenance upon this equipment,
follow these general precautions.
• To reduce the risk of death, personal injury or property damage from fire, electric
shock, falling parts, cuts/abrasions, and other hazards read all warnings and
instructions included with and on the fixture box and all fixture labels.
• Product should be installed by a certified electrician in accordance with applicable
national, state, and local building and electrical codes.
• Failure to properly support the fixture may result in damage or injury, for which the
manufacturer does not assume responsibility.
• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal
or other sharp objects.
• Do not make or alter any open holes in an enclosure of wiring or electrical
components during installation.
WARNING
• Turn off electrical power at fuse or circuit breaker box before wiring fixture to the
power supply!
• Turn off the power when you perform any maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label
information.
LumeGen | 1000 Westinghouse Drive STE 1, New Stanton PA 15672 | 800-998-6977 | Lightup.com |Page | 1
Specifications and dimensions subject to change without notice.
Project:
Date of Purchase
Included Parts List:
•
(1) Anchor Bolt Carrier
•
(16) M10*8 Nut
•
(4) M10 Spring Washer
•
(8) M10 Flat Washer
(4) Anchor Bolt
•
•
(1) Hex Wrench
