- Page 1 Uputstvo za upotrebu (EN) DELL laptop Precision M3581 (NOT22424) Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike, potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji. Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike i konkurentne cene proizvoda.
- Page 2 Precision 3581 Technical Guidebook Regulatory Model: P127F Regulatory Type: P127F002 November 2023 Rev. A03...
- Page 3 A WARNING indicates a potential for property damage, personal injury, or death. © 2023 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 4: Table Of Contents
Contents Chapter 1: Views of Precision 3581....................5 Right....................................... 5 Left......................................6 Top......................................7 Display....................................8 Back......................................9 Bottom....................................9 Service Tag..................................10 Battery charge and status light .............................10 Chapter 2: Specifications of Precision 3581..................11 Dimensions and weight..............................11 Processor....................................11 Chipset....................................12 Operating system................................13 Memory....................................13 External ports..................................13 Internal slots.................................. - Page 5 Dell ControlVault 3.0 ..............................42 Trusted Platform Module............................42 Thermal and acoustic improvements..........................43 System management features............................43 Dell Client Command Suite for In-Band systems management ..............43 Out of Band Systems Management........................44 Chapter 4: ComfortView Plus...................... 45 Chapter 5: Using the privacy shutter...................46 Chapter 6: Dell Optimizer......................
-
Page 6: Chapter 1: Views Of Precision 3581
Views of Precision 3581 Right 1. microSD-card slot Reads from and writes to the microSD-card. 2. Universal audio jack Connect headphones or a headset (headphone and microphone combo). 3. USB 3.2 Gen 1 port Connect devices such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps. 4. -
Page 7: Left
Supports USB4, DisplayPort 1.4, Thunderbolt 4 and also enables you to connect to an external display using a display adapter. Provides data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4. NOTE: You can connect a Dell Docking Station to the Thunderbolt 4 ports. For more information, search in the Knowledge Base Resource at www.dell.com/support. NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device. -
Page 8: Top
1. Power button with optional fingerprint reader Press to turn on the computer if it is turned off, in sleep state, or in hibernate state. When the computer is turned on, press the power button to put the computer into sleep state; press and hold the power button for 10 seconds to force shut-down the computer. -
Page 9: Display
Display 1. Left microphone Provides digital sound input for audio recording and voice calls. 2. Infrared emitter (optional) Emits infrared light, which enables the infrared camera to sense and track motion. 3. Infrared camera (optional) Enhances security when paired with Windows Hello face authentication. 4. -
Page 10: Back
1. Speakers Provide audio output. 2. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. 3. Fan vents Views of Precision 3581... -
Page 11: Service Tag
Service Tag The service tag is a unique alphanumeric identifier that allows Dell service technicians to identify the hardware components in your computer and access warranty information. Battery charge and status light The following table lists the battery charge and status light behavior of your Precision 3581. -
Page 12: Chapter 2: Specifications Of Precision 3581
Specifications of Precision 3581 Dimensions and weight The following table lists the height, width, depth, and weight of your Precision 3581. Table 2. Dimensions and weight Description Values Height: Front height 22.70mm (0.89 in.) Rear height 24.70mm(0.97 in.) Width 357.80 mm (14.09 in.) Depth 233.30 mm (9.19 in.) Weight... -
Page 13: Chipset
Table 3. Processor Description Option one Option two Option three Option four Processor type Generation Intel Generation Intel Generation Intel Generation Intel Core i5-13600H Intel Core i7-13700H Intel Core i7-13800H Intel Core i9-13900H Intel vPro Enterprise vPro Essentials vPro Enterprise vPro Enterprise Processor wattage 45 W... -
Page 14: Operating System
Table 4. Chipset (continued) Description Values PCIe bus Up to Gen 4 Operating system Your Precision 3581 supports the following operating systems: ● Windows 11 Home, 64-bit, Windows 10 downgrade capable ● Windows 11 Pro, 64-bit ● Windows 10 China G-SKU, 64-bit ●... -
Page 15: Internal Slots
● Two Thunderbolt 4 port with DisplayPort Alt Mode/USB Type-C/USB4/Power Delivery NOTE: You can connect a Dell Docking Station to this port. For more information, search in the Knowledge Base Resource at www.dell.com/support. ● One USB 3.2 Gen 1 port with PowerShare ●... -
Page 16: Wireless Module
Wireless module The following table lists the Wireless Local Area Network (WLAN) modules that are supported on your Precision 3581. Table 9. Wireless module specifications Description Option one Option two Model number Realtek RTL8852BE Intel AX211 Transfer rate Up to 1201 Mbps Up to 2400 Mbps Frequency bands supported 2.4 GHz/5 GHz... -
Page 17: Audio
● Supports 4x4 MIMO NOTE: For instructions on how to find your computer's IMEI (International Mobile Equipment Identity) number, search in the Knowledge Base Resource at www.dell.com/support. Audio The following table lists the audio specifications of your Precision 3581. Table 11. Audio specifications ... -
Page 18: Storage
Table 11. Audio specifications (continued) Description Values External volume controls Keyboard shortcut controls Speaker output: Average speaker output Peak speaker output Subwoofer output Not supported Microphone Digital-array microphones in camera assembly Storage This section lists the storage options on your Precision 3581. Your Precision 3581 supports Two M.2 2230/2280 solid-state drives Table 12. -
Page 19: Keyboard Function Keys
Table 14. Keyboard specifications (continued) Description Values ● Japan: 103 keys ● Canada: 99 keys ● French-Canadian Quebec: 100 keys ● French-Canadian: 99 keys Keyboard size X=18.05 mm key pitch Y=18.05 mm key pitch Key distance (Key size: X/Y) X=15.05 mm Y=15.05 mm Keyboard shortcuts Some keys on your keyboard have two symbols on them. -
Page 20: Camera
Table 15. Secondary tasks of keyboard keys (continued) Key combination for task What the task does fn and Cursor up Page up fn and Cursor down Page down Keys with alternate characters There are other keys on your keyboard with alternate characters. The symbols that are shown at the bottom of these keys are the main characters that are displayed when the key is pressed;... -
Page 21: Touchpad
Touchpad The following table lists the touchpad specifications of your Precision 3581. Table 17. Touchpad specifications Description Values Touchpad resolution: >300 DPI Touchpad dimensions: Horizontal 115 mm Vertical 67 mm Touchpad gestures For more information about touchpad gestures available on: ●... -
Page 22: Battery
CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge is completely depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the power consumption. -
Page 23: Display
Display The following table lists the display specifications of your Precision 3581. Table 20. Display specifications Description Option one Option two Option three Display type 15.60-inch Full High Definition 15.60-inch Full High Definition 15.60-inch Full High Definition (FHD) (FHD) (FHD) Touch options Display-panel technology In-Plane Switching (IPS) -
Page 24: Fingerprint Reader (Optional)
Fingerprint reader (optional) The following table lists the specifications of the optional fingerprint-reader of your Precision 3581. Table 21. Fingerprint reader specifications Description Values Fingerprint-reader sensor technology Capacitive Fingerprint-reader sensor resolution 500 dpi Fingerprint-reader sensor pixel size 108 x 88 Sensor The following table lists the sensor of your Precision 3581. -
Page 25: External Display Support
This section lists the contactless smart-card reader specifications of your Precision 3581. Table 27. Contactless smart-card reader specifications Title Description Dell ControlVault 3 contactless smart-card reader with NFC Felica Card Support Reader and software capable of supporting Felica contactless cards... - Page 26 Circuit Card Interface Device for OS level drivers Windows Certified Device certified by Microsoft WHCK Dell ControlVault support Device connects to Dell ControlVault for usage and processing FIDO2 compliance Dell ControlVault 3 Smart-card reader is compliant with the FIDO SPEC NOTE: 125 Khz proximity cards are not supported.
-
Page 27: Contacted Smart-Card Reader
The following table lists the contacted smart-card reader specifications of your Precision 3581. Table 29. Contacted smart-card reader specifications Title Description Dell ControlVault 3 smart-card reader ISO 7816 -3 Class A Card Support Reader capable of reading 5V powered smart mcard... -
Page 28: Operating And Storage Environment
FIPS 201 (PIV/HSPD-12) Compliant via Device compliant with FIPS 201/PIV/ HSPD-12 requirements FIDO2 compliance Dell ControlVault 3 Smart-card reader is compliant with the FIDO SPEC Operating and storage environment This table lists the operating and storage specifications of your Precision 3581. -
Page 29: Chapter 3: Engineering Specifications
Engineering specifications Ethernet Integrated Connection I219-LM Table 31. Integrated Connection I219-LM Data Rates supported 10/100/1000 Mbps Controller Details Controller Bus Architecture PCIe-based interface for S0 state, SMBus for Sx low power state Wake On LAN Wake-on-LAN and remote wake-up support (Magic Packet and Pattern Match) Integrated Memory Interface/BUS... -
Page 30: Wireless Module
Wireless module Realtek RTL8852BE, 2x2, Wi-Fi 6 (Wi-Fi 802.11 a/b/g/n/ac/ax), Bluetooth 5.3 wireless card The following table lists the Realtek RTL8852BE specifications. Table 32. Realtek RTL8852BE specifications Host interface ● PCIe for Wi-Fi ● USB for Bluetooth Network standard IEEE 802.11a/b/g/n/ac/ax, MU-MIMO Wi-Fi Alliance certifications Wi-Fi CERTIFIED* a/b/g/n/ac/ax, WMM*, WPA, WPA2*, WPA3*, and Wi-Fi Direct (Microsoft Windows* only) -
Page 31: Intel Ax211, 2X2 Mimo, 2400 Mbps, 2.4/5/6 Ghz, Wi-Fi 6E (Wifi 802.11Ax), Bluetooth 5.3 Wireless Card
Intel AX211, 2x2 MIMO, 2400 Mbps, 2.4/5/6 GHz, Wi-Fi 6E (WiFi 802.11ax), Bluetooth 5.3 wireless card The following table lists the Intel AX211 specifications. NOTE: Wi-Fi 6 is supported in regions where Wi-Fi 6E is unavailable. Table 33. Intel AX211 specifications Host interface CNVio Network standard... -
Page 32: Wwan Module
Table 33. Intel AX211 specifications (continued) Bluetooth operating frequency bands 2.4 GHz Bluetooth profiles supported Support for Microsoft Inbox Bluetooth profiles in Windows Bluetooth data encryption 128-bit encryption Bluetooth output power Power class 1 Operating temperature 0°C to + 50°C (Full performance at shield temperatures up to 80°C) Storage temperature -40°C to +70°C... -
Page 33: Intel 5000 Global 5G Modem
Intel 5000 Global 5G Modem The following table lists the Intel 5000 Global 5G Modem specifications. Table 35. Intel 5000 Global 5G Modem specifications Form factor M.2 3052 Key-B Host interface PCIe Gen3 Network standard ● NR FR1 (Sub6) FDD/TDD ●... -
Page 34: Intel Uhd Graphics
Table 36. Intel Iris X Graphics specifications (continued) Memory type Shared with system memory Memory interface N/A (Unified Memory Architecture) Estimated maximum power consumption (TDP) 45 W, included in the CPU power Maximum color depth 10 bits Maximum vertical refresh rate Up to 120 Hz NOTE: The refresh rate depends on the resolution. -
Page 35: Nvidia Rtx A1000 Laptop, 6 Gb, Gddr6
Table 38. NVIDIA RTX A500 specifications (continued) Feature Values Memory size 4 GB Memory interface 64-bit Memory configuration 2 x 8 GB (2CH x 256M x 16,14 Gbps) GPU package GB5B-128 ● GPU - 25.7 W ● Memory - 8.5 W 35 W GPU base clock 570 MHz... -
Page 36: Nvidia Rtx A2000 Ada, 8 Gb, Gddr6
NVIDIA RTX A2000 Ada, 8 GB, GDDR6 The following table lists the NVIDIA RTX A2000 Ada specifications. Table 40. NVIDIA RTX A2000 Ada specifications Feature Values NVIDIA RTX A2000 Ada Generation Laptop GPU Cores CUDA cores 3072 Memory bandwidth 256 Gbps Memory type GDDR6 Memory size... -
Page 37: M.2 2230, 512 Gb, Pcie Nvme Gen4 X4, Class 35 Ssd
Table 42. 256 GB SSD specifications (continued) Height (approximate) 3.5 mm (0.17 in.) Width (approximate) 22.00 mm (0.87 in.) Depth (approximate) 30.00 mm (1.18 in.) Interface type PCIe Gen4 Speed (maximum) 64 Gb/s (up to 4 lanes) MTTF 1.4M hours Logical blocks 500,118,192 Power source Power consumption (reference only) -
Page 38: M.2 2230, 1 Tb, Pcie Nvme Gen4 X4, Class 35 Ssd
Table 43. 512 GB SSD specifications (continued) Relative humidity range 5% to 95% M.2 2230, 1 TB, PCIe NVMe Gen4 x4, Class 35 SSD The following table lists the M.2 2230, 1 TB SSD specifications. Table 44. 1 TB SSD specifications Capacity 1 TB Height (approximate) -
Page 39: M.2 2280, 512 Gb, Pcie Nvme Gen4 X4, Class 40 Ssd
Table 45. 256 GB SSD, self-encrypting drive specifications (continued) ● Idle: 5 mW (PS4) Power consumption (reference only) ● Active: 4 W Environmental operating conditions (non-condensing) Temperature range 0°C to 70°C Relative humidity range 10% to 90% Op shock 1500G Environmental non-operating conditions (non-condensing) Temperature range -40°C to 70°C Relative humidity range... -
Page 40: M.2 2280, 2 Tb, Pcie Nvme Gen4 X4, Class 40 Ssd
Table 47. 1 TB SSD specifications (continued) Width (approximate) 22.00 mm (0.87 in.) Depth (approximate) 80.00 mm (3.15 in.) Interface type PCIe Gen4 Speed (maximum) 64 Gb/s (up to 4 lanes) MTBF 1.4M hours Logical blocks 2,000,409,264 Power source Power consumption (reference only) ●... -
Page 41: Power Adapter
Adapters: ● Dell USB-C Mobile Adapter - MH3021P ● Dell Mobile Adapter Speaker phone - DA310 Carrying case: ● Dell Pro Hybrid Briefcase Backpack 15 - PO1521HB Dock: Dell Thunderbolt 4 Dock - WD22TB4 Mouse: Dell Mobile Pro Wireless Mice - MS5120W... -
Page 42: Security
SW and Drivers MUP/DUP compliant per spec Agile S01310 Dell Power Manager 3.0 or later version (DPM) Dell Command | Configure 4.0 or later (DCC) with Remote BIOS configuration Dell Command | Monitor 10.0 or later (DCM) Dell Command | Update 3.0 or later (DCU) -
Page 43: Fingerprint Reader
Dell ControlVault HW protected and encrypted Match on chip FIPS 201 certified Dell ControlVault 3.0 The following table lists the Dell ControlVault 3.0 specifications of your Precision 3581. Table 53. Dell ControlVault 3.0 specifications Title Description Dell ControlVault 3.0... -
Page 44: Thermal And Acoustic Improvements
Dell Client Command Suite. In-Band management meaning that the Operating System is functional and the device is connected to a network so that it can be managed. The Dell Client Command Suite of tools can be leveraged individually or with a systems management console like SCCM, LANDESK, KACE, etc. -
Page 45: Out Of Band Systems Management
Dell Command | vPro Out of Band console extends hardware management to systems that are offline or have an un- reachable OS (Dell exclusive features). Dell Command | Integration Suite for System Center - This suite integrates all the key components of the Client Command Suite into Microsoft System Center Configuration Manager 2012 and Current Branch versions. -
Page 46: Chapter 4: Comfortview Plus
ComfortView Plus WARNING: Prolonged exposure to blue light from the display may lead to long-term effects such as eye strain, eye fatigue, or damage to the eyes. Blue light is a color in the light spectrum which has a short wavelength and high energy. Chronic exposure to blue light, particularly from digital sources, may disrupt sleep patterns and cause long-term effects such as eye strain, eye fatigue, or damage to the eyes. -
Page 47: Chapter 5: Using The Privacy Shutter
Using the privacy shutter 1. Slide the privacy shutter to the left to access the camera lens. 2. Slide the privacy shutter to the right to cover the camera lens. Using the privacy shutter... -
Page 48: Chapter 6: Dell Optimizer
Dell Optimizer This section provides the Dell Optimizer specifications of your Precision 3581. On Precision 3581 with Dell Optimizer, the following features are supported: ● ExpressConnect—Automatically joins the access point with the strongest signal, and directs bandwidth to conferencing applications when in use. -
Page 49: Chapter 7: Color, Material, And Finish
Color, material, and finish This section details the color, material, and finish (CMF) specifications of your Precision 3581. Table 56. CMF specifications A Cover (Top) ● Carbon Fiber Reinforced Plastic (CFRP) + Bi-Injection Antenna Cover ● Titan Gray Waterborne UV Monocoat (WUVM) ●... -
Page 50: Chapter 8: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 57. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app... - Page 51 Ovaj dokument je originalno proizveden i objavljen od strane proizvođača, brenda Dell, i preuzet je sa njihove zvanične stranice. S obzirom na ovu činjenicu, Tehnoteka ističe da ne preuzima odgovornost za tačnost, celovitost ili pouzdanost informacija, podataka, mišljenja, saveta ili izjava sadržanih u ovom dokumentu.
