Model : TLX-350FM
TV Mount Installation Guide
Thank you f
Thank you for choosing Stanley – the hardware of choice
for Architect
for Architects, Contractors, and Home Owners for its quality,
performance
performance and dependability.
Following is
Following is your step-by-step instructions for an install
made easy.
made easy.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Stanley TLX-350FM
Summary of Contents for Stanley TLX-350FM
- Page 1 Model : TLX-350FM TV Mount Installation Guide Thank you for choosing Stanley – the hardware of choice Thank you f for Architects, Contractors, and Home Owners for its quality, for Architect performance and dependability. performance Following is your step-by-step instructions for an install Following is made easy.
-
Page 2: Getting Started
Caution: Please read the entire manual before proceeding View warranty and disclaimer on page 16 Getting Started Before we start lets make sure we have the correct mount and all the required tools and hardware to complete the installation. The TV is a Flat Panel TV is between 32” - 55” and weighs no more than 60lbs. The Wall the TV will be mounted on is either concrete or dry wall with wood studs. -
Page 3: Parts & Hardware
Caution: This product contains small items that could be a choking hazard if swallowed. Parts & Hardware Caution: Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts or previously used parts! VESA plate Wall mount... - Page 4 Step 1: Preparation 1 Check what screw size will fit in your TV. (B1,C1,D1,C3,D2) M5x14 (x4) M6x14 (x4) M8x20 (x4) M6x30 (x4) M8x30 (x4) Note: If Your TV has a curved back you may need to use longer screws with spacers ( F1,F2).
- Page 5 Step 2: VESA plate configuration For 200 x 200 / 100 x 100 For 400 x 200 Check screw hole pattern at back of TV, and configure VESA plate accordingly. For 400 x 400 / 300 x 300 Tool Required: Screwdriver...
- Page 6 Step 3: Attach TV to Mounting Plate Then attach the VESA plate B1/C1/D1 C3/D1/D2 prepared in Step 2 onto the back of TV using the G1/G3 appropriate hardware. D1/C3/D2 Caution: Hand tighten with screwdriver only, over tightening may damage the B1/C1/D1 Do not use an electric drill for this step!
- Page 7 Step 4A: Install Wall Plate on Drywall with Wood Stud Note : For Concrete Skip to Step 3B Use a stud finder to locate 1 stud. Then draw a vertical line to mark the center of the stud. Level the wall mount and align it with the center of the studs.
- Page 8 Remove the Wall plate and drill pilot holes with a 3/16” drill bit. Align the wall plate with the pilot holes and insert 3 bolts through the washer in the pilot holes and tighten. Note: Use bubble level to level the mount before fully tightening all screws.
- Page 9 Step 4B: Install Wall Plate on Concrete Level the wall mount and make 5 marks with pencil to show where to drill the pilot holes. Remove the wall mount and drill the pilot holes with a 3/8” drillbit. level Tools Required: Pencil 3/8’’...
- Page 10 3 Insert the anchors into the 5 pilot holes. Tap with a hammer. 4 Align the wall plate with the pilot holes and anchors and insert 5 bolts through the washer into the anchors and tighten. Note: Use bubble level to level the mount before fully tightening all screws Tools Required:...
- Page 11 Step 5: Install Wall Covers Snap wall rail cover（I & J） onto the wall plate. “snap” “click” Listen for a “Click” to ensure mount is locked in place...
- Page 12 Step 6: Hang Your TV Warning:Always have two people lift the TV. Lift the TV with the mounting plate and attach the mounting plate to the wall mount. Reinstall the 2 nuts that were previously removed. Tighten all 4 nuts.
- Page 13 Step 7: Install Cablemanagement 1 Make use of cable clips at under side of arms route cables to connection ports at back of TV.
- Page 14 Step 8A : Tension Adjustment Use Hex keys E to adjust the two nuts for appropriate tension for tilting TV.
- Page 15 Step 8B: Tension Adjustment 1 Push front dynamic arm to horizontal position to expose hex screw for adjustment. 2 Use Hex key（F）to adjust tension of front dynamic arm to match weight of TV. Note: for heavy TV for lighter TV...
