Swisscom Centro Business 3.0 How To Set Up page 2

LED behaviour
WLAN LED
LED is not on – WLAN is switched off.
LED lights up blue – WLAN is switched on.
LED flashes white – WPS mode is active.
Service LED
LED lights up white – Business Network Solutions
(BNS) is activated.
Telephony LED
LED is not on – you are not subscribed to
telephone services or there is a fault.
LED lights up green – telephony is activated.
LED lights up red – not all numbers are registered
or registration is in progress.
Internet backup LED
(customers with «Failsafe Internet Backup service»)
LED is not on – no backup dongle connected.
LED flashes white (1–2 times per sec.) – backup
dongle installation in progress.
LED lights up white – backup service is ready.
LED flashes white/red – Internet backup in
operation.
LED lights up red – there is a fault.
LED flashes red fast (3–4 times per sec.) –
activation fault has occurred. Please wait.
Mobile Internet LED
LED is not on – no connection to a mobile Internet
device.
LED flashes green – connection to mobile Internet
in progress.
LED is green – mobile Internet is active.
LED is red – there is a fault.
Internet LED
LED is not on – no connection to the Internet.
LED flashes white – connection to the Internet in
progress.
LED lights up white – Internet connection active
and IP address assigned.
LED lights up red – there is a fault.
Power LED
LED is not on – router is switched off.
If you are unable to switch it on, check the power
supply.
LED flashes white – router launch, configuration or
update in progress. Please do not switch off.
LED lights up white – router is ready.
LED lights up red – there is a fault.
For more information, go to:
www.swisscom.ch/centrobusiness
Ports, LEDs and buttons
Analogue telephone ports
1 Gbit/s Ethernet
10 Gbit/s Ethernet
Internet
USB 2.0
Power supply connection
On/Off (Power)
Reset
WLAN
Service
Telephony
Internet Backup
Mobile Internet
Internet
Power
WLAN (WPS)
USB 3.0
