TV Mount Installation Guide
Thank you for choosing Stanley – the hardware of choice
for Architects, Contractors, and Home Owners for its quality,
performance and dependability.
Enclosed are your step-by-step instructions for an install made
easy.
Model: TLR-EC3215T
www.stanleymounts.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TLR-EC3215T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Stanley TLR-EC3215T

  • Page 1 Model: TLR-EC3215T TV Mount Installation Guide Thank you for choosing Stanley – the hardware of choice for Architects, Contractors, and Home Owners for its quality, performance and dependability. Enclosed are your step-by-step instructions for an install made easy. If you get stuck, give customer service a call at 1-855-816-6868 You can also reach us at contact@stanleymounts.com...
  • Page 2: Getting Started

    Caution: Please read the entire manual before proceeding View warranty and disclaimer on page 15 Getting Started Before we start lets make sure we have the correct mount and all the required tools and hardware to complete the installation. The TV is a Flat Panel TV is between 32” - 70” and weighs no more than 110lbs.
  • Page 3: Parts & Hardware

    Caution: This product contains small items that could be a choking hazard if swallowed. Parts & Hardware Caution: Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts or previously used parts! Left TV Bracket Right TV Bracket...
  • Page 4 Select TV Screws TV bracket. Flat Back Hand thread screws into the threaded inserts on the back your TV to determine which If the back of your TV is Flat Screw diameter to use. Mount the spacers A5 above the TV bracket. Determine whether your TV TV bracket.
  • Page 5 Step 1: Attach TV Bracket Caution: Hand tighten with screwdriver only, Do not use a power tool for this step! over tightening may damage the TV! Position your TV bracket over your TV hole pattern, making sure the brackets are vertically centered and TV with Flat Back TV with Irregular/Round back;...
  • Page 6 Step 2A: Install Wall Plate on Drywall with Wood Stud Note: For Concrete skip to Step 2B Use the stud nder to locate Min. 1 1/2” 2 studs, and then draw (38mm) a vertical line on the center of each stud. Min.
  • Page 7 Remove the wall plate and drill the pilot holes with a 3/16” drill bit Align the wall plate with the pilot holes and insert 4 bolts through the washer in the pilot holes and tighten. Tools Required: Drill 3/16” Drill Bit...
  • Page 8 Step 2B: Install Wall Plate on Concrete Level the wall plate and make 4 marks with pencil to show where to drill the pilot holes. Remove the wall plate and drill the pilot holes with a 3/8” drill bit. Tools Required: Pencil Level Drill...
  • Page 9 Insert the anchors into the 4 pilot holes. Tap with hammer Align wall plate with pilot holes and anchors. Insert 4 bolts through washers and anchors then tighten with wrench. Tools Required: Hammer Wrench...
  • Page 10 Step 3: Hang Your TV Warning: TV should always be lifted by 2 people. To hang your TV, clip the TV Rails to the mounted wall plate. After the TV is hanging properly on the wall mount, press on the bottom of the TV to lock it in place.
  • Page 11: Step 4 : Connect Cables

    Step 4 : Connect Cables Pull the release cords down while gently pulling the bottom of the TV from the wall. Connect the cables. “snap” “click” Push the bottom of the TV body onto wall plate till you hear a “Click” Listen for a “Click”...
  • Page 12 Usage: Magnet Tabs Attach the magnet tabs hanging from the TV Mount to the frame of the TV Mount.
  • Page 13 Usage: Tilt Tilt TV up or down to achieve the best angle of view. No tools required. Your Stanley TV mount has been preset at a perfect tension to easily tilt most TVs. If you need to adjust the tilt tension, tighten or...
  • Page 14: Removing The Tv

    Removing the TV Warning: TV should always be lifted by 2 people. Disconnect all cables from the TV. Pull both release cords down to unlock the TV from the wall plat e. Pull bottom of TV from wall, allow enough space to lift TV up and off wall plate.
  • Page 15 SUNCRAFT SOLUTIONS INC. LIMITED WARRANTY SUNCRAFT SOLUTIONS INC. LIMITED WARRANTY SUNCRAFT SOLUTIONS, INC. warrants its products to be free of defects in material and for a particular purpose and warranties of merchantability. SUNCRAFT SOLUTIONS, INC. will not workmanship for the product’s Warranty Period. The Warranty Period commences on the original be liable for any damages whatsoever arising out of the use or inability to use its products, even if purchase date of the product and the sales receipt serves as proof of purchase.
  • Page 16: General Disclaimer

    GENERAL DISCLAIMER General Disclaimer Disclaimer – Suncraft Solutions Inc. has extended every effort to ensure the accuracy and is damaged or missing. In the event that replacement parts or hardware are needed, please contact completeness of this manual. However, Suncraft Solutions Inc. does not claim that the information Customer Service at 1-855-816-6868 or service@suncraftsolutions.com .
