SC-HD-2B
4K UHD HDMI 2.0 Scaler & Audio Embedded/Extractor
USER MANUAL
August 10, 2023
Hall Technologies
August 10, 2023
Page 1 of 13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-HD-2B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hall Technologies SC-HD-2B

  • Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com SC-HD-2B 4K UHD HDMI 2.0 Scaler & Audio Embedded/Extractor USER MANUAL August 10, 2023 Hall Technologies August 10, 2023 Page 1 of 13...
  • Page 2 8. Protect the power cord from being walked on or pinched particularly at plugs. 9. Only use attachments / accessories specified by the manufacturer. Refer all servicing to qualified service personnel. Hall Technologies August 10, 2023 Page 2 of 13...
  • Page 3: Table Of Contents

    Overview ............................4 Features ............................5 Package Contents ............................5 Installation ..............................5 ODS Menu ........................... 6-7 Connectors and Indicators ......................... 8 SC-HD-2B Front ..........................8 SC-HD-2B Back ..........................8 Troubleshooting ............................9 Specifications ............................10 Hall Technologies August 10, 2023...
  • Page 4: Introduction

    The audio embedded into the HDMI output is selectable from one of three sources: HDMI input, analog L/R input, or digital optical input. The SC-HD-2B has the ability to output a wide range of resolutions regardless of the input timing and resolution. The output resolution can automatically match the native resolution of the display connected to its output (based on the EDID setting of the display), or it can be specified by the user.
  • Page 5: Features

    Ÿ 1x 3.5mm to (2) RCA Audio Cable Ÿ 1x Product Information Card Installation Connect the HDMI source to the SC-HD-2B HDMI Input. • Optionally, connect the Analog or Digital audio source to the 3.5mm or optical TOSLink Input •...
  • Page 6: Ods Menu

    Press MENU to select sub- menus, and press MENU again to apply new values. Select EXIT to return to the main menu or exit the OSD. Values in BOLD* are factory default settings. Hall Technologies August 10, 2023 Page 6 of 13...
  • Page 7 Hall Technologies August 10, 2023 Page 7 of 13...
  • Page 8: Connectors And Indicators

    Connectors & Indicators SC-HD-2B Front Name Description USB-A connector is provided for firmware upgrade. INPUT: Video and audio inputs. HDMI accepts resolutions up to 4K UHD. Audio input is INPUT user-selectable via OSD menu: HDMI, Optical TOSLink, or Analog Audio.
  • Page 9: Troubleshooting

    • buttons simultaneously for 3 seconds. As shipped, the SC-HD-2B output resolution is defaulted to NATIVE. This means it will read the • EDID of the attached display, and set the scaled output to match the preferred timing found in the EDID.
  • Page 10: Specifications

    < +/- 3 dB @ 20 Hz- 20 kHz Crosstalk < -70 dB @ 10 kHz Type Unbalanced Optical Audio Input Audio Level 32, 44.1, 48, 82, 88.2, 96, 176.4, 192 Optical Audio Output Audio Level Hall Technologies August 10, 2023 Page 10 of 13...
  • Page 11 Dimensions mounting flanges Model Only 0.77 lbs (0.35kg) Product Weight Shipping 2.85 lbs (1.29 kg) Safety EMI/EMC CE, FCC, Class A MTBF 90,000 hours (estimate) Warranty 3 years parts and labor Hall Technologies August 10, 2023 Page 11 of 13...
  • Page 12 Supported Input and Output Resolutions Hall Technologies August 10, 2023 Page 12 of 13...
  • Page 13 © Copyright 2023. Hall Technologies All rights reserved. 1234 Lakeshore Drive, Coppell, TX 75019 halltechav.com / support@halltechav.com (800)-959-6439 Hall Technologies August 10, 2023 Page 13 of 13...
