  • Page 1 User's Manual Stork Vitals+ Smart Home Baby Monitor...
  • Page 3 Masimo® and ® are federally registered trademarks of Masimo Corporation. Stork™ is a trademark of Masimo Corporation. Google Play and the Google Play logo are trademarks of Google LLC. App Store and App Store logo are registered trademarks of Apple Inc. The Bluetooth word mark and logo are registered trademarks owned by Bluetooth SIG, Inc.

  • Page 5: Table Of Contents

    Live Controls ................... 27 Side Menu ....................28 Bottom Menu ................... 30 How to Turn Stork On and Off ............... 31 Troubleshooting ..................31 Appendix ....................35 Safety Information..................35 Specifications ..................40 Service and Maintenance ................55 Masimo Corporation www.masimo.com...

  • Page 7: About This Manual

    Watch the videos in your app to find out more about: • Setting up your Stork System. • Connecting your Stork Camera to Bluetooth and Wi-Fi. • Stork Sensor pairing. • Placing sensor in the Stork Boot and boot placement. Masimo Corporation www.masimo.com...

  • Page 8: Glossary

    A parameter is an element of a system that is critical in evaluating the system’s Parameter: condition. Perfusion: The bodily process of delivering blood to the capillary beds. The number of times a heart beats in a minute. Pulse Rate: Masimo Corporation www.masimo.com...

  • Page 9: Product Description

    Masimo Stork™ is a smart home baby monitoring system designed for parents to track health data for a healthy baby at home. Masimo Stork Vitals+ consists of a sensor, boot, camera, cloud, and app, which combine to allow parents to stay connected with their baby via video, 2-way audio, and continuous health data on the app.

  • Page 10: Meet The Stork System

    Stork Sensor 5W AC power adapter • Stork Camera 12W AC power adapter • Stork Sensor charge cable and cable clip • Stork Camera power cable and cable covers • Stork Camera wall mounting bracket (and hardware) Masimo Corporation www.masimo.com...

  • Page 11: Components Of Stork

    Located on the bottom of the camera. Power is provided by the AC adapter and the power cable. The cable is routed through the opening in camera base. A hole to access the factory reset button is located on the bottom of the camera. Note: Masimo Corporation www.masimo.com...
  • Page 12 Sensor Sta tus Light Displays the sensor status. See on page 41. Light 5 Charging Charge the sensor battery using the charging cable and AC power Contacts C ha rging the Stork Sensor adapter. See on page 18. Masimo Corporation www.masimo.com...
  • Page 13 Do not use the boot if it appears to be damaged. Damage to the boot may result in poor performance and/or injury. 1 Stork Boot Secures the Stork Sensor to the baby's foot. 2 Strap Attaches to the boot. 3 Stork Sensor Pocket The sensor is placed into this pocket. Masimo Corporation www.masimo.com...

  • Page 15: Basic Setup And Use Of Stork

    • Smart phone battery is charged • Bluetooth is ON • Wi-Fi is ON and the smart phone in connected to the internet • Time is set to the current local time Masimo Corporation www.masimo.com...

  • Page 16: Step 2: Setting Up The Stork System

    28 to connect Stork devices. • Connect the Stork Camera to the app and local Wi-Fi network, and set up the camera viewing location. • Charge the Stork Sensor and use the app to pair the sensor. Masimo Corporation www.masimo.com...
  • Page 17 If the camera cannot connect, see Troubleshooting on page 31. 3. Next, connect to your Wi-Fi by selecting Setup Wi-Fi and follow the app instructions. Note: If requested to Share Wi-Fi Settings, select Allow. 4. Select the wireless Network and enter the Password. Select Continue. Masimo Corporation www.masimo.com...
  • Page 18 Do not place or mount the camera inside or on the edge of the crib to prevent the camera from falling on the baby or the baby pulling on the power cable. No matter the camera location, the camera can be adjusted for the perfect view of the baby. Masimo Corporation www.masimo.com...
  • Page 19 5. Hold the mounting plate against the wall. Secure the mounting plate onto the wall with the included screws. 6. Align the 4 holes on the camera base with the hooks on the mounting plate, and then slide the camera down to snap it in place. Masimo Corporation www.masimo.com...
  • Page 20 5W AC power adapter and plug the power adapter into a wall socket (B). 2. Use the peel-and-stick cable clip to secure the charge cable to a flat surface like a dresser or nightstand. Masimo Corporation www.masimo.com...
  • Page 21 If multiple devices are found, follow the app instructions to select the correct sensor Note: from a list. Note: If the Bluetooth connection fails, hold the smart phone closer to the sensor and try to Troubleshooting reconnect. If the sensor cannot connect, see on page 31. Masimo Corporation www.masimo.com...
  • Page 22 (A), use a larger boot. Strap Sizes Straps come in 4 sizes. The small and medium boots come preattached with strap sizes 3 and 4. Size 1 and 2 come in separate packaging. Masimo Corporation www.masimo.com...
  • Page 23 To remove the strap, simply slide back off. 2. Insert the sensor into the boot at an angle, toe end first, with the Masimo logo facing down. 3. Press down to secure the sensor. The sensor should sit flush in the boot.
  • Page 24 4. The strap at the ankle strap should be snug but not tight. The sensor strap should sit flush against the top of the foot, with no gap. Using excessive force when removing the boot CAUTION: may damage it. Masimo Corporation www.masimo.com...

  • Page 25: Step 3: View Live Data

    6 Health Data Dashboard - Swipe up to view Hea lth Da ta health data readings. See Da shboa rd on page 24. 7 Bottom Menu - Shortcuts to additional app Bottom Menu functions and features. See page 29. Masimo Corporation www.masimo.com...
  • Page 26 It is important to make sure your sensor is properly applied. The following items on the Data Dashboard can help identify good sensor placement: • Oxygen saturation is displayed • Pulse Rate is displayed • Temperature is displayed Masimo Corporation www.masimo.com...

  • Page 27: Advanced Use

    All notifications - Select More in the upper right corner of the screen. Select Ma rk a ll a s rea d to acknowledge all notifications or select Delete a ll to delete all notifications. Masimo Corporation www.masimo.com...

  • Page 28: Sensor Battery Charge Status

    • The Stork Sensor battery is low (low priority notification) or depleted (medium priority notification). • The Masimo Cloud server is disconnected from the Stork System. • The ambient room temperature is too low.* Examples of high priority notifications: •...

  • Page 29: Live Controls

    When selected, a photo button appears at the bottom of the live feed to take a picture. The picture is saved to the smart phone. Lullaby Player Lullaby music can be played over the Stork Camera speaker. When selected, controls to play and pause the lullaby displays. Masimo Corporation www.masimo.com...

  • Page 30: Side Menu

    Device Management Devices screen displays all connected Stork devices and their current connection status. From this screen you can also view detailed connected device information, remove connected devices or add additional Stork devices from this screen. Masimo Corporation www.masimo.com...
  • Page 31 Swipe left on the invitation and select to cancel or resend the invitation. • Private Mode can be enabled to stop sharing health data with caregivers at anytime, without revoking a caregivers access. See Live Controls on page 27. Masimo Corporation www.masimo.com...

  • Page 32: Bottom Menu

    Select the baby's name to see live health data as well as access history data. Sharing Reject invitation - Select Deny on the invitation from the screen. Masimo Corporation www.masimo.com...

  • Page 33: How To Turn Stork On And Off

    Boot and the Boot is properly placed on the foot. • If you still experience issues, please contact Masimo Customer Support. See Customer Support on page 55. "Replace your sensor" Sensor is not working. Replace sensor.
  • Page 34 • Update the smart phone software. Refer to the smart • Smart phone does not phone's Operator's Manual or Directions For Use. support Bluetooth Low • Contact Masimo Customer Support. See Customer Support Energy (BLE). on page 55. Stork Camera •...
  • Page 35 • Incorrect user logged into • Ensure correct user is logged into the app. the app. • Contact Masimo Customer Support. See Customer Support • Stork Camera has been on page 55. registered with another account.

  • Page 37: Appendix

    To avoid skin injury, consider alternating feet after it has been used for more than 12 hrs. WARNING: Only use Masimo authorized devices with Stork. Using unauthorized devices with Stork may result in damage to the device and/or patient injury. CAUTION: Only use the AC power supply and cable included with your Stork Sensor to prevent damage to the device.
  • Page 38 Clinicians should consider additional information to supplement values to completely understand the patient’s condition. WARNING: Only use Masimo-approved parts with Stork to make sure the device works correctly. CAUTION: Avoid using Stork Sensor under bright light sources and direct sunlight to maintain the performance of the device.
  • Page 39 When using with a smart phone, keep both devices within the recommended Spec ific a tions range of each other. See on page 40 for details. Moving outside of this range may cause a loss in connection. Masimo Corporation www.masimo.com...
  • Page 40 Smart phone should be located with the responsible users. • Smart phone should not be left unattended. • Security features on smart phone should be activated. • Unauthorized changes should not be made to the Stork system. Masimo Corporation www.masimo.com...
  • Page 41 Radio Compliance WARNING: Changes or modifications not approved by Masimo can void the user’s authority to operate the equipment. WARNING: The frequency bands of this device (2.4 GHz and 5.15 to 5.25 GHz) are only for indoor use in accordance with international telecommunication requirements.

  • Page 42: Specifications

    Unit of Measure Oxygen Level (SpO 0 to 100 Pulse Rate (PR) 25 to 240 Temperature 77.0 to 109.4 (25.0 to 43.0) °F (°C) Ambient Temperature 59 to 113 (15 to 45) °F (°C) Ambient Humidity 10 to 100 Masimo Corporation www.masimo.com...
  • Page 43 25 bpm to 240 bpm 1 bpm The emitted wavelengths range from 600 nm to 1000 nm and the peak optical power is less than 15 mW. Information about the wavelength range can be especially useful to clinicians. Masimo Corporation www.masimo.com...
  • Page 44 The tables below provide the (Accuracy Root Mean Square) values for the Stork as compared to Masimo RD SET Adhesive sensors under no motion clinical testing. A total of 30 subjects, 14 dark skinned and 16 light skinned, were tested.
  • Page 45 Stork Vitals+ Appendix The below Bland-Altman plot represents the distribution of points in the difference between the Masimo Stork and the RD SET Adhesive reference (SpO – SpO ) versus the reference 2Ref (SpO ) under no motion with an upper 95% and lower 95% limits of agreement.
  • Page 46 Stork provides a surface temperature of the skin where the Stork Sensor is applied. The displayed temperature may require time to equilibrate after initial application (up to 7 minutes). Accuracy Temperature Laboratory 25°C to 43°C (77°F to 109.4°F) ±0.3°C (±0.54 °F) Application Site Foot Masimo Corporation www.masimo.com...
  • Page 47 Output Power Type Fixed at the Factory Modulation Types GFSK Modulation Signals Analog and Digital Available Data Rates 1 Mbps Recommended Max. Range 100 ft (~30 meters) line-of-sight Radio Compliance - Stork Sensor FCC ID: VKF-STORK Canada IC: 7362A-STORK Masimo Corporation www.masimo.com...
  • Page 48 Surge +/-1 kV line(s) +/-1 kV line(s) to Mains power quality should be that of a typical IEC 61000-4-5 to line(s) line(s) commercial or hospital environment. Conducted RF 3 Vrms 3 Vrms Performed over 0.15-80 MHz Masimo Corporation www.masimo.com...
  • Page 49 RF compliance level above, the ME Equipment should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the ME Equipment. : Rated voltage for the equipment. Masimo Corporation www.masimo.com...
  • Page 50 The carrier shall be modulated use a 50% duty cycle square wave signal. As an alternative to FM modulation, 50% pulse modulation at 18 Hz may be used because while it does not represent actual modulation, it would be worst case. Masimo Corporation www.masimo.com...
  • Page 51 The sensor is not actively monitoring. Solid White The sensor is actively monitoring with a successful connection to the Masimo Cloud. Blinking Green The camera is ready for pairing to the smart phone/Stork app or to be connected to the wireless network.
  • Page 52 Output Power Type Fixed at the Factory Modulation Types DH5, 2DH5, 3DH5 Modulation Signals Analog and Digital Available Data Rates 1, 2, 3 Mbps Communication (Bluetooth LE) - Stork Camera Type Bluetooth LE 5.0 Frequency 2402-2480 MHz Masimo Corporation www.masimo.com...
  • Page 53 Security and Authentication - Stork Camera Encryption 64/128-bit WEP, Dynamic WEP, WPA-TKIP, WPA2-AES Authentication Open System, Shared Key, Pre-Shared Key (PSK), 802.1X: LEAP, PEAP, TTLS, TLS, EAP-FAST Radio Compliance - Stork Camera FCC ID: VKF-STORKC Canada IC: 7362A-STORKC Masimo Corporation www.masimo.com...
  • Page 54 IP44 - Protection from solid bodies larger than 1 millimeter and protection and Particulate Matter against small splashes of water coming from all directions. Mode of Operation Continuous EMC Compliance - Stork Camera FCC 15B, Class B (Emissions) Safety Standards Compliance IEC 62368-1 Masimo Corporation www.masimo.com...
  • Page 55 Caution material Date of manufacture Warning YYYY-MM-DD Manufacturer Catalog number (model number) Serial number Masimo reference number Storage temperature range AC current Keep dry Do not use if package is damaged Storage humidity limitation Wireless Symbol level Atmospheric pressure limitation Masimo Corporation www.masimo.com...
  • Page 56 Biotek Index 2 simulator with signal strengths as low as 0.02% for the simulated saturation range of 70% to 100%. [4] The Masimo SET Technology has been validated for pulse rate accuracy for the range of 25-240 bpm in bench top testing against a Biotek Index 2 simulator and Masimo’s simulator with signal strengths of greater than 0.02%.

  • Page 57: Service And Maintenance

    Customer Support For product support, along with troubleshooting for your Stork product, please go to the Stork Support page www.masimostork.com/en-us/support/contact-us.html. For warranty information for your Stork product, please go to the Stork warranty page www.masimostork.com/en-us/support/warranty.html. Masimo Corporation www.masimo.com...
  • Page 60 304200/LAB-11858A-0623...
