- Page 1 SMARTFLEX 2 & 3 ADJUSTABLE BED MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ………...……………………………….….….…3 Introduction………………...……………… .………...5 Care……………………………………………………..6 Features...…………..………………..………..……..7 Unpacking Your Base ………………….…..…...8 Attaching Legs & Castors to the Base ...…..…………9 Hand Control Overview…………………..….…..10 Reprogramming Hand Control Positions...………….11 Syncing Bases………………..…………..…….…….12 Battery Back Up ……………………………………...13 Bluetooth Accessory………………………………….14 Troubleshooting ..……………………………..….…..15 Product Guarantee ………..…………………..…...17 Notes …………………………………………………..19... -
Page 3: Safety
SAFETY ATTENTION: Important Safety Disclaimers Read all instructions before using your adjustable base. Save these instructions. WARNING Always unplug the base from electrical outlet before servicing any part of the base. Unplug the base before cleaning. To safely disconnect, ensure base is in a flat position with all motors off. TO REDUCE THE RISK OF SHOCK, FIRE OR INJURY: For optimal safety and operation, plug the bed base into a surge protector (not included). - Page 4 SAFETY To reduce the risk of falls on height adjustable bases, the base should always • be in its lowest position for sleeping and resting. The highest position should only be used for carer’s access to the user, ease of entry and exit of bed for the user and ease of making the bed.
-
Page 5: Introduction
You may be asking, what are the differences between the two beds seen above? The SmartFlex 3 has enhanced functionality with the addition of the Hi-Lo feature. • Legs come standard on the SmartFlex 2, whilst the SmartFlex 3 comes standard with • Castors. -
Page 6: Care
Lubricate moving parts using a non-corrosive lubricant every 6 • months or as required. Avante recommends the use of INOX. Beds should be positioned with clearance from walls and other objects • so as not to cause damage. -
Page 7: Features
Under-bed lighting. • Zero Gravity. • Wireless remote control with LED • screen. Castors (For SmartFlex 3). • Black legs (For SmartFlex 2). • Battery back up. • Dual zone massage. • 3 Speed massage unit. • FRAME DESIGN FEATURES Whisper quiet, low voltage, DC lift •... -
Page 8: Unpacking Your Base
UNPACKING YOUR BASE Open the carton box & remove the protective plastic. Open all the parts boxes & cut the zip ties to release all parts. -
Page 9: Attaching Legs & Castors To The Base
THE BASE For SmartFlex 3: Locate the box containing the castors. Screw in the castors as shown below. For SmartFlex 2: Locate the box containing the bed legs Screw the 4 corner legs in as shown with included leg bolts. -
Page 10: Hand Control Overview
Insert the 2 x AAA batteries into the back of the controller. Depending on if you have purchased a SmartFlex 2 or 3, your remote will be different. The image at the left depicts a SmartFlex 2 remote, whilst the right image is of a SmartFlex 3 remote. Please refer to the following diagram explaining the functions. -
Page 11: Reprogramming Hand Control Positions
The current position of the bed is now saved as a custom position under the pre-set button. SMARTFLEX 3 SMARTFLEX 2 HAND CONTROLLER HAND CONTROLLER SET UP MEMORY POSITION 1. Adjust the bed into desired position. -
Page 12: Syncing Bases
The blue pairing LED light on the control box will turn green to indicate that pairing is complete. If not successful, repeat the above steps. SMARTFLEX 3 SMARTFLEX 2 HAND CONTROLLER HAND CONTROLLER To Sync TWO bases to ONE remote Requires Link Cable (Need to be purchased separately) Insert link cable end into each control box on the separate bases you wish to sync. -
Page 13: Battery Back Up
BATTERY BACK UP The Battery Back Up requires 2 x 9 volt batteries and is located in the back of the transformer. Batteries NOT included. This system is designed for a once off use (for each set of batteries). Batteries should be replaced straight away when the battery back up function has been used. -
Page 14: Bluetooth Accessory
BLUETOOTH ACCESSORY The Bluetooth device will allow the user to connect the smart device (smartphone, tablet) to the adjustable bed and operate the bed through phone app. The Bluetooth device is not included as part of the bed. Device needs to be purchased separately. -
Page 15: Troubleshooting
TROUBLESHOOTING Below is a list of possible problems & their solutions should the adjustable base fail to operate properly PROBLEM SOLUTION The base does not respond when Perform any or all of the following: the remote is used. Check that the power cord is plugged •... - Page 16 The USB port is a SLOW charging port and will not support Fast Charge. If you have followed the instructions outlined in this manual, and your problem is persisting, please contact the retailer you originally purchased your bed from or Avante Australia for further assistance.
-
Page 17: Product Guarantee
Avante Australia proudly provides a full guarantee (10 years—applies to frame, structure & electric motors only. All other electronic components & upholstery are covered for 2 years). Please refer to www.avante.com.au for details against faulty workmanship and/or faulty materials. During the guarantee period, if we are satisfied there is a genuine fault, we will repair or replace the product if it’s an option. - Page 18 If this cannot be done, please contact Avante Australia Pty Ltd directly via the details on the back of this manual. Avante Australia will require photos of the Mattress and Base support system to be sent at the time of a claim being made.
-
Page 19: Notes
NOTES... - Page 20 NOTES...
- Page 21 Avante Australia Pty Ltd Unit 2, 29-71 Saltwater Circuit Narangba, QLD 4504 Phone: 07 3284 3133 Fax: 07 3284 3199 www.avante.com.au...
