Avante HED102D Lift Assembly Instructions

ASSEMBLY INSTRUCTIONS
Model:Lift
HED102D
Desktop Dimensions: 108-187cm
●
4 Height Position Memory
●
Vertical Range: 60 - 125cm
●
Power Input Max.Speed Motion Noise
110V-240V 25 mm/s
< 55dB
[Revision 3.0 June 2019]
Screws/Fasteners (bag)
A M5×16 screw
B M6×12 screw
C Adjustable feet
D M5×12 screw
S=4mm
E
RATED
Load Capability
260 lbs / 120 kg
10pcs
32pcs
4pcs
2pcs
1pcs
PARTS INCLUDED
4
10
6
A
B
C
INSTALLATION
1 Attach the adjusting foot(C) to the foot (9) ,
connect the table leg (8) to the foot (9), and
fasten the screw (B) with the wrench (E).
C
9
B
M6x12
8PCS
9
B
8
1 Desk Parts
1.
Desktop
2
2. Controller panel
D
Side plates
3.
5 3
4. Power cord
7
Frame
5.
8
Connection line
6.
7. Connecting rod
Table legs
8.
9
Foot
9.
10. Controller box
2
Mount the frame (5) and use the wrench (E)
to lock the screw (B)
E
B
M6x12
8PCS
E
1pc
1pc
2pcs
1pc
2pcs
2 p s c
2pcs
2pcs
2pcs
1pc
5
