One Handle Deck Mount Tub FIller: How to Replace a 161772 Diverter
This is an easy-to-follow instructional guide explaining the process for identifying and replacing the 161772 diverter
cartridge in a Moen Single Handle Deck Mount Tub Filler.
Preparation:
• The water supply shut off valves must be turned off- see article
Faucet.
• Recommended Tools: 5/32" Hex Wrench, Pliers, Phillips screwdriver, Diverter Tool 161773 (This is required for the
repair. Do not start to service the product unless you have the Diverter Tool. If you need the tool
1-800-BUY-MOEN
Identify Your Diverter Lift Rod Style
One Handle Deck Mount Tub Filler
style of the
diverter lift rod
Wrench and flathead screwdriver.
Model:T907
To Access the Diverter
https://solutions.moen.com/Article_Library/One_Handle_Deck_Mount_Tub_FIller%3A_How_to_Replace_a_161772_Diverter
diverter lift rods
are assembled in two different ways. You must first identify the
before accessing the diverter. If you are servicing the T937 you will also need a 7/64" Hex
How to Turn Off the Water Supply to the
Model: T967
Updated: Sat, 17 Feb 2024 04:55:08 GMT
