USX-MOUNT XML601-24K Instruction Manual
  1. Manuals
  2. Brands
  3. USX-MOUNT Manuals
  4. TV Mount
  5. XML601-24K
  6. Instruction manual

USX-MOUNT XML601-24K Instruction Manual

For 37-90" tv
Hide thumbs

Advertisement

Quick Links

Download this manual
R
XML601-24K
INSTRUCTION MANUAL
For 37-90" TV
If you have any questions along the way, just message
to us. We're ready to help!
USA-C0

Advertisement

loading
Need help?

Need help?

Do you have a question about the XML601-24K and is the answer not in the manual?

Questions and answers

Related Manuals for USX-MOUNT XML601-24K

Summary of Contents for USX-MOUNT XML601-24K

  • Page 1 XML601-24K INSTRUCTION MANUAL For 37-90" TV If you have any questions along the way, just message to us. We’re ready to help! USA-C0...
  • Page 2 CAUTION: PLEASE READ ENTIRE MANUAL PRIOR TO USE AND SAVE THESE INSTRUCTIONS Before getting started, let’s check below lists to make sure it is just right for you! MAX:600mm/23.62" (MIN:200mm/7.87") Check your TV VESA is within No? This mount is NOT compatible. Min and Max size MAX:400mm/15.74"...
  • Page 3 Dimensions TV INTERFACE 200mm [7.87in] 100mm 400mm [3.94in] [15.74in] 600mm [23.62in] WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 609mm +5° [24in] [0.35in] 304mm 175mm [11.98in] [6.89in] -20° 406mm [16in] FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED SIDE VIEW - EXTENDED 635mm [25.00in] 38mm...

  • Page 4: Parts And Hardware

    Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
  • Page 5 Parts and Hardware for STEP 2 Mounting template Wall Plate Extenders Velcro x3 16"(406.4mm) 8"(203.2mm) 24"(609.6mm) Concrete wall anchor (NOT INCLUDED) Level x1 Contact us and message to us to have these additional pieces shipped directly to you. Concrete Wall Anchor Ø10x50mm 4pcs M6x16mm Bolt Lag Bolt M8x60mm...
  • Page 6 Assemble Wall plate STEP 3 Please choose proper wall plate pattern according to your wall condition. Pattern 1: For 16" wood studs or concrete wall 16" Wall plate Pattern 2: For 24" wood studs or concrete wall 16" Wall plate 24"...

  • Page 7: Step 1 Attach Brackets To Tv

    STEP 1 Attach Brackets to TV 1-1 Select TV Screws...
  • Page 8 1-2 Figure out the suitable position of brackets HIGH MOUNTING HOLES LOW MOUNTING HOLES TV BRACKETS MUST BE LEVEL INSTALL UP/DOWN IF NEEDED...
  • Page 9 1-4 Attach the TV Plate 1-3 Need Spacer? No, choose suitable screws and washers. a b c Yes, choose suitable screws, washers and spacers. g h i Tips: If you need to combine M6/M8(c/e/f) screws with 2.5mm spacers( i ), you have to remove the inner circle.
  • Page 10 STEP 2A Attach Wall Plate to Wall Wood Stud Option CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall, must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) ●...
  • Page 11 3. Drill pilot holes using a 7/32 in. (5.5 mm) diameter drill bit. IMPORTANT: Pilot holes must be drilled to a depth of 2.5 in. (64 mm). Be sure to drill into the center of the studs. 4. Install wall plate using four lag bolts .
  • Page 12 STEP 2B Attach Wall Plate to Solid Concrete Wall CAUTION: Avoid potential personal injury or property damage! ● Mount the wall plate assembly directly onto the concrete surface ● Minimum solid concrete thickness: 8 in. (203 mm) 1. Position the mounting template on the wall at your desired height. Level the wall plate and mark the hole locations.
  • Page 13 3. Insert four anchors. CAUTION: Be sure the anchors are seated flush with the concrete surface. 4. Insert wall plate using four lag bolts . Tighten the lag bolts only until they are pulled firmly against the wall plate. CAUTION: Improper use could reduce the holding power of the lag bolt. DO NOT over-tighten the lag bolts.
  • Page 14 STEP 3 Extension Arms and end support Assembly Please make sure you install these extension arms in right direction.
  • Page 15 STEP 4 Wall Plate Installation Integrity Test Before hanging TV, please try to pull the mount to make sure that it has been assembled on the wall tightly. 120 LBS (54.5 kg)
  • Page 16 STEP 5 Hang and Secure TV to Wall Plate Hang the pre-assembled TV into the extension arm. wrap clips on bracket around extension arms, and wrap the extension arm, and then tighten the bracket with the wrap clips by Allen Key and Bolt...
  • Page 17 STEP 6 Adjustments 6-1 Tilting angle adjustment (+5°/-20°) ： Pull TV to your desired angle then fasten 2 tilting bolts with Allen key +5° Tighten Loosen +5° -20° -20° Tighten Loosen...
  • Page 18 6-2 Cables manage: Manage TV cables orderly and guide them through the velcros. Velcro...
