Xerox Phaser 7750 Network Manual

Xerox phaser 7750: network guide
Hide thumbs Also See for Phaser 7750:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual See also: Service Manual, Reference Manual

Connections and IP Address

This topic includes:
■
"Printer Setup" on page 3-2
■
"Connection Setup" on page 3-6

Printer Setup

The information in this section is also stored as an information page in your printer.
Use the front panel to quickly print this information in the future.
Ethernet Connection (Recommended)
An Ethernet connection is recommended because it is faster than a USB cable connection. It
also allows the user direct access to CentreWare IS.
Network Connection
Use an Ethernet connection with two twisted-pair (Category 5/RJ-45) cables and an Ethernet
hub. Connect the computer to the hub with one cable, then connect the printer to the hub with
the second cable. Connect to any port on the hub except the uplink port. TCP/IP and EtherTalk
are the most common protocols used with Ethernet cables. To print using TCP/IP, each
computer and printer requires a unique IP address. Go to "Setting an IP Address" in this
section.
Standalone (Cable or DSL) Network Connection
For information about setting up a cable or DSL connection for your printer, go to
www.xerox.com/office/infoSMART
Tutorial and Home Networking Guidelines.
Setting an IP Address
If your computer is on a large network, contact your network administrator for the appropriate
TCP/IP addresses and additional configuration information.
If you are creating your own small Local Area Network or connecting the printer directly to
your computer over Ethernet, follow the procedure for automatically setting the printer's IP
address.
The printer and computer(s) must have unique IP addresses. It is important that the addresses
are similar, but not the same. For example, your printer can have the address 192.168.1.2 while
your computer has the address 192.168.1.3. Another device can have the address 192.168.1.4.
For more information, go to
Copyright © 2004 Xerox Corporation. All Rights Reserved.
to view Document # 33188, entitled Basic TCP/IP
www.xerox.com/office/infoSMART
3-2
Phaser® 7750 Color Laser Printer
to view Document # 18545.

Advertisement

loading

Related Manuals for Xerox Phaser 7750

Summary of Contents for Xerox Phaser 7750

  • Page 1: Connections And Ip Address

    Use an Ethernet connection with two twisted-pair (Category 5/RJ-45) cables and an Ethernet hub. Connect the computer to the hub with one cable, then connect the printer to the hub with the second cable. Connect to any port on the hub except the uplink port. TCP/IP and EtherTalk are the most common protocols used with Ethernet cables.
  • Page 2 Automatically Setting the Printer’s IP Address Use the Phaser installer on the Printer Installer and Utilities CD-ROM to detect and/or assign an IP address to your printer. For further instructions, insert the Printer Installer and Utilities CD-ROM into your computer’s CD-ROM, launch the installer, then follow the prompts for installation.
  • Page 3 USB Connection The USB connection requires a standard USB cable. This cable is not included with your printer and must be purchased separately. Verify that you are using the correct USB cable for your connection. Windows 98 or Later and Windows 2000 or Later Connect the USB cable to the PC and follow the Add New Hardware Wizard to create the USB port.
  • Page 4 Select the printer in the printers window. Verify that your printer is set to Auto Select. Click the Add button. The printer is displayed as an available printer in the Print Center. For more information, go www.xerox.com/office/infoSMART Phaser® 7750 Color Laser Printer Connections and IP Address to view Document # 49355.

  • Page 5: Connection Setup

    Double-click the installer on the Printer Installer and Utilities CD-ROM to install the printer driver. Open the Chooser, then click the LaserWriter driver. From the right column of the Chooser, select the printer, then click Create to create the desktop printer. For more information go to www.xerox.com/office/infoSMART...

  • Page 6: Printer Identification

    # 50080, and # 49814. Dynamic Methods of Setting the Printer’s IP Address An Internet Protocol (IP) address is required to identify your printer on a network. Set the printer’s IP address by any of the following methods: ■...
  • Page 7 To use an IP host name for the printer, the system administrator must configure one or more DNS servers and a local DNS domain name space database. To set up the printer for DNS, supply a maximum of two DNS name server IP addresses. There are two ways to set up the printer: ■...
  • Page 8 ■ DDNS - Set to ON. ■ Release Host Name - Set to NO. ■ DDNS/WINS Name - Use the default name provided by Xerox or enter another name. ■ Primary WINS Server (optional) ■ Secondary WINS Server (optional) Click Save Changes when you are finished entering the settings.
