ARCHITECTURAL INDOOR LED EMERGENCY LIGHT
INSTALLATION AND OPERATING INSTRUCTION
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including
the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. Install in accordance with all national and local electrical codes.
2. Disconnect power at circuit breaker or fuse before installing or servicing the unit.
3. DO NOT mount in hazardous locations, near gas or near electric heaters.
4. DO NOT let power cords contact hot surfaces.
5. Equipment should be mounted in locations and at heights where it will not be readily subject
to tampering by unauthorized personnel.
6. DO NOT use accessory equipment not recommended by the manufacturer. The use of such
equipment may cause unsafe condition and will void the unit's warranty.
7. DO NOT use this equipment for other than it's intended purpose.
8. All servicing should be performed by qualified personnel only.
9. Allow battery to charge for 24 hours before first use.
10. For indoor use only.
AIR SERIES
SAVE THESE INSTRUCTIONS
31 Waterloo Ave • Berwyn, PA • 19312 U.S.A
Telephone: (610) 647-8200 • Email: support@isolite.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Isolite AIR Series
Summary of Contents for Isolite AIR Series
- Page 1 8. All servicing should be performed by qualified personnel only. 9. Allow battery to charge for 24 hours before first use. 10. For indoor use only. SAVE THESE INSTRUCTIONS 31 Waterloo Ave • Berwyn, PA • 19312 U.S.A Telephone: (610) 647-8200 • Email: support@isolite.com...
-
Page 2: Maintenance
SECTION 1: BASIC FUNCTIONALITY & FEATURES Open enclosure using flat blade screw driver to access knockouts. ROTATE & ANGLE LED ARRAY HEADS TEST SWITCH/STATUS INDICATOR REAR PANEL RELEASE TABS 2 ISOLITE WWW.ISOLITE.COM REV-1 20230629... -
Page 3: Installation Instructions
[figure] a. When snapping the unit together, ensure that the plug and mating connector are aligned so that the unit receives power. 7. Adjust the lamp heads down and outward for the designed emergency illumination. ISOLITE WWW.ISOLITE.COM REV-1 20230629... -
Page 4: Wiring Instructions
When installing remote lamps, ensure that adequate space is provided between the line voltage wires and the remote lamp wires [FIGURE]. Always wire the devices in accordance with local and national electrical codes. 4 ISOLITE WWW.ISOLITE.COM REV-1 20230629... -
Page 5: Mounting Instructions
If the battery charge is insufficient, the 30 second functional test will be performed instead. NOTE: The lamp current will be calculated upon the running of the first self-diagnostic test. Subsequent self-diagnostics checks will verify the lamp current against the initial measurement. ISOLITE WWW.ISOLITE.COM REV-1 20230629... -
Page 6: Status Indications
Failure indications can be cleared by correcting the indicated fault and pushing and holding the “TEST” Switch for 1 second. STATUS INDICATIONS Status indications for the self-testing / self-diagnostic system are shown on the following page. 6 ISOLITE WWW.ISOLITE.COM REV-1 20230629... -
Page 7: Status Indicators
To reset the lamp failure status, remove the unit from the wall, disconnect the battery, wait 30 seconds, reconnect the battery, reinstall the unit onto the mounting plate. The lamp current calculation will be performed on the next function test. ISOLITE WWW.ISOLITE.COM REV-1 20230629... - Page 8 SAVE THESE INSTRUCTIONS 31 Waterloo Ave • Berwyn, PA • 19312 U.S.A Telephone: (610) 647-8200 • Email: support@isolite.com...
