DESIGN, INSTALLATION, OPERATION AND

MAINTENANCE MANUAL

DuraQuench

DELUGE SYSTEM FOR THE PROTECTION OF MACHINERY AND

COMBUSTION TURBINES IN ENCLOSURES

P/N 06‐791‐1

Rev. 3

™

SOLUTIONS



Fire Protection



Explosion Protection



Overpressure Protection



Pressure Activation

Table of Contents

Need help?

Do you have a question about the DuraQuench and is the answer not in the manual?

Questions and answers

Summary of Contents for Fike DuraQuench

Page 1 DESIGN, INSTALLATION, OPERATION AND MAINTENANCE MANUAL ™ DuraQuench DELUGE SYSTEM FOR THE PROTECTION OF MACHINERY AND COMBUSTION TURBINES IN ENCLOSURES P/N 06‐791‐1 Rev. 3 SOLUTIONS  Fire Protection  Explosion Protection  Overpressure Protection  Pressure Activation ...
Page 2 You should install and use the Fike products described in this document within the range specified by Fike, especially with respect to the product application, maximum ratings, operating supply voltage range, installation and other product characteristics. Fike shall have no liability for malfunctions or damages arising out of the use of Fike products beyond such specified ranges. You should install and use the Fike products described in this document in compliance with all applicable laws, standards, and regulations. Fike assumes no liability for damages or losses occurring as a result of your noncompliance with applicable laws and regulations. It is the responsibility of the buyer or distributor of Fike products, who distributes, disposes of, or otherwise places the product with a third party, to notify such third party in advance of the contents and conditions set forth in this document. ...
Page 3 OTOR EPLACING THE OTOR LECTRICAL ESTS IAGNOSING C.11 ‐P PECIFIC ROBLEMS AND ORKSHEET FOR HREE HASE OTORS HIS INFORMATION IS . AVAILABLE FOR DOWNLOAD FROM THE RUNDFOS WEBSITE AND IS NOT CONTROLLED BY 29. A D. DDED RUNDFOS PUMP PERFORMANCE CURVES TO NNEX P/N 06‐791‐1 (Rev. 3) Page I 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 4: Table Of Contents
Containment ............................ 3 6 3.9. Pump Room .............................. 3 6 3.10. Water Supply .............................. 3 7 Water Supply Source .......................... 3 7 Water Quality ............................ 3 7 Water Supply Capacity .......................... 3 8 3.11. Design Process .............................. 3 8 Determine Application .......................... 3 8 Page II P/N 06‐791‐1 (Rev. 3)) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 5 4.6. Signage ................................ 57 5. SYSTEM ACCEPTANCE AND COMMISSIONING ...................... 58 5.1. Commissioning Requirements ........................ 58 6. OPERATION ................................ 59 6.1. Electric Automatic or Manual ......................... 59 6.2. C‐EL Valve Manual Release Lever ........................ 59 7. INSPECTION AND TESTING ............................ 60 7.1. Frequency ................................ 60 8. REFURBISHING AFTER SYSTEM ACTIVATION ...................... 60 9. SYSTEM RESTORATION AFTER OPERATION ...................... 61 ANNEX A – AUTOMATIC LOW FLOW BYPASS VALVE ADJUSTMENTS ................ 63 ANNEX B – BASKET STRAINER CLEANING PROCEDURE .................... 64 ANNEX C – NOZZLE STRAINER CLEANING PROCEDURE .................... 65 ANNEX D – PUMP INFORMATION............................. 66 P/N 06‐791‐1 (Rev. 3) Page III 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 6 Page No. Figure 1: Typical DuraQuench Deluge Water Mist System Diagram ................... 2 Figure 2: K6 Deluge Nozzle .............................. 7 Figure 3: K6 Deluge Nozzle Dimensions .......................... 8 Figure 4: K6 Nozzle Spray Pattern ............................ 8 Figure 5: DuraQuench Pump Skid ............................ 9 Figure 6: Typical Pump Skid Configuration .......................... 9 Figure 7: C‐EL Deluge Control Valve .......................... 1 6 Figure 8: Deluge Valve Dimensions ........................... 1 8 Figure 9: Check Valve ................................ 1 9 Figure 10: Check Valve Dimensions ........................... 2 0 ...
Page 7: Introduction
INTRODUCTION 1.1. General DuraQuench is an FM Approved, single‐fluid water mist system, that when configured for Deluge System operation provides active fire protection for large machinery spaces and turbine enclosures. The primary components of the DuraQuench Deluge system are a fire pump skid, patented K6 fine water spray nozzles, ancillary components such as deluge control valves, backflow preventers, isolation valves, and a reliable water source (i.e., public mains, gravity tanks or other suitable water sources). These components are connected together as a system to deliver water mist to the protected enclosure to control, suppress, or extinguish fires. With a minimum operating pressure of 112 psi (8 bar) and a maximum operating pressure of 232 psi (16 bar) at the system nozzles, the system is classified by NFPA 750, Standard ...
Page 8: Figure 1: Typical Duraquench Deluge Water Mist System Diagram
Figure 1 below shows the typical components that make up a DuraQuench deluge system. Figure 1: Typical DuraQuench Deluge Water Mist System Diagram 1. Suction isolation valve (monitored) 17. C‐EL deluge control valve (normally closed) 2. Suction flange 17a. Deluge valve solenoid* 3. Suction basket strainer 17b. Deluge valve manual release valve* 4. Suction pressure gauge 17c. Deluge valve inlet pressure gauge* 5. Circulation relief valve (opens at 275 psi/19 bar) 17d. Deluge valve outlet pressure gauge* 6. Centrifugal pump and motor 18. Pressure switch (monitored) 7. Test header isolation valve (monitored) 19. Drain/flow test isolation valve (monitored) 8. Test header flange 20. Riser stop valve (valve service, monitored) 9. Pressure relief valve (opens at 245 psi/16.9 bar) 21. K6 nozzles (open head) 10. Fire pump controller 22. Remote test/flush valve (monitored) 11. Pump controller to motor electrical connection 23. Releasing control panel 12. Discharge pressure gauge ...
Page 9: Water Mist Principle
As the water spray is converted to steam, it expands approximately 1,700 times forcing oxygen away from the vicinity of the droplet. This results in dilution of the air (oxygen) supply within the protected enclosure. If the amount of oxygen necessary to support combustion is reduced below a critical level (13% – 14%), the energy output of the oxidation process falls below the level of energy input the fire requires to sustain the chemical fire process, which causes the fire to burn inefficiently making it easier to extinguish. Blocking of Radiant Heat As water mist is released into the protected enclosure, the fine water droplets block the radiant heat generated by the fire from getting to unignited fuel surfaces and reduce the radiant heat flux between the flame and the fuel surface. P/N 06‐791‐1 (Rev. 3) Page 3 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 10: Enclosure Effects
(integrity) Enclosures shall be fairly air‐tight. Higher O2% = reduced fire‐fighting effect. Ventilation Ventilation shall be turned off prior to system activation. High heat output (larger fire) = more combustion gases and steam = Heat Output improved fire‐fighting effect. Low ignition temperatures = higher cooling effect on fuels = improved Fire Characteristics Fuel Types fire‐fighting effect. Low shielding = more water evaporation = more steam and cooling = Shielding improved fire‐fighting effect. Higher High = more steam = less condensation = improved fire‐fighting effect. Ambient Temperatures Low Low = less steam = more condensation = decreased fire‐fighting effect. Conclusions: Large Enclosures, Small Fires and Ventilation  Larger Enclosures = More Air and Oxygen = Slower Smothering of Fire  Small Fires = Less Heat Energy = Less Steam and Combustion Gases = Slower Smothering of Fire  Ventilation = More Oxygen = Harder to Dilute Oxygen Concentration = Slow or Non‐smothering of fire Small Enclosures and Large Fires  Small Enclosures = Less Air and Oxygen to Dilute = Faster Smothering of Fire  Large Fires = More Heat Energy = More Steam and Combustion Gases = Faster Smothering of Fire Page 4 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 11: Water Mist Versus Traditional Sprinkler System
1.5. Water Mist Versus Traditional Sprinkler System Water mist has several advantages over conventional sprinkler systems. One of the key benefits of the DuraQuench system is that it typically uses 75% less water than a sprinkler system. With a water mist system, the majority of the water droplets are evaporated by the heat and hot gases generated by the fire resulting in much less water damage to the protected property and a dramatic reduction in down time for cleanup. In industrial applications, the reduced down time means that the facility will be able to resume normal operations very quickly after a fire event. In contrast, traditional sprinkler systems spread large water droplets over the protected enclosure to absorb heat and cool the room. Due to the large size and relatively small surface area of sprinkler water droplets, they will not absorb enough energy to evaporate and quickly fall to the floor as water. This results in limited cooling of the fire and greater water damage to the protected property causing a large increase in facility down time due to the fire event. 1.6. Approvals The DuraQuench deluge water mist system is FM Approved to FM5560 appendix E and F for active fire protection of machinery enclosures and turbine enclosure with exposed or insulated turbines with the following limitations: Volumes of 0 ‐ 28,252 ft (800 m ) Enclosure height up to 26.25 ft. (8 m) max. Nozzle installation height up to 26.25 ft. (8 m) max. Volumes of 28,252 ft (800 m ) ‐ 162,801 ft (4610 m ) Enclosure height up to 39.37 ft. (12 m) max. Nozzle installation height up to 39.37 ft. (12 m) max. 1.7. Applicable Standards Fire protection consultants, system designers, system installers, fire authorities, system inspectors, system maintenance engineers, and users of the system should refer to the following standards and guidelines for additional information regarding the application of water mist systems.  NFPA 750, Standard on Water Mist Protection Systems  NFPA 20, Standard for the Installation of Stationary Pumps for Fire Protection  NFPA 25, Standard for the Inspection, Testing, and Maintenance of Water‐Based Fire Protection Systems ...
Page 12: Applications
1.9. Applications The DuraQuench water mist system has been tested and approved for total compartment protection of machinery enclosures containing Class B flammable liquid processes and incidental Class A combustible materials, and turbine enclosures. Applications include but are not limited to the following:   Internal combustion engines (excluding engine test cells) Lubrication skids ...
Page 13: Equipment
EQUIPMENT The DuraQuench deluge water mist system consists of a number of K6 nozzles connected by a piping network and a deluge control valve connected to a continuous pressure pump skid unit which is connected to a suitable water source (i.e., public mains, gravity tanks, reservoirs, etc.). This section provides a description of the components offered by Fike that can be used to construct the DuraQuench deluge water mist system. 2.1. Sourcing System Components The DuraQuench pump skid unit and the K6 nozzles are the only two components that must be purchased from Fike in order to maintain FM Approval. The remaining system components including deluge valve, detection and control panel, valves, piping, switches, etc. can be sourced from other suppliers. The operating pressure requirement of the DuraQuench system allows the use of traditional FM Approved sprinkler components and deluge system valves. Components selected for use on the DuraQuench system shall be FM Approved for use in deluge sprinkler systems. All system components should be a part of a FM Approval follow up service. It is very important to verify that the ...
Page 14: Figure 3: K6 Deluge Nozzle Dimensions
) Ceiling height (max.) 26.25 ft. (8 m) 39.37 ft. (12 m) 117.29 ft (10.89 m ) 96.83 ft (9 m ) Nozzle spacing (max.) 10.83 ft. x 10.83 ft. 9.83 ft. x 9.83 ft. (3.3 m x 3.3 m) (3 m x 3 m) Distance to wall (max.) 5.41 ft. (1.65 m) 4.93 ft. (1.5 m) 0.005 in/ft 0.006 in/ft Water density (1.4 mm/m ) (1.7 mm/m ) Dimensions Figure 3: K6 Deluge Nozzle Dimensions K6 Nozzle Spray Pattern Figure 4: K6 Nozzle Spray Pattern Page 8 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 15: Pump Skid
2.3. Pump Skid The pump skid unit is the primary control center for Fike’s DuraQuench water mist system providing the necessary flow and pressure to the system pipe network and spray nozzles. The compact skid unit is factory assembled, pre‐wired, pre‐piped and functionally tested prior to shipment from the factory which reduces the time and labor required for field installation. The skid unit is designed to meet the requirements of NFPA 750, Standard on Water Mist Fire Protection Systems, NFPA 20, Standard for the Installation of ...
Page 16 Pipe flange allows easy connection of system distribution piping. See System Connection Piping Connections for flange size. 9 Recirculation Loop Provides a path for continuous water flow through the pump when the pump is operating in churn (no flow) condition. 10 Relief Valve Allows the diversion of water through the recirculation loop to limit excess pressure in the system. 11 Test Header Isolation Allows the water supply from the fire pump to be routed to a connected test Valve (butterfly) header for the purpose of measuring the system flow rate during acceptance testing and during annual testing. 12 Test Header Pipe Pipe flange allows easy connection of test header piping to the pump skid. See Connection System Piping Connections for flange sizes. 13 Pump Controller Provides a means to start the fire pump automatically or manually in response to a fire event. Provides remote alarm connections for fire pump monitoring (VFD controller shown) (i.e., pump running, AC power failure, phase reversal, etc.). Controller can be activated via a normally closed remote contact from a releasing control panel (deluge system) or via a pressure sensing line connection (wet pipe system). 14 Motor Bracing Strap Provides bracing of pump motor. Page 10 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 17 Pump Skid Ordering Format The DuraQuench pump skid can be ordered with different pump controller and pump combinations. When ordering the pump skid, it is extremely important to verify the voltage and frequency (50/60 Hz) of the power feed supplying the pump skid before selecting the appropriate pump skid part number. The voltage and frequency of the pump controller and the pump selected must be compatible with the available power supply. The fire pump controller is available in the following configurations: 1) Standard single source pump controller provides across‐the‐line full voltage starting for the three phase motor driven pump. No transfer switch included. 2) Dual source pump controller incorporates a transfer switch directly into the standard pump controller enclosure. The transfer switch provides for automatic transferring of the pump load from one power source to another (self‐ acting). 3) Variable speed fire pump controller provides a variable frequency drive (VFD) built into the standard pump ...
Page 18 29 (460 V/ dual source) 1 (Standard) 2,6 02‐14909‐3‐1‐29‐2 3 (111 gpm/420 lpm) 1 (60 Hz) 29 (460 V/ dual source) 2 (Soft) 2,7 02‐14909‐4‐2‐2‐1 4 (75 gpm/284 lpm) 2 (50 Hz) 2 (208 V/single source) 1 (Standard) 1,4,6 02‐14909‐4‐2‐2‐2 4 (75 gpm/284 lpm) 2 (50 Hz) 2 (208 V/single source) 2 (Soft) 1,4,7 02‐14909‐4‐2‐6‐1 4 (75 gpm/284 lpm) 2 (50 Hz) 6 (380 V/single source) 1 (Standard) 1,6 02‐14909‐4‐2‐6‐2 4 (75 gpm/284 lpm) 2 (50 Hz) 6 (380 V/single source) 2 (Soft) 1,7 Page 12 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 19 2,4,6 02‐14909‐5‐2‐22‐2 5 (133 gpm/503 lpm) 2 (50 Hz) 22 (208 V/ dual source) 2 (Soft) 2,4,7 02‐14909‐5‐2‐27‐1 5 (133 gpm/503 lpm) 2 (50 Hz) 27 (400 V/ dual source) 1 (Standard) 2,6 02‐14909‐5‐2‐27‐2 5 (133 gpm/503 lpm) 2 (50 Hz) 27 (400 V/ dual source) 2 (Soft) 2,7 Notes: 1. Single power source controller. 2. Dual power source controller with integral automatic transfer switch. 3. Variable frequency drive controller. Transfer switch, if required, must be ordered separately. 4. Pump motor has been tested for operation at 208 V. 5. Jockey pump, if required, must be ordered separately on all skids using P/N 02‐15270. 6. Controller provides standard Across the Line motor starting. 7. Controller provides motor soft starter. P/N 06‐791‐1 (Rev. 3) Page 13 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 20 (25 bar / 120°C) (25 bar / 120°C) (25 bar / 90°C) (30 bar / 90°C) Maximum Inlet 100 psi 100 psi 100 psi 100 psi 100 psi Pressure*** (6.9 bar) (6.9 bar) (6.9 bar) (6.9 bar) (6.9 bar) Liquid Temp. ‐4 to +248 °F ‐4 to +248 °F ‐4 to +248 °F ‐4 to +248 °F ‐22 to +248 °F Range (‐20 to +120 °C) (‐20 to +120 °C) (‐20 to +120 °C) (‐20 to +120 °C) (‐30 to +120 °C) *Usable at 208 Volts. **The motor’s inrush current, also known as locked‐rotor amps or LRA, can be calculated by inserting the KVA/HP value into the following formula: LRA = KVA/HP x Motor HP x 1000 / 1.732 x Motor Voltage ***Current inlet pressure + churn (no flow) pressure must always be lower than the maximum permissible system operating pressure to prevent potential damage to the bearing in the motor or reduced life of the shaft seal. Page 14 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 21 (Standard and VFD) Approvals ANSI/UL 218 and FM 1321/1323 Fire Protection Standards Complies with NFPA 20, IEC62091 Voltage Rating See Pump Skid Ordering Format (‐15% and +10%) Short Circuit Current Rating 100,000 symmetrical RMS amps at 200 VAC to 480 VAC Horsepower Rating Specific name plated motor horsepower rating Motor Service Factor 1.15 maximum Voltage free contacts rated for 2 amps (resistive) at 30 VDC, or 1 amp Remote Contacts (resistive) at 125 VAC Pressure Rating 300 PSI (20.7 bar) standard Pressure Sensing Line ½” nominal, brass Enclosure NEMA Type 2 with drip lip 122° F (50° C) provided input and output cable has a temperature rating of 221°F (105°C) Ambient Operating Temperature 104° F (40° C) provided input and output cable has a temperature rating of 194°F (90°C) No direct sunlight allowed on the enclosure. Tested to comply with EN 61000‐6‐2 for immunity and EN 6100‐6‐4 for Electromagnetic Compatibility emissions P/N 06‐791‐1 (Rev. 3) Page 15 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 22: Deluge Control Valve (C
ANSI flange or threaded inlet and outlet connections and can Figure 7: C‐EL Deluge Control Valve be easily disassembled for maintenance and refurbishment, without removing the valve housing from the connected system. The valve trim provides two methods of system activation, which includes a manual release lever and electrical release through a 24 VDC impulse solenoid valve. The impulse solenoid valve is designed to hold the C‐EL valve in the open position once active. The valve will remain in the open position until a reverse polarity voltage is applied to the impulse solenoid allowing the C‐EL valve to close. Refer to Fike document P/N 06‐791‐3, Model C‐EL Valve manual for more information. Valve Sizes and Variations Sizes Part KV‐Value Flanged Flanged Number Inlet Outlet 119 g/min at 14.5 psi pressure loss 02‐14873‐3 DN 50 DN 50 ...
Page 23 Factory Tested 348 psi (24 bar) Materials Stainless Steel 316L Gasket Materials EPDM Valve Inlet Pressure Gauge Locations Primary Valve Outlet Manual Release Level Valve Trim Activation Options Electrical Solenoid (24 V DC NC/Impulse) Listing / Approvals FM Approved Spare Parts Part Number Description 02‐15258‐1 Valve Wrench 02‐15258‐2 Basic Valve Service Kit (2” and DN 50 C‐EL Valves) 02‐15258‐3 Full Valve Service Kit (2” and DN 50 C‐EL Valves) 02‐15258‐4 Basic Valve Service Kit (3” and DN 80 C‐EL Valves) 02‐15258‐5 Full Valve Service Kit (3” and DN 80 C‐EL Valves) 02‐15258‐6 Valve Core Kit (2” and DN 50 C‐EL Valves) 02‐15258‐7 Valve Core Kit (3” and DN 80 C‐EL Valves) P/N 06‐791‐1 (Rev. 3) Page 17 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 24: Figure 8: Deluge Valve Dimensions
18.54 in. (471 mm) 20.87 in. (530 mm) H1 5.39 in. (137 mm) 6.50 in. (165 mm) 6.58 in. (167 mm) 8.86 in. (225 mm) H2 9.88 in. (251 mm) 9.88 in. (251 mm) 12.68 in. (322 mm) 12.80 in. (325 mm) D1 8.35 in. (212 mm) 8.35 in. (212 mm) 9.84 in. (250 mm) 9.84 in. (250 mm) OD 6.50 in. (165 mm) 6.50 in. (165 mm) 7.87 in. (200 mm) 7.87 in. (200 mm) ØK 4.92 in. (125 mm) 4.92 in. (125 mm) 6.30 in. (160 mm) 6.30 in. (160 mm) ØA 4 x Ø0.70 in. (18 mm) 4 x Ø0.70 in. (18 mm) 8 x Ø0.70 in. (18 mm) 8 x Ø0.70 in. (18 mm) Page 18 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 25: Check Valve
2.5. Check Valve The ARGCO Check Valve is used in a DuraQuench system to prevent the reversal of water flow. In the fully‐open position the clapper is held tightly against the valve body, out of the flow stream, to provide maximum ﬂow area and prevention of clapper ﬂutter. Each valve is hydrostatically tested for leak tightness to 500 PSI. Specifications 02‐14915‐1 (2”) 02‐14915‐2 (2 1/2”) Part Number 02‐14915‐3 (3”) Working Pressure 300 psi (20.7 bar) ...
Page 26: Figure 10: Check Valve Dimensions
B 2‐1/8” (54.0 mm) 2‐1/16” (52.4 mm) 5‐5/8” (142.9 mm) C 1‐7/16” (36.5 mm) 1‐9/16” (39.7 mm) 2” (50.8 mm) D 1‐3/4”(44.5 mm) 1‐1/4” (31.8 mm) 1‐11/16” (42.9 mm) E 4‐1/2” (114.3 mm) 3‐11/16” (93.7 mm) 4‐1/4” (108.0 mm) F 3‐1/16” (77.8 mm) 3‐5/8” (92.1 mm) 3‐11/16” (93.7 mm) G 4‐5/8” (117.5 mm) 3‐1/2” (88.9 mm) 4‐11/16” (119.1 mm) F G C B D A E Figure 10: Check Valve Dimensions Page 20 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 27: Control Valves
2.6. Control Valves The butterfly control valves are used on the DuraQuench™ water mist system for the following functions: Suction (supply) Isolation Control Valve, Test Header Isolation Valve, Discharge Isolation Control Valve, Riser Inlet Isolation Valve and Riser Outlet Isolation Valve. These valves are designed to be installed in any orientation and monitored to signal if the valve is opened or closed. The valves are designed to open and close slowly to prevent water hammer. They are FM Approved for Fire Protection Use. Each valve is equipped with a tamper switch assembly suitable for indoor or outdoor use. The tamper switch features two switches. Switch 1 can be used for connection to a supervisory circuit of a listed fire alarm control panel. ...
Page 28: Figure 14: Fppi 2" & 2 1/2" Threaded Control Valve
2” & 2 1/2” Threaded Control Valve Valve “A” “B” “C” 2” Grooved 6.07” (154 mm) 4.65” (118 mm) 4.09” (104 mm) 2 1/2” Grooved 6.58” (167 mm) 4.65” (118 mm) 4.49” (114 mm) 2” Threaded 6.13” (156 mm) 4.65” (118 mm) 3.25” (83 mm) 2 1/2" Threaded 6.58” (167 mm) 4.65” (118 mm) 4.49” (114 mm) Figure 15: NIBCO 3” Wafer Style Control Valve Valve “A” “B” “C” 3” Wafer 14” (356 mm) 7.95” (202 mm) 1.81” (46 mm) Page 22 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 29: Backflow Preventer
33° ‐ 140°F (1° ‐ 60°C) IPS Groove for Steel Pipe AWWA C606 End Connections Flange Adapters ANSI B16.1 Class 124 38 lbs./17 kg (2 1/2”) Weight 40 lbs./18 kg (3”) Materials Valve Housing 304 Stainless Steel Valve Cover 304 Stainless Steel SOV Disks EPDM/304 Stainless Steel SOV Shafts 304 Stainless Steel SOV Bearings Teflon/Bronze Non Wetted Bolts Grade 8 Zinc Plated Wetted Fasteners 18‐8 Stainless Steel Check Disks Silicone (NSF) Check Springs 17‐7 Stainless Steel Check Pins 17‐7/18‐8 Stainless Steel Check Seats Noryl Polymer (NSF) O‐Rings Buna‐N (NSF) Listing / Approval FM Approved P/N 06‐791‐1 (Rev. 3) Page 23 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 30: Figure 17: Backflow Preventer Flow Performance Chart
Hb L Ec D H W Sc in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) NPT 2 1/2” (65) 7.1 (180) 2.9 (74) 18.7 (475) 2 1/2 (65) 0.0 (0) 10.0 (254) 11.0 (279) 1/2” 3” (80) 7.4 (188) 2.9 (74) 18.7 (475) 3 (80) 0.0 (0) 10.3 (262) 11.0 (279) 1/2” Page 24 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 31: Pressure Switch
2.8. Pressure Switch The Potter Pressure Actuated Switch is equipped with a ½” NPT male pressure connection that can be connected to the discharge side of the DuraQuench™ deluge valve or to the alarm port outlet of an approved deluge valve to provide waterflow detection in the system due to manual activation of the valve’s trim. The pressure switch will actuate when the alarm line pressure reaches 4 ‐ 8 PSI (0.27 – 0.55 BAR). The SPDT contacts within the switch can be used to signal a waterflow condition to a listed fire alarm control panel for activation of the DuraQuench pump skid and alarm notification. Specifications Figure 19: Pressure Switch Part Number 02‐15245 ...
Page 32: Waterflow Bell
6 24VDC 16 to 33VDC DC‐31.1mA / FWR‐53.5mA 82 20‐130‐156 8 24VDC 16 to 33VDC DC‐31.1mA / FWR‐53.5mA 80 20‐130‐157 10 24VDC 16 to 33VDC DC‐31.1mA / FWR‐53.5mA 81 20‐130‐158 6 120VAC 96 to 132VAC 53mA 85 20‐130‐159 8 120VAC 96 to 132VAC 53mA 82 20‐130‐160 10 120VAC 96 to 132VAC 53mA 82 Page 26 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 33: 2.10. Fire Department Connection
2 1/2” inlet. A fire department connection shall be provided on all water mist systems, except as outlined in NFPA 750. Specifications Figure 21: FDC 02‐14931 (FDC) Part Number 02‐15244 (Cap, ordered separately) Material Cast Brass Inlet – 2 1/2” (Qty. 2) Size Outlet – 4” Lettering AUTO. SPKR. Figure 22: FDC Cap Listing / Approval FM Approved Dimensions 5 1/4” 6 3/4” 10” Figure 23: FDC Dimensions P/N 06‐791‐1 (Rev. 3) Page 27 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 34: 2.11. Pressure Relief Valve
2.11. Pressure Relief Valve The AGF Manufacturing Inc. Pressure Relief Valve is used in a DuraQuench system to relieve excess system pressure caused by surges or temperature changes. This valve complies with NFPA‐13 which stipulates that a pressure relief valve be installed on all gridded systems and downstream of all pressure reducing valves. This valve has a bronze body, stainless steel spring, and flushing handle to remove debris. Specifications 02‐14932‐1 (1/2”) Part Number 02‐14932‐2 (3/4”) 185 psi (12.8 bar)(1/2”) Pressure Rating 250 psi (17.24 bar)(3/4”) Figure 24: Relief Valve ...
Page 35: 2.12. Identification Signs
DESCRIPTION PART NUMBER SIGN SIZE Drain Valve Sign 02‐15230 6” x 2” (152 x 51mm) Fire Alarm Sign 02‐15231 9” x 7” (229 x 178mm) Blank Sign 02‐15232 6” x 2” (152 x 51mm) Normally Open Sign 02‐15233 6” x 2” (152 x 51mm) Hydraulic System Sign 02‐15234 8 1/2” x 11” (216 x 279mm) Inspection Test Sign 02‐15235 6” x 2” (152 x 51mm) P/N 06‐791‐1 (Rev. 3) Page 29 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 36: 2.13. Test Connection
2.13. Test Connection The Test Connection is used to permit the flow of water from the pump skid assembly, to test the flow capacity and operation of the fire pump during initial acceptance and annual testing. The test connection provides a connection point for a fire hose that can be used to direct the water stream generated during the test to a safe discharge location. A Test Connection shall be provided on all water mist system, as outlined in NFPA 750. Specifications Part Number 02‐14942 Material Polished Brass Inlet 2‐1/2” female NPT Figure 27: Test Outlet Male hose thread snoot with cap and chain Connection Lettering 8” plate “HYDRANT” Listing / Approval FM Approved Dimensions 8” 1 7/8” Figure 28: Test Connection Dimensions Page 30 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 37: 2.14. Test Header Flow Meter
02‐15264 Carbon steel ASTM A53 / Carbon Steel Material Insert Valves ¼” MSAE Flare Brass Ball 1/8” FNPT CS Weld Fitting 150# Identification Tag Polycarbonate Maximum Temperature 250°F (120°C) Pressure 300 PSIG (21 bar) Pipe Size 2 ½” End Connection Grooved 6” (150 mm) Dial Size 270° Arc Standard Diaphragm Pressure Gauge ±1.75% Accuracy, Full Scale 180°F (80°C) Temperature Brass/Bronze Hoses Nylon Flow Rate 50 – 200 GPM (189 – 757 lpm) Dimensions 6” (152 mm) end to end Weight 3 lbs (1.4 kg) Listings / Approvals FM Approved P/N 06‐791‐1 (Rev. 3) Page 31 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 38: 2.15. Piping Network
L ASTM B‐75/B‐88 Welded, Brazed, Flared, Compression CAUTION: To prevent clogging of the system nozzles, it is prohibited to use components with black iron, hot galvanized or electro galvanized pipe and system components used in traditional sprinkler systems, because of corrosion and risk of loose zinc flakes. NOTE: From this point forward, where the word pipe is used it shall imply tubing as well. Fittings Fittings shall have a minimum rated system design working pressure equal to or greater than the maximum operating pressure of the water mist system at 130°F (54°C) and shall have corrosion resistance at least equivalent to wrought copper fittings conforming to ASME/ANSI B16.22, Wrought Copper and Alloy Solder Joint Pressure Fittings. Heat Resistance Fires in machinery and turbine enclosures may cause excessive heating of the pipe network inside the fire protected enclosure. Pipe, fittings, and joints should be resistant to heat and tensile stress caused from heating. Pipe materials shall be chosen and configured to not cause a risk of fire spreading between enclosures. Solder joints and copper alloy pipes should be avoided inside the fire protected enclosures. Galvanic Corrosion To avoid galvanic corrosion from occurring in the water mist system, all component materials incorporated into the system shall be compatible so no galvanic reaction can take place, or as a minimum be electrically insulated from the pipe materials to the satisfaction of FM Approval and the authorities having jurisdiction. Page 32 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 39: Design
DESIGN This section details the steps necessary to design a DuraQuench water mist system for deluge operation. It is the responsibility of the system designer to ensure that the DuraQuench water mist system is: 1. Fully designed in accordance with the design guidelines of this manual as well as the applicable guidelines and requirements of FM Global, NFPA 750, NFPA 13, and the requirements of the authorities having jurisdiction. 2. Fully documented to the satisfaction of FM Global and the authorities having jurisdiction (AHJ). Design shall be reviewed and accepted by the authorities having jurisdiction prior to the installation. 3. Applied using system components of good quality and reliable products, which are accepted and approved by FM Global and the AHJ, and that are suitable for their particular use in the system. See Section 2.1. 4. Designed to fully match the location and application to be fire protected. 5. Hydraulically designed from water supply to water mist nozzles. The hydraulic design shall ensure that ...
Page 40: Electrical Clearances
Electrical Code. Refer to NFPA 750, Standard on Water Mist Fire Protection Systems for further information and clearance data. 3.3. Deluge Control Valve Fike recommends using the C‐EL deluge control valve in conjunction with the DuraQuench system; however, any FM Approved deluge sprinkler control valve can be used as long as it complies with the following criteria: 1) Valve must be capable of handling the maximum working pressure created by the DuraQuench system 245 psi (16.9 bar). 2) Valve must be capable of handling the water flow requirements required by the DuraQuench system. 3) Valve must be constructed of corrosion resistant materials in order to minimize the risks of clogging the water mist nozzles. 4) Friction losses associated with the valve must be compatible with the performance criteria of the system. 5) Valve must be FM Approved and compatibility tested for use with the associated detection and releasing ...
Page 41: System Activation And Alarms
3.7. System Activation and Alarms The DuraQuench water mist system shall have FM Approved fire detection and releasing system installed in all areas served by the system. The detection and releasing system shall be suitable for the application and location to which it provides protection and shall be capable of providing verified detection and deluge valve activation. A verified detection system requires two detection devices in the same area of protection to be active in order to release the water mist system. An automatic alarm shall sound or indicate when each detection step detects a fire. The fire detection system shall be designed and installed in compliance with the following standards: 1) NFPA 72, National Fire Alarm and Signaling Code 2) NFPA 70, National Electrical Code 3) Factory Mutual Loss Prevention Data Sheet 5‐48, Automatic Fire Detection 4) Factory Mutual Loss Prevention Data Sheet 4‐2, Water Mist Systems Automatic activation of the DuraQuench deluge water mist system shall be accomplished via dry relay connection to the fire detection and releasing system, or by remote manual activation (where acceptable to the AHJ). The chosen type of system activation shall be designed and documented to the satisfaction of FM Global and the AHJ. The releasing panel shall match the system deluge valve requirements, shall be approved by FM, and be accepted by the AHJ. If an existing detection system is used in a new water mist system, the detection system shall be evaluated for compliance with the standards identified above and the requirements outlined in this document. Detector Requirements The detector requirements for each system will vary according to the specific hazard requirements. It is because of these variances that only general guidelines are discussed in this section. It is the responsibility of the system designer to determine the precise location and quantity of detectors required for each individual protected enclosure. Detector Selection: Due to the type of hazards that the deluge water mist system protects, Fike recommends that only heat detectors be used for automatic fire detection. Selecting the temperature rating of the detector is critical to the proper operation of the water mist system. When selecting which temperature rating to use, consideration shall be given to the normal temperatures incurred during system operation as well as ventilation inside the protected ...
Page 42: Protected Enclosure
A fire pump room or building shall be prepared for installation of the pump skid unit in accordance with the requirements of NFPA 20, Standard for the Installation of Stationary Pumps for Fire Protection and FM Property Loss Prevention Data Sheet 3‐7, Fire Protection Pumps. Site preparation shall be the responsibility of the buyer. The location of an access to the fire pump room shall be preplanned with the fire department and/or the AHJ. Planning shall include considerations for equipment access, heating, lighting, emergency lighting and ventilation. The pump room shall provide protection for both the pump operator and pumping equipment during a fire event. Consideration should be given to locating the pump room at grade level, with direct access to the exterior of the building, to provide quick and easy egress for the pump operator and access to the pumping equipment for fire department personnel. Where the pump room cannot be located on grade with direct access from the outside of the building, a fire rated and protected space must be provided. The space must be accessible through an enclosed passageway from an exterior exit from an enclosed stairway. Page 36 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 43: 3.10. Water Supply
3.10. Water Supply The water supply source for the DuraQuench system shall meet the requirements of NFPA 750, NFPA 13, and FM Global, with exceptions to the water density, water flows, and pipe system materials described in this manual. The water supply source shall comply with the overall design of water supply systems for deluge sprinkler systems for fire protection of similar locations. Water Supply Source The water supply shall be supplied by one of the following sources: 1. A connection to a reliable waterworks system (public service main) capable of providing the necessary water flow, water pressure, and quantity of water needed for the operation of the water mist system. Adequacy and dependability of the water source shall be fully determined from a water flow test or other approved method in accordance with NFPA 20, Standard for the Installation of Stationary Fire Pumps. Where the public service main is not capable of supplying water in the quantity, or pressure required to operate the water mist system, an alternate water supply source shall be provided. 2. A tank arranged in accordance with NFPA 750, Standard on Water Mist Fire Protection Systems; NFPA 22, Standard for Water Tanks for Private Fire Protection; and FM Property Loss Prevention Data Sheet 3‐2, Water Tanks for Fire Protection. No suction under lift is allowed. Tanks should furthermore be in accordance with the following: A. Be sealed and shielded from sunlight. B. Be install in a frost‐free area. ...
Page 44: Water Supply Capacity
The minimum Net Positive Suction Head Required (NPSHR) for the pumps used on the DuraQuench system can be obtained from the manufacturer’s pump curves. It is recommended that the NPSHR be selected at the highest flow the pump will be delivering plus a safety margin of 2.0 feet (0.61m). CAUTION: Do not exceed the manufacturer’s set limits for the pump with regards to maximum inlet pressure and ...
Page 45: Determine Enclosure Volume
Extrapolation beyond the values listed is not allowed. Machinery & Turbine Enclosures* Large Volume Small Volume Volume up to 162,801 ft (4610 m ) Volume up to 28,252 ft (800 m ) Enclosure height up to 39.4 ft. (12 m) Enclosure height up to 26.3 ft. (8 m) *Exposed and insulated turbines Determine Nozzle Layout The DuraQuench K6 deluge water mist nozzles shall be installed within the protected enclosure in a homogenous grid covering the whole area of the enclosure. Nozzles shall be installed in a pendent (downward) position located no greater than 1 ft. (0.3 m) below the ceiling. Spacing of the nozzles shall be in accordance with the requirements listed in the table below. Machinery & Turbine Enclosures* Large Volume Small Volume Nozzle installation height up to 39.4 ft. (12 m) max. Nozzle installation height up to 26.3 ft. (8 m) max. Max. nozzle spacing 9.84 ft. x 9.84 ft. (3m x 3m) Max. nozzle spacing 10.8 ft. x 10.8 ft. (3.3m x 3.3m) Max. nozzle distance to wall 5 ft. (1.5m) Max. nozzle distance to wall 5.4 ft. (1.65m) *Exposed and insulated turbines 3.11.3.1. Determine Nozzle Quantity ...
Page 46: 3.11.3.2. Determine Nozzle Spacing
40 ft. (12.2m) ÷ 4 nozzles = 10 ft. (3m) between nozzles B. Distance between nozzles (length) ÷ 2 = distance between nozzles and perimeter walls 10 ft. (3m) ÷ 2 = 5 ft. (1.5m) between nozzles and perimeter walls C. Enclosure Width ÷ 3 nozzles = spacing of nozzles required along the width dimension 25 ft. (7.62m) ÷3 nozzles = 8.33 ft. (2.54m) between nozzles D. Distance between nozzles (width) ÷ 2 = distance between nozzles and perimeter walls 8.33 ft. (2.54m) ÷ 2 = 4.2 ft. (1.3m) between nozzles and perimeter walls Verify that calculated nozzle spacing does not exceed the values identified in Section 3.11.3. 3.11.3.3. Nozzle Spacing for Turbine Enclosures with Turbines with Exposed Casings The fine water spray produced by the DuraQuench system may cause too much cooling to the casing surfaces on exposed turbines. The uneven temperatures in the casing materials from the cooling by the applied water mist may cause tensile cracks to occur in the casing of un‐insulated (exposed) turbines, in the case of water mist system being activated and distributing the water mist on hot turbine casing without thermal insulation. In order to overcome this potential problem, the radius of the protected turbine is limited to a maximum of 14’‐9” (4.5 m) and the K6 nozzles must be installed as shown in Figure 30 with regards to the spacing and location of the nozzles in direct relationship to the un‐insulated turbine. Figure 30: Nozzle Spacing for Exposed Turbine Casing ...
Page 47: 3.11.3.4. Nozzle Obstructions
3.11.3.4. Nozzle Obstructions NOTE: *Systems with nozzles installed as described in this section are not part of the DuraQuench system FM approval. Care should be given when placing the K6 nozzles adjacent to obstructions. A major obstruction is defined as any object that obstructs more than 30% of the water mist from one nozzle when observed from below the obstruction. See Figure 32. If the protected area contains one or more major obstructions, an additional nozzle should be installed adjacent to the obstruction(s). Depending on the elevation of the obstruction, additional K6 nozzles shall be installed below major obstructions (i.e., beams, walkways, ductwork, etc.) in order to provide a homogenous distribution of the water mist in the enclosure. Regardless of the distance between nozzles and obstructions, and distances from the obstructions and the application, additional water mist nozzles shall be installed below obstructions with a foot print area exceeding 3.3 ft. (1m) wide and 9.84 ft. (3m) long. This includes grated walkways. Areas in which combustible liquids and other such materials may accumulate shall be protected by additional K6 nozzles. Figures 31 and 32 below should be applied to calculate the shield factor of an obstruction. Figure 31 shows the typical water spray from one K6 nozzle. Figure 32 shows an example of an obstruction to the water spray from one K6 nozzle. K6 water spray distribution from a single nozzle for obstruction calculation. Bold blue line = Water spray. Pink Area = Calculation area for determining the shielding of the water spray. K6 Water Spray 7.5 bar (109 psi) Pendent Spray Figure 31: K6 nozzle water spray distribution from single nozzle for obstruction calculation. Example of obstruction to fine water spray from where obstruction is approximately 20%. No extra nozzles are required underneath obstruction object. K6 Water Spray 7.5 bar (109 psi) Pendent Spray Figure 32: Example of an obstruction to water spray from one K6 nozzle. P/N 06‐791‐1 (Rev. 3) Page 41 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 48: 3.11.3.5. Examples On How To Assess Nozzle Obstructions
Ft. (m) nozzles above from delivering a homogeneous Ft. (m) water spray distribution. Width < 1 ft. (0.3m), length > 0 Additional nozzles should only be located below Additional nozzles are obstructions, if water spray for surrounding 1 > 9 ft. (2.75m) >6.6 ft. (2m) not necessary nozzles are inhibited from getting in between the obstruction and the fire protected application. Additional horizontal Width < 1.3 ft. (0.4m), length > 0, installed K6 nozzles may be Additional nozzles should only be located below installed for enhanced fire Rack of multiple obstructions, if water spray for surrounding protection, in cases where 2 > 9 ft. (2.75m) cable trays, along the cables represent a fire nozzles are inhibited from getting in between a wall. risk, or where particular the obstruction and the fire protected cooling of cables is application. required. Page 42 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 49: Determine Nozzle Flow Rate
Ft. (m) Ft. (m) homogeneous water spray distribution. Width < 3.3 ft. (1m), Length < 3.3 ft. (1m) Additional nozzles should only be located below Additional nozzles are 1 obstructions, if water spray for surrounding > 9 ft. (2.75m) > 6.6 ft. (2m) not necessary nozzles are inhibited in getting in between the obstruction and the fire protected application. Determine Nozzle Flow Rate Use the following formula to calculate the flow rate from each K6 nozzle using the given K‐factor for the nozzle (0.387 gal/min/psi or 5.6 l/min/bar). The K‐factor is a constant that gives the ratio between the flow rate and the pressure at the nozzle. System pressure (P) at the nozzle will vary between 112 to 232 psi (7.7 – 16 bar). The most favorable condition shall be considered. Q = K * P Where: Q = Flow from the nozzle (gal/min or l/min.) K = Nozzle K factor (gal/min/psi or l/min/bar) P = Pressure at the nozzle (psi or bar) To estimate the total flow for the protected area, multiply the calculated nozzle flow rate by the total number of nozzles serving the protected area. = Q * N Where: = Total flow for the area (gal/min or l/min.) Q = Flow from the nozzle (gal/min or l/min) = Total number of nozzles P/N 06‐791‐1 (Rev. 3) Page 43 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 50: Determine Size Of Fire Pump Required
must be positive. 3. Determine friction head (pressure loss) through the pipe distribution system. The friction loss depends on the flow rate, the pipe size, the pipe length, and elevation changes in the system. Piping components, such as valves, fittings, backflow preventers, etc., must also be factored into the system friction loss calculations. Actual system friction loss shall be determined by hydraulic calculations. 4. Calculate the required total head for the pump. The required total head for the pump is the difference between NPSH from the connected water supply and the friction head loss of the pipe distribution system. 5. Select the pump. Select the pump based on the pump curve information provided in Annex D.4 and D.5, using the total head and flow determined in the previous steps. The selected pump must be adequate to meet both the flow and pressure demands for the system. NOTE: NFPA 750 requires that a fire pump(s) be selected to provide a minimum of 110% of the required system water flow and pressure; whereas, FM Property Loss Prevention Data Sheet 4‐2 requires that a fire pump be sized to provide 120% of the required system water flow rate, at the minimum system operating pressure. The following formula can be used to estimate the size and number of pumps required to serve the protected area based on the total water flow required. = Q / q PUMPS MAX Where: = Number of pumps PUMPS = Total flow for area (gal/min or l/min) + safety factor (10% NFPA or 20% FM) q = Flow rate output of selected pump unit NOTE: Using the formula above, in most cases, will result in the selection of a fire pump that is oversized for the application. Hydraulic calculations shall be performed in order to determine the actual required capacity of the fire pump. Page 44 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 51: Ambient Temperature And Altitude
Figure 33: Relationship between motor output (P ) and ambient temperature/altitude Example: From Figure 33 it appears that P2 must be reduced to 88% when a pump with NEMA premium efficiency ML motor is installed 15,584 feet above sea level. At an ambient temperature of 167°F, P2 of a standard efficiency motor must be reduced to 74% of rated output. In cases where both the maximum temperature and the maximum altitude are exceeded, the derating factors must be multiplied. Example: 0.89 x 0.89 = 0.79. Determine Distribution Piping Layout The piping system for the DuraQuench deluge water mist system shall be designed in accordance with the basic design principals used by traditional deluge sprinkler systems. The piping system must be sized to suit the application design in order to achieve the correct design parameters for both water flow and pressure drop. Hydraulic Calculations The hydraulic design shall ensure the presence of the necessary water flow, water pressure and quantity of water needed for the full system operation time. The pipe network shall be hydraulically pressure loss calculated using the formulas below. 1. System working pressure does not exceed 175 psi (12 bar) use Hazen‐Williams calculation method. 2. System working pressure exceeds 175 psi (12 bar) use Darcy‐Weisbach calculation method. P/N 06‐791‐1 (Rev. 3) ...
Page 52: Installation
INSTALLATION This section provides installation instructions for the major components that make up the DuraQuench deluge water mist system. Each subsection provides detailed instructions on how to install a specific component of the system. All installation steps shall be completed before the applicable component can be considered installed and operational. 4.1. Pump Skid Site Preparation The site shall be prepared for installation of the pump skid unit prior to receipt to minimize handling. Site preparation shall be the responsibility of the Buyer and shall consist of the following: A. Provide a suitable fire pump room constructed in accordance with NFPA 20 to house the pump skid unit. B. Floor shall be pitched for adequate drainage of water away from pump skid unit. C. Floor drain piping shall be installed to convey water discharge from the pump skid unit to a frost‐free location. D. A suitable foundation shall be provided for installation of the pump skid unit. Foundation shall be adequately sized to accommodate the skid and shall be level. See Figure 36 for pump skid dimensions. Power circuit(s) and final hookup shall be provided by the buyer for the pump skid unit. Inspection The DuraQuench pump skid and its components are to be inspected at time of delivery. If any item(s) show signs of shipping damage when received, this must be noted on the waybill when signing for acceptance of shipment and also whether or not the item(s) had been inspected for concealed damage. Buyer should notify the carrier immediately and make arrangements for an inspector of the carrier to be present during the unpacking of the item(s). Buyer should then notify Fike immediately. Item(s) should not be opened until the carrier’s inspector is present. If the items have been unpacked, the shipping container MUST be saved for inspection. Handling Removal and installation of the DuraQuench pump skid is the responsibility of the buyer and should be performed by experienced riggers accustomed to the handling of large packages. Lifting devices such as cranes, spreader bars, slings, and shackles required for removal and installation of the package are the responsibility of the buyer. Lifting rings and forklift slots are supplied with the unit. Care shall be taken to prevent damage to the pump skid during off loading and installation. CAUTION: Pump skids off loaded and stored prior to final placement MUST be leveled to prevent racking of the skid. Page 46 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 53: Mounting
Mounting The pump skid is constructed with the following features that enable it to be easily maneuvered to its final installation location and secured in place. 1. The skid is equipped with fork lift slots at each end of the skid to allow it to be easily lifted using a standard forklift with adjustable forks. See Figure 34. 2. Two lifting eyes are provided at each end of the skid to allow it to be lifted using lifting devices such as a crane or hoist. See Figure 34. 3. Optional rolling casters (P/N 02‐15334) can be ordered and mounted to the skid in the field to allow the unit to be rolled into its mounting location. See Figure 35. Figure 34: Pump Skid Lifting and Mounting Points Figure 35: Pump Skid with Casters Installed Pump skid unit shall be mounted and anchored to a suitable foundation (provided by others) using the four mounting holes provided on the pump skid. See Figure 34. Pump skid unit shall be leveled and piping connection locations verified prior to installation of the skid to ensure piping mates up with the pump flanges without strain. P/N 06‐791‐1 (Rev. 3) Page 47 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 54: Pump Skid Dimensions
14 71 70.00 02‐14909‐4 [208] [56] [76] [18] [218] [18] [36] [180] [177.80 86 22 30 7 90 7 14 71 82.71 02‐14909‐5 [218] [56] [76] [18] [229] [18] [36] [180] [210.10] *Dimensions are rough and will vary slightly due to manufacturing tolerances. Page 48 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 55: Power Supply Connection To Pump Controller
(NFPA 750; 6.9.2.2). However, power feed shall be arranged so that if the power supply within the protected facility itself must be disconnected during a fire, the power supply to the pump feeder circuit will not be interrupted (NFPA 750: 6.9.2.3). 4.1.6.2. Power Supply Capacity Power supply shall be capable of carrying indefinitely the sum of the locked‐rotor current of the fire pump motor(s) and pressure maintenance pump motor(s) and the full‐load current of the associated fire pump accessory equipment. The following formula can be used to calculate the pump’s motor inrush current, also known as locked‐rotor amps or LRA. Simply insert the motor’s KVA/HP, HP rating, and Voltage values into the formula. LRA = (KVA/HP x Motor HP x 1000) / (1.732 x Motor Voltage) Detection and Releasing Panel Connections to Pump Controller The buyer is responsible for material and labor required to connect the detection and releasing panel to the pump skid controller for pump activation and monitoring purposes, where required. Refer to documentation supplied with the pump controller for connection requirements. Fike recommends that the fire detection control panel and associated control modules used to monitor and control the pump skid be located outside the water mist protected area so they are not subject to the effects of the fire, which could render them inoperable. P/N 06‐791‐1 (Rev. 3) Page 49 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 56: Pipe Connections
3” NPS 2” NPS 2” NPS 1” NPS (420 lpm) 1,758 lbs. 02‐14909‐3‐X‐(21‐30) (797 kg) 1,619 lbs. 02‐14909‐4‐X‐(1‐10) (734 kg) 75 gpm 3” NPS 2” NPS 2” NPS 1” NPS (284 lpm) 1,734 lbs. 02‐14909‐4‐X‐(21‐30) (787 kg) 1,768 lbs. 02‐14909‐5‐X‐(1‐10) (802 kg) 133 gpm 3” NPS 2” NPS 2” NPS 1” NPS (503 lpm) 1,883 lbs. 02‐14909‐5‐X‐(21‐30) (854 kg) *NPS = Nominal Pipe Size Page 50 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 57: Circulation Relief Valve Connection
4.1.8.1. Circulation Relief Valve Connection Each DuraQuench pump skid is equipped with a circulation relief valve. The valve is designed to provide cooling water when the pump is operating at churn (no flow) conditions. The valve is set to automatically open when the system pressure reaches 275 psi (19 bar). The valve provides a 1” NPT female outlet for connection of a drain pipe that must be routed outdoors or to a floor drain where the discharge can be observed by the pump operator. 4.1.8.2. Water Supply Connection To facilitate easy connection of the DuraQuench pump skid to the system water supply, Fike provides the necessary components to install the required suction isolation valve and connect the water supply to the pump skid. The supplied components vary depending upon the inlet size of the pump skid. See Figures 37 and 38. Figure 37: 2” (DN50) Pump Skid Water Supply Connection Item Figure 38: 3” (DN80) Pump Skid Description P/N No. Water Supply Connection 1 Pump skid inlet flange N/A 2 ...
Page 58: Test Header Connection
4.1.8.3. Test Header Connection The test header piping and components must be field installed in accordance with the system design documents. In order to prevent water damage, the discharge from the test header connection shall be piped to a safe discharge location where there is adequate drainage for the pressurized water discharge. A flanged outlet and an isolation valve are provided on the DuraQuench pump skid to allow easy connection and isolation of the test header components. See Figure 39. Figure 39: Test Header Connection 1. Suction flange 9. Discharge Pressure Gauge 2. Suction basket strainer 10. Discharge isolation valve (monitored) 3. Suction pressure gauge 11. Discharge flange 4. Circulation relief valve (opens at 275 psi/19 bar) 12. Flow meter (optional) ...
Page 59: Fire Department Connection
1. Where the system’s design pressure is less than or equal to 175 psi (12 bar), the FDC connection shall be made after the fire pump on the supply side of the pump skid, as shown in Figure 40. Installation of the FDC in this manner requires that a strainer or filter be installed in the FDC supply line. Figure 40: Fire Department Connection for System Design Pressure <= 175 psi (12 bar) 1. Suction flange 10. Discharge isolation valve (monitored) 2. Suction basket strainer 11. Discharge flange 3. Suction pressure gauge 12. Discharge check valve 4. Circulation relief valve (opens at 275 psi/19 bar) 13. Isolation valve 5. Centrifugal pump and motor 14. Strainer or filter 6. Pressure relief valve (opens at 245 psi/16.9 bar) 15. Check valve 7. Test header stop valve (monitored) 16. Drain valve (piped to drain) 8. Test header flange 17. Fire department connection 9. Discharge pressure gauge P/N 06‐791‐1 (Rev. 3) Page 53 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 60: Figure 41: Fire Department Connection For System Design Pressure >175 Psi (12 Bar)
2. Where the system’s design pressure is greater than 175 psi (12 bar), the FDC connection shall be made on the suction side of the fire pump, as shown in Figure 41. Figure 41: Fire Department Connection for System Design Pressure >175 psi (12 bar) 1. Suction flange 9. Discharge pressure gauge 2. Suction basket strainer 10. Discharge isolation valve (monitored) 3. Suction pressure gauge 11. Discharge flange 4. Circulation relief valve (opens at 275 psi/19 bar) 12. Supply isolation valve (monitored) 5. Centrifugal pump and motor 13. Check valve 6. Pressure relief valve (opens at 245 psi/16.9 bar) 14. Drain valve 7. Test header stop valve (monitored) 15. Fire department connection 8. Test header flange Page 54 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 61: System Piping And Components
After flushing, all plugs shall be removed and any trapped debris removed prior to installing nozzles. Pneumatically purge the water from the distribution piping. Electrical Potentials Pipes and wetted component materials having different electrical potentials shall be electrically insulated from one another. CAUTION: When connecting the stainless steel system pipes from the protected enclosure to a pipe system of different materials outside the protected enclosure, an electrical isolation pipe washer of minimum 1” (25 mm) should be installed between the two pipe systems, and flange bolts and nuts should also be electrically insulated. Pipe Joints Pipe joining methods shall be acceptable to FM Global and the authority having jurisdiction. Thin walled stainless steel pipes may be joined together using FM Approved press fittings, flanges, and threaded joints. See Electrical Potentials above. P/N 06‐791‐1 (Rev. 3) Page 55 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 62: Pipe Supports
Where the C‐EL deluge valve is used, refer to Fike document 06‐791‐3 for installation instructions. The valve shall be installed so it is accessible for operation, inspection, and maintenance, but shall not be installed where it will be subject to damage that would prevent proper operation. 4.4. Automatic Pressure Relief Valve Every DuraQuench pump skid is equipped with an automatic pressure relief valve that ensures a continuous flow through the pump when running by diverting a portion or all of the pump discharge back to the pump suction based on the process flow. The valve is closed when the process flow is greater than the control set point (that is, minimum flow rate required), opens gradually as the process flow is reduced and pressure increases, and is fully open when the process flow is reduced or stopped resulting in an increase in pressure greater than the pressure relief valve’s set point. ...
Page 63: Nozzles
4.5. Nozzles 1) All nozzles should subjected to a thorough visual inspection prior to the installation of the product. Should the packaging appear to be damaged in any way, it should not be installed. Damaged nozzles shall be returned to Fike. 2) Prior to installing the nozzles, it is recommended to record the production batch number imprinted on the nozzle along with a description of the placement of each nozzle for product traceability. 3) Care should be taken not to drop or otherwise physically damage the nozzles prior to installation. 4) The K6 water mist nozzles shall be installed in strict accordance with the design documentation prepared for the specific installation. Any required deviations must be approved prior to installation. 5) Nozzles shall be installed in one level at the maximum height indicated on the design documentation. 6) Nozzles shall be installed in a pendent position in the distribution pipe. 7) Nozzles shall be installed below construction beams and major obstructions to provide a homogenous water mist distribution in the enclosure. See Section 3.11.3.4. Installation of additional nozzles to account for ...
Page 64: System Acceptance And Commissioning
SYSTEM ACCEPTANCE AND COMMISSIONING The DuraQuench water mist system shall successfully meet all system acceptance and commissioning procedures and should be documented with copies provided to the system owner and manufacturer. All acceptance and commissioning procedures shall be reviewed by FM Global. FM Global can request changes prior to granting the approval. Refer to the following Fike documents for system Startup and Testing procedures: 1. 06‐814 – Centrifugal Fire Pump Acceptance Test Form 2. 06‐815 – Fire Pump Controller Start‐Up Form 3. 06‐816 – Water Mist System Acceptance Test Form 5.1. Commissioning Requirements Acceptance and commissioning testing should include the following: 1. Acceptance procedures shall be in accordance with FM Global Property Loss Prevention Data Sheet 4‐2 ‐Water Mist Systems; Data Sheet 2‐8 ‐ Earthquake Protection for Water‐Based Fire Protection Systems; NFPA 750 ‐ Standard on Water Mist Fire Protection Systems; NFPA 25 ‐ Standard for the Inspection, Testing, and ...
Page 65: Operation
OPERATION Subject to the specific project requirements, the DuraQuench deluge water mist system will be arranged to operate automatically or manually as described in this section. 6.1. Electric Automatic or Manual Upon activation of the fire detection and releasing system from thermal detectors (verified) or a manual release switch within the protected area, the following events shall occur: 1. Fire detection and releasing panel shall initiate a fire alarm signal to the fire brigade. 2. Fire detection and releasing panel shall activate exterior alarm bell to indicate water flow. 3. Fire detection and releasing panel shall activate interior alarm notification appliances for building occupant notification. 4. Fire detection and releasing panel shall initiate an electrical signal to the C‐EL valve’s solenoid actuator to open the valve allowing water to flow through the valve into the pipe distribution system. 5. Fire detection and releasing panel shall initiate an electrical signal to the fire pump controller to initiate start‐ up of the fire pump. 6. The system will discharge on a continuous basis through the pipe distribution system to the water spray nozzles until the fire pump is manually stopped at the fire pump controller. 6.2. C‐EL Valve Manual Release Lever The trim‐kit on the C‐EL valve is equipped with a manual release lever that provides a manual means of activating the deluge valve. Upon activation of the local manual release lever, the following events shall occur: 1. The deluge valve will open allowing water to flow through the valve into the pipe distribution system. 2. The flow of water will trigger a water flow alarm pressure switch that is installed in the distribution piping. 3. Alarm pressure switch will be monitored by the fire detection and releasing panel and will provide an electrical signal to initiate start‐up of the fire pump. 4. Fire detection and releasing panel shall initiate a fire alarm signal to the fire brigade. 5. Fire detection and releasing panel shall activate exterior alarm bell to indicate water flow. 6. Fire detection and releasing panel shall activate interior alarm notification appliances for building occupant ...
Page 66: Inspection And Testing
INSPECTION AND TESTING The DuraQuench water mist system shall be inspected and tested in accordance with the requirements of the following documents and standards to verify that it functions as intended:  FM Global Property Loss Prevention Data Sheet Number 4‐2, Water Mist Systems  FM Global Property Loss Prevention Datasheet 2‐8, Fire Protection System Inspection, Testing and Maintenance  NFPA 25, Standard for the Inspection, Testing, and Maintenance of Water‐Based Fire Protection Systems  NFPA 750, Standard on Water Mist Fire Protection Systems  Local code requirements NOTE: Should the area surrounding the nozzles need maintenance, it is important to protect the K6 nozzles from any damage or from getting in contact with different chemicals (including cleaning fluid, paint, etc.) or fairly dirty water which can lead to clogging or obstructions. 7.1. Frequency The inspection and testing frequency shall be in accordance with Table 12.1.2 of NFPA 25, Standard for the Inspection, Testing, and Maintenance of Water Based Fire Protection Systems, FM Global Property Loss Prevention Data Sheet Number 2‐8 and FM Global Property Loss Prevention Data Sheet Number 4‐2, or the following instructions, whichever is more frequent. Item Activity ...
Page 67: System Restoration After Operation
SYSTEM RESTORATION AFTER OPERATION After system operation (test or fire incident), the following procedure must be followed to restore the DuraQuench system back to normal operation. The procedure is written around the use of the C‐EL deluge control valve. Once it has been confirmed that the test is complete or the fire has been extinguished, press the red STOP button on the front of the pump controller to turn off the fire pump. Notify remote monitoring entity and fire brigade that the water mist system is going to be taken out of service. Power down the fire pump controller by closing the Circuit Breaker Switch and then the Isolating Switch. Verify loss of AC power to the controller is indicated on the Detection and Releasing panel. Close the supply isolation valve [X] on the pump skid. See Figure 43. Verify that a supervisory signal is indicated at the Detection and Releasing panel. Disconnect the actuator from the C‐EL valve solenoid coil by loosening the attachment screw. With the solenoid coil still attached to the valve body, momentarily apply 24 VDC reverse polarity voltage (‐ to A and + to B) to the solenoid coil [B] as shown in Figure 42 to close the valve. Figure 42: Solenoid Valve Reset Reconnect the solenoid actuator to the solenoid coil and secure in place with the attachment screw. Open the system drain/test valve [Z] located upstream of the C‐EL control valve to drain the residual water from the system riser pipe. See Figure 43. Verify that a supervisory signal is indicated at the Detection and Releasing panel. Close the drain/test valve [Z] once water flow stops. See Figure 43. Verify that the supervisory signal event indicated in Step 8 clears. Turn the manual release lever [A] on the C‐EL valve to the open position to drain any residual water from the C‐EL valve via the valve trim drain. See Figure 43. Close the manual release lever [A] once water flow stops. See Figure 43. Clean the pump skid strainer per the procedure outlined in Appendix B. Inspect a representative sample (minimum of 10% of nozzles in the activated zone) of the system nozzles for contamination of nozzle strainer. If debris is found all nozzle strainers in the activated zone should be cleaned. See Appendix C. Close isolation valve [Y] on the pipe riser. See Figure 43. Verify that a supervisory signal is indicated at the Detection and Releasing panel. Open the supply isolation valve [X] on the pump skid and verify that the supervisory signal event indicated in Step 4 clears. See Figure 43. Verify that the inlet pressure gauge [C] on the C‐EL valve shows a build‐up of water pressure. See Figure 43. P/N 06‐791‐1 (Rev. 3) Page 61 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 68: Figure 43: Typical C-El Valve Riser
Verify that the outlet pressure gauge [D] on the C‐EL valve reads zero, indicating that the C‐EL valve is closed. See Figure 43. Verify that the supervisory event indicated in Step 14 clears. If the pressure gauge [D] shows a pressure build‐up between the isolation valve [Y] and the C‐EL valve, close isolation valve [X] and correct the problem before attempting to open isolation valve [X] again. See Figure 43. A pressure buildup indicates that either the C‐EL valve is not seated correctly; the manual release valve [A] is open; or the solenoid valve [B] is open. See Figure 43. Open isolation valve [Y]. See Figure 43. Reset the Detection and Releasing panel making sure that no events are present on the system. It is important that the panel be clear of all events (normal operation) in order to prevent the fire pump from restarting once power is reapplied to the fire pump controller. Power up the fire pump controller by closing the Isolating Switch and then the Circuit Breaker Switch. Figure 43: Typical C‐EL Valve Riser Page 62 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 69: Figure 44: Pressure Relief Valve Schematic
5) Turn the adjusting screw of Relief Pilot (6) counterclockwise until valve spring is free. 6) Make sure closing speed control (5) is fully open. Inlet Outlet 7) Open the water supply isolating valve on the pump skid to apply water pressure to pressure relief valve inlet. Figure 44: Pressure Relief Valve Schematic Pressure relief valve should be wide open. 8) Confirm that power is applied to the fire pump controller. 9) Start the fire pump by pressing the green start button on the controller. One‐hundred percent of pump capacity will now flow through the pressure relief valve back to the pump inlet. 10) Turn adjusting screw of Pilot (6) slowly clockwise until pressure at the pressure relief valve inlet reaches desired set point. Use the pump discharge pressure gauge to determine valve inlet pressure. 11) Turn off the fire pump by pressing the red stop button on the controller. 12) Lock adjusting screw of Pilot (6) in place. Valve is now set to relieve at the desired pressure. 13) Record the set pressure on the tag attached to the pressure relief valve. P/N 06‐791‐1 (Rev. 3) Page 63 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 70: Annex B - Basket Strainer Cleaning Procedure
Remove the strainer cover making sure O‐ring remains intact. Lift strainer basket from the strainer body. Invert the basket and wash out debris by directing a stream of air or water against the basket exterior. NOTE ‐ Do not allow basket contents to dry as this will make cleaning most difficult. Inspect basket strainer at each cleaning for holes or tears and replace as required. Place clean or new basket squarely on the basket seat. Be sure basket handle is sufficiently high to be compressed by strainer cover. Inspect O‐ring and seal surface. Clean seat or replace O‐ ring as necessary. Replace strainer cover making sure O‐ring is in place. Figure 45: Pump Skid Basket Strainer Swing the yoke over the cover and make full contact with the yoke stud. Tighten the center T‐bolt. Perform pump skid startup procedure. Page 64 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 71: Annex C - Nozzle Strainer Cleaning Procedure
1) Loosen part A M3 pivot screw on the side of the nozzle. 2) Unscrew the two main nozzle parts B and C from each other. 3) Remove part D nozzle strainer from part B and clean it. 4) Reinstall part D nozzle strainer into part B. 5) Screw part B and part C together again. 6) Insert part A M3 pivot screw in the hole on the side of the nozzle and screw in place to secure nozzles components Figure 46: K6 Nozzle Strainer Cleaning together. P/N 06‐791‐1 (Rev. 3) Page 65 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 72: Annex D - Pump Information
Head in Feet at Rated Flow 444.9 500.3 4 Rated Motor hp (P2) 15 25 5 Head at Zero Flow (max) 554.5 638.5 6 Rated rpm 2924 2934 7 Rated Flow (gpm) 74.85 132.09 8 Rated Frequency (Hz) 50 50 Maximum Pressure / 9 363 / 194 435 / 194 Maximum Liquid Temperature 10 Direction of Rotation CCW CCW Page 66 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 73: Figure 48: Fire Pump Vent Plug
D.2. Priming the Pump CAUTION: Be sure the isolation valve on the discharge side of the DuraQuench pump skid is closed and the fire pump is primed (filled with water) and ready operation prior to starting the pump. Failure to prime the pump before running the motor will cause damage to the motor bearings. CAUTION: Pump motor should not be run unloaded or uncoupled from the pump at any time; damage to the motor bearings will occur. 1. Close the discharge isolating valve on the pump skid to prevent water from flowing into the piping network. 2. Close the water supply isolating valve on the pump skid to prevent water from flowing into the pump skid. 3. Open the priming plug on the pump head. See Figure 48. LOOSEN CENTER PLUG TO VENT PUMP Figure 48: Fire Pump Vent Plug 4. Gradually open the water supply isolating valve on the pump skid until a steady stream of airless water runs out of the priming hole. 5. Close the plug and tighten securely. 6. Completely open the water supply isolating valve on the pump skid. The discharge isolating valve should remain closed until testing of the pump is complete. 7. Pump is now ready for functional testing. P/N 06‐791‐1 (Rev. 3) Page 67 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 74: Figure 49: Fire Pump Coupling Guard
10. Re‐close the controller cabinet door then close the IS and CB to re‐energize the controller. 11. Jog (bump) the motor again to verify correct direction of rotation (counter‐clockwise). 12. Once the correct direction of rotation has been visually verified, open the CB and the IS to remove power from the controller. 13. Replace the coupling guard on the fire pump; then re‐apply power to the controller. Do not attempt to reinstall the coupling guard while power is applied to the controller. 14. Check that the display is powered up with no Alarms present. CAUTION: Motors should not be run unloaded or uncoupled from the pump at any time; damage to the motor bearings will occur. Do not start the pump before priming or venting the pump. Never let the pump run dry. Page 68 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 75 D.4. Pump Performance Curves 02‐14909‐1, 53 gpm (200 l/min) / 60 Hz Pump 02‐14909‐2, 53 gpm (200 l/min) / 60 Hz Pump (increased pressure) ‐14 (02‐14909‐2‐X‐X) ‐12 (02‐14909‐1‐X‐X) P/N 06‐791‐1 (Rev. 3) Page 69 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 76 02‐14909‐3, 111 gpm (420 l/min) / 60 Hz Pump ‐10 (02‐14909‐3‐X‐X) Page 70 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 77 02‐14909‐4, 75 gpm (284 l/min) / 50 Hz Pump ‐12 (02‐14909‐4‐X‐X) P/N 06‐791‐1 (Rev. 3) Page 71 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 78 02‐14909‐5, 133 gpm (503 l/min) / 50 Hz Pump ‐10 <(02‐14909‐5‐X‐X) Page 72 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 79 D.5. Factory Pump Performance Curves 02‐14909‐1, 53 GPM / 60 Hz Fire Pump P/N 06‐791‐1 (Rev. 3) Page 73 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 80 02‐14909‐2, 53 GPM / 60 Hz Fire Pump Page 74 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 81 02‐14909‐3, 111 GPM / 60 Hz Fire Pump P/N 06‐791‐1 (Rev. 3) Page 75 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 82 02‐14909‐4, 75 GPM / 50 Hz Fire Pump Page 76 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 83 02‐14909‐5, 133 GPM / 50 Hz Fire Pump P/N 06‐791‐1 (Rev. 3) Page 77 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
Page 84 This page intentionally left blank. Page 78 P/N 06‐791‐1 (Rev. 3) 704 SW 10 Street, P.O. Box 610, Blue Springs, Missouri 64013‐0610 U.S.A. ● Phone: (816) 229‐3405 ● www.fike.com ...
