Stanley TLH-120F Installation Manual

GENERAL DISCLAIMER
General Disclaimer
is damaged or missing. In the event that replacement parts or hardware are
Disclaimer – Suncraft Solutions Inc. has extended every effort to ensure to accuracy
needed, please contact Customer Service at 1-855-816-6868 or service
and completeness of this manual. However, Suncraft Solutions Inc. does not claim
that the information covers all installation, situational or operational variables. The @suncraftsolutions.com . International customers needing assistance should
information contained in this document is subject to change without notice or contact the Dealer from which they purchased the product.
obligation of notification of any kind. Regarding the information contained herein,
The included hardware is designed for use on vertical walls constructed of wood
Suncraft Solutions Inc. makes no representation of warranty, expressed or implied,
and assumes no responsibility for accuracy, sufficiency, or completeness of the studs or solid concrete. A wood stud wall is defined as consisting of a minimum
information contained in this document. of 2x4 wooden studs (1.5" wide by 3.5" deep 51 x 102 mm) with a maximum of
5/8" (16 mm) drywall. The included hardware is not designed for use with metal
studs or cinderblock walls. If you are uncertain or unknowledgeable about the
WARNING: FAILURE TO READ, THOROUGHLY UNDERSTAND, AND FOLLOW
construction of your wall, then please consult a qualified contractor or professional
ALL INSTRUCTIONS CAN RESULT IN SERIOUS PERSONAL INJURY, DAMAGE
TO PERSONAL PROPERTY, OR VOIDING OF LIMITED WARRANTY! installer for assistance. The wall you are mounting to must support 4 times the
weight of the total load. The load is defined as the TV and Mount along with
anything else suspended from the mount. If not, then the surface must be
It is the responsibility of the installer of this product to ensure all components are
reinforced to meet this standard. The installer is responsible for verifying that the
properly assembled and installed using the instructions provided. If you do not
understand these instructions or have any questions or concerns, please contact wall structure and hardware used in any installation method will safely support
customer service at 1-855-816-6868 or service@suncraftsolutions.com. Do not the total load.
attempt to install or assemble this product if the product or hardware
11
TV Mount Installation Guide
Thank you for choosing Stanley – the hardware of choice
for Architects, Contractors, and Home Owners for its quality,
performance and dependability.
Enclosed are your step-by-step instructions for an install
made easy.
If you get stuck, give customer service a call at 1-855-816-6868
You can also reach us at contact@suncraftsolutions.com
www.stanleytvmounts.com
Model : TLH-120F
A
