Page 1 CIRRUS PERSPECTIVE TOUCH + Cockpit Reference Guide Cirrus SR2x System Software Version 3956.Q2 or later...
Page 3 FLIGHT INSTRUMENTS ENGINE & AIRFRAME SySTEMS (EAS) AUDIO AND CNS FLIGHT MANAGEMENT SySTEM HAZARD AVOIDANCE AUTOMATIC FLIGHT CONTROL SySTEM ADDITIONAL FEATURES ABNORMAL OPERATIONS ANNUNCIATIONS & ALERTS APPENDIX INDEX...
Page 5 Garmin, G2000, GDL, FliteCharts, Connext, SafeTaxi, flyGarmin, and flyGarmin.com are registered trademarks of Garmin International, Inc. or its subsidiaries. Autonomí, ChartView, GDU, GEA, GFC 700, GMA, GTX, Garmin ESP, Garmin SVT, Garmin Pilot, Flight Stream, Smart Airspace, SurfaceWatch, and WireAware are trademarks of Garmin International, Inc.
Page 6 Bluetooth SIG, Inc. and any use of such marks by Garmin is under license. iOS is a registered trademark of Cisco in the US and is used by Apple under license. Android is a trademark of Google LLC.
Page 7 WARNING: Do not use terrain avoidance displays as the sole source of information for maintaining separation from terrain and obstacles. Garmin obtains terrain and obstacle data from third party sources and cannot independently verify the accuracy of the information.
Page 8 WARNING: Do not use the Garmin SVT runway depiction as the sole means for determining the proximity of the aircraft to the runway or for maintaining the proper approach path angle during landing.
Page 9 NOTE: Do not rely solely upon data link services to provide Temporary Flight Restric- tion (TFR) information. Always confirm TFR information through official sources such as Flight Service Stations or Air Traffic Control. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 10 Navigation Database. Differences in system operation may be observed among similar types of procedures due to differences in the Navigation Database coding specific to each procedure. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 11 Warnings, Cautions & Notes NOTE: The FAA has asked Garmin to remind pilots who fly with Garmin database- dependent avionics of the following: • It is the pilot’s responsibility to remain familiar with all FAA regulatory and advisory guidance and information related to the use of databases in the National Airspace System.
Page 12 NOTE: Intruder aircraft at or below 500 ft. AGL may not appear on the Garmin SVT display or may appear as a partial symbol. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 13 It is not intended to be a comprehensive operating guide. Complete operating procedures for the system are found in the Pilot’s Guide for this aircraft. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 14 Warnings, Cautions & Notes Blank Page Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 15 Software remain with Garmin and/or its third-party providers. You acknowledge the Software is the property of Garmin and/or its third-party providers and is protected under the United States of America copyright laws and international copyright treaties. You further acknowledge the structure,...
Page 16 Software License Agreement Blank Page Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 17 Sep, 2022 Initial Release for GDU 32.01.10 190-02954-01 Dec, 2023 Initial Release for GDU 32.01.30 Production Revision - Updated Warnings/Cautions/ Advisories - Updated content and images 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 18 Record of Revisions Blank Page Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 19: Table Of Contents
COM Transceiver Selection and Activation ................23 COM Frequency Tuning ......................23 NAV OPERATION ......................... 26 MODE S TRANSPONDERS ......................29 ADDITIONAL AUDIO FUNCTIONS .................... 30 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 20 Approaches ..........................88 WEIGHT AND BALANCE ......................97 GENERAL PERFORMANCE AND TRIP PLANNING ..............98 Datalink Weather for Performance Estimates ............... 98 Trip Planning ..........................98 Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 21 OVERVIEW ..........................143 Basic Autopilot Operation ..................... 143 AFCS Preflight Test (PFT) ......................143 FLIGHT DIRECTOR OPERATION ....................144 Activating the Flight Director ....................144 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 22 ELECTRONIC DOCUMENTS ..................... 176 AUXILIARy VIDEO (EVS) ......................178 STABILIZED APPROACH ......................178 ELECTRONIC STABILITy & PROTECTION (ESP) (OPTIONAL) ........... 179 DATABASE MANAGEMENT ..................... 179 Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 23 ANNUNCIATIONS AND ALERTS ................ 195 SySTEM ANNUNCIATIONS ...................... 195 CREW PROFILE IMPORT/EXPORT MESSAGES ..............196 Comparator Annunciations ....................197 Reversionary Sensor Annunciations ..................198 AIRSPACES ..........................198 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 24 TOUCHSCREEN CONTROLLER SCREENS ................252 MFW Mode Touchscreen Controller Screens ............... 254 Touchscreen Controller Screens ..............267 PFD SOFTKEyS ........................... 272 Screen Cleaning ........................285 Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 25 ........................... 272 Screen Cleaning ........................285 MAP SyMBOLS .......................... 285 PFW Navigation Status Box / MFW Navigation Data Bar ..........285 Land Symbols .......................... 285 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 26 PFW Navigation Status Box / MFW Navigation Data Bar ..........285 Land Symbols .......................... 285 Aviation Symbols ........................286 Additional Map Display Items ....................289 FLIGHT PLANNING ........................290 INDEX ........................Index-1 viii Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 27: Flight Instruments
Touch the General , Takeoff , or Landing Tab. To enable all Vspeed bugs, touch the All On Button. To disable all Vspeed, touch the All Off Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 28: Altimeter
3) Press the Altitude Units Softkey 4) Press the Meters Softkey to display the meters overlay. Press again to disable the overlay. 5) When finished, touch the Back Button. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 29: Horizontal Situation Indicator (Hsi)
HORIZONTAL SITUATION INDICATOR (HSI) Changing the HSI Display Format: From PFW Home, touch PFD Map Settings . 2) Touch the Layout Button. 3) Touch the HSI Map Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 30: Course Deviation Indicator (Cdi)
2) Press the Active NAV Softkey again to change from VOR1/LOC1 to VOR2/LOC2. 3) Press the Active NAV Softkey a third time to return to GPS. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 31: Required Navigation Performance And Estimated Position Error
2) Press the Other PFD Settings Softkey. 3) Press the AOA Softkey to cycle through the different modes ( On , Off , or Auto). 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 32: Garmin Svt™ (Synthetic Vision Technology)
3) Scroll and touch the Field of View Button to enable/disable field of view display. SUPPLEMENTAL FLIGHT DATA WIND DATA Displaying Wind Data: 1) From PFW Home, touch PFD Settings > Wind . Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 33: Timer
5) Enter the MDA/DH altitude using the keypad or the large/small upper knob. When finished, touch the Enter Button or push the small upper knob. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 34 Flight Instruments Blank Page Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 35: Engine And Airframe Systems
Engine & Airframe Systems ENGINE AND AIRFRAME SySTEMS ENGINE/AIRFRAME SySTEMS INDICATIONS EIS Display (SR22) 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 36 Engine & Airframe Systems EIS Display (SR22T) Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 37 Engine & Airframe Systems EIS Display (SR20) 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 38 Displays the left and right Turbo Inlet Temperatures in degrees Fahrenheit. Cylinder Head Displays the head temperature of the hottest and coldest cylinder. Temperature (CHT) Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 39 Flap Position Flap Positions Actual Flap Position Commanded Flap Position Box - Caution Flap Positions Invalid Flap Indication Invalid Flap Position Box - Amber X 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 40 Displays Oxygen Pressure in Pounds per Square Inch (PSI). If the oxygen system is on then the word “ON” will be displayed in a Cyan Box. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 41: Aircraft Systems
Refer to the specific synoptic sections for more information. Aircraft systems depicted in the synoptic diagrams include: • Ice Protection (if equipped) • Status & Information • Electrical • Video (if equipped) • Engine & Fuel 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 42: Status & Info
Flight ID Air Data and Weight Landing/ Takeoff Performance Aircraft Hours Display Parking Status Brake Position Baggage Cabin Door Door Status Status Status and Info Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 43: Engine & Fuel
Fuel Valve Total Fuel Selected And Quantity Mode Right Tank Left Tank Fuel Quantity Fuel Quantity Fuel Fuel Used Economy And Range Remaining Fuel Synoptics (SR22T) 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 44: Electrical
Red objects or text/background indicates a warning state. Accessing the Electrical Synoptics: From MFW Home, touch Aircraft Systems > Electrical Power. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 45 Engine & Airframe Systems Lithium Battery Option Electrical Synoptics 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 46: Ice Protection
Pitot Heat AOA Heat Status Status IPS Valve Status Total IPS Fluid Right Left Tank Tank Total Total IPS Endur- ance Status Ice Protection Synoptics Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 47: System Tests
Once all cylinders are lean of peak, the last cylinder to peak is denoted by the “Last” annuncia- tion below its bar on the graph. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 48: Reversionary Mode
Primary Flight Display (PFD) symbology together with con- densed EIS and MFD information (refer to the System Overview for more information about Reversionary Mode). Display EIS (Reversionary Mode) Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 49: Audio And Cns
1) From NAV/COM Home, touch the Audio & Radios Button to display the ‘Audio & Radios’ Screen. 2) Touch the COM1 or COM2 Volume Slider Button to select that radio for tuning. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 50 2) If needed, touch the airport button to enter or find the desired airport. 3) Touch the Freqs Tab to display the ‘Airport Frequencies’ Screen. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 51 10) Touch the Add Favorite Button. Adding a COM frequency to favorites from any ‘Load Frequency’ Screen: 1) From any ‘Load Frequency’ Screen, touch the Add to Favorites Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 52: Nav Operation
2) Touch the NAV1/NAV2 Frequency Button to display the NAV1/NAV2 Standby Screen. 3) Touch the XFER Button or push and hold the small upper knob to transfer the frequencies. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 53 3) Touch the Find Button. 4) Touch the Favorite Tab. 5) Touch the X Button next to the frequency to be deleted. 6) Touch the OK Button to confirm. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 54 4) Touch the location button to load the frequency to NAV1 or NAV2 Active/Standby or Favorites. 5) Touch the Done Button or the Back Button to return to the ‘Nearest VOR’ Screen. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 55: Mode S Transponders
3) Touch the Enter Button or push the small upper knob to enter the new code. Pressing the Cancel Button before code entry is complete cancels code entry and restores the previous code. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 56: Additional Audio Functions
3) Touch the Mute Settings Button to display the ‘Music Mute Settings’ Screen. 4) Select the Intercom , Radio Inputs , and/or Aural Alerts Buttons to enable/disable mute SiriusXM audio. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 57 SiriusXM or other music source audio. 6) Adjust volume using the slider bar. 7) Adjust mute settings by touching the Mute Settings Button and selecting desired options. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 58 Audio and CNS Blank Page Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 59: Flight Management
1) From MFW Home, touch Map > Map Selection > Map Settings . 2) Touch the Orientation Button. 3) Touch the Heading Up , Track Up , or North Up Button to select the orientation. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 60: Map Range
3) Touch the Back Button on the Touchscreen Controller to return to the 'Map Pointer Control' Screen without removing the Map Pointer from the map. Or : Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 61: Measuring Bearing And Distance
1) Push the lower knob. (Measure Pointer functionality is not available for traffic and terrain panes.) 2) Touch the BRG/DIS Button. A Measure Pointer is displayed on the map at the aircraft’s present position. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 62: Absolute Terrain
Press the Terrain Softkey until 'Absolute' is shown to display absolute terrain data on the PFW Map. Press the Terrain Softkey until 'Off' is shown to remove absolute terrain data from the PFW Map. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 63: Map Symbols
5) Touch the Range Button to display the range choices. 6) Touch a Range Selection Button to select the maximum range. 7) Repeat Steps 3 through 6 as necessary. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 64: Additional Map Display Items
Selecting the lat/lon line maximum range: 1) From MFW Home, touch Map > Map Selection > Map Settings . 2) Touch the Other Tab, if necessary. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 65: Waypoints
Finding and selecting an airport for review by category (Recent, Nearest, Flight Plan, or Favorites): 1) From MFW Home, touch Waypoint Info > Airport . 2) Touch the Info Tab, if necessary. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 66 4) Touch the Nearest Airport Min Rwy Length Button to display the keypad. 5) Use the keypad to enter the minimum length. 6) Touch the Enter Button to accept the length criteria. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 67: Non-Airport And User Created Waypoints
6) Touch the Facility Name Button or the City Name Button to display the keypad. 7) Use the keypad to enter the name. 8) Touch the Enter Button to accept the entry and display the search results. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 68 Touch the RAD Button to display the keypad. f) Use the keypad and the Enter Button to select the radial. g) Touch the DIS Button to display the keypad. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 69 3) Touch the Create WPT Button. The 'Create User Waypoint' Screen is displayed with the captured position. 4) Touch the User Waypoint Name Button to display the keypad. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 70 5) Touch the User Waypoint Name Button to display the keypad. 6) Use the keypad and the Enter Button to select a user waypoint name. 7) Touch the Save Button to accept the new name. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 71 Touch the OK Button in response to the question "User waypoint is part of at least one flight plan. Any modifications affect the associated flight plan(s)." 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 72: Airspaces
2) Scroll as required, and touch the Airspace Alert Altitude Buffer (displays current selection in cyan). 3) Enter the desired altitude buffer value and touch the Enter Button. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 73: Smart Airspace
4) Scroll the list if necessary and touch a data field type button to select the field type and return to the 'Flight Plan Data Fields' Screen. 5) Touch the other data field button to choose another data field type, if necessary. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 74: Flight Plan Display
1) From MFW Home, touch Map > Map Selection > Map Settings . 2) Touch the Inset Window Tab. 3) Touch the Flight Plan Progress Button to display/remove the flight plan progress inset. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 75: Direct-To Navigation
Selecting any waypoint as a direct-to destination: 1) Select the screen containing the desired waypoint and select the desired waypoint. 2) If necessary, touch the Waypoint Options Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 76 'Insert and Activate ¯ <waypoint> Before?' Window. b) Touch the Waypoint Selection Button to select the flight plan location to insert the direct to waypoint, and to activate the direct-to. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 77 1) From MFW Home, touch the ¯ Button on the Button Bar to display the 'Direct To' Screen with the active flight plan waypoint selected as the direct-to destination. 2) Touch the Activate ¯ Button to activate the direct-to. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 78 2) If necessary, touch the Waypoint Selection Button to enter the waypoint as the direct-to destination. Then, touch the Course Button to display the keypad. 3) Touch the Course or Radial Button. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 79: Flight Plan Keypad Operation
2) Touch the Sliding Flight Plan Keyboard Button to enable/disable. Route Entry Route Entry Description "<entry wpt>*<airway>*<exit wpt>" Basic Airway Segment with a specified exit waypoint. "*<airway>*<exit wpt>" 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 80 "JIGSY" and exit point "FLM" into flight plan. FLM* "J24*BIGAL* Review and load J24 airway with BIGAL* entry point "FLM" and exit point "BIGAL" into flight plan. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 81: Creating A Basic Flight Plan
Touch the Flight Plan Catalog Button to display the 'Flight Plan Catalog' Screen. c) Touch the Create New Catalog Flight Plan Button to display the 'Edit Stored Flight Plan' Screen. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 82 Touch the Select Arrival Runway Button to display the 'Select Runway' Screen. Touch a Runway Selection Button to select the destination runway and return to the flight plan. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 83: Flight Plan Modification And Navigation
'Flight Plan Catalog' Screen. b) Scroll the list if needed and touch a Stored Flight Plan Button to display the 'Catalog Options' Window. c) Touch the Edit Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 84 6) Scroll the list as necessary, and touch the Waypoint Selection Button to select where to insert the new waypoint. The waypoint is inserted into the active flight plan before the selected waypoint. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 85 3) Place the map pointer over a waypoint or map location for the next desired waypoint. Place the map pointer over multiple map items. Touch the Prev or Next Button to cycle to the desired waypoint. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 86 Touch the Edit Button. 2) Scroll the list if necessary and touch a Waypoint Selection Button to display the 'Waypoint Options' Window. Then, touch the Remove WPT(s) Button. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 87 1) From MFW Home, touch Flight Plan . 2) Scroll the list as necessary, and touch the desired 'manseq' heading Waypoint Selection Button to display the 'Waypoint Options' Window. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 88 For a LAT/LON fix, touch the LAT/LON Button, to open the 'LAT/LON' Screen: For a latitude intersecting fix, enter the latitude, and touch the Enter Button. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 89 Adding a waypoint to the active flight plan using fix information: 1) From MFW Home: Touch Flight Plan > Flight Plan Options > Fix Function. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 90 7) Touch the Show on Map Button to preview the airway on the active display pane. 8) Touch the Load Airway Button to insert the airway into the active or standby flight plan. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 91 4) Touch the Back Button to return to the flight plan. Changing Collapsed/Expanded settings for newly loaded airways: 1) For the active flight plan: From MFW Home, touch Flight Plan . 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 92 3OOO 23OO Cross AT 2,300 ft Cross BETWEEN 3,000 ft & 5,000 ft Manual Input of Temperature Compensation Active Flight Plan – Waypoint Altitude Constraints Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 93 6) If necessary, touch the Type Button, then touch the At , At or Above , At or Below or Between Button. If the Between Button is selected, use the keypad and touch the Enter Button to enter the ceiling and floor altitudes. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 94 4) Touch the Revert Button. The altitude is now the database altitude and is shown in cyan, indicating it is usable for vertical guidance. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 95 4) Touch the Enter Button to accept the new FPA constraint. Removing a flight path angle constraint in the active flight plan: 1) From MFW Home, touch Flight Plan > VNAV . 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 96 5) Touch a Mode Selection Button to select it and return to the 'Vertical Situation Display Settings' Window. Advisory Descent Enabling/disabling the Advisory Descent: 1) From MFW Home, touch Flight Plan > VNAV . Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 97: Flight Plan Operations
1) From MFW Home, touch Flight Plan > Flight Plan Options > Parallel Offset . 2) Touch the Distance Button to display the keypad. 3) Use the keypad to select the distance. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 98 To create holding, touch the Waypoint Selection Button to select the waypoint at which to define the holding pattern. The 'Waypoint Options' Window is displayed. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 99 Enter Button to select the time for a reminder. 9) Touch the Create Button to create an Offroute Direct-to hold waypoint at the aircraft present position. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 100 <waypoint name>?'. The hold is removed. To cancel the request, touch the Cancel Button. To remove the hold along with a series of multiple waypoints: Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 101 3) Scroll the list if necessary and touch a Stored Flight Plan Button to display the 'Catalog Options' Window. 4) Touch the Edit Button to display the 'Edit Stored Flight Plan' Screen. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 102 Load the Standby Flight Plan and create new direct-to leg guidance: Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 103: Managing Flight Plans
Touch the Load Standby Button. The Standby will replace the Active Flight Plan and vice versa. Touch Flight Plan Options > Load Standby . The Standby will replace the Active Flight Plan and vice versa. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 104 To cancel the request, touch the Cancel Button. Viewing information about a stored flight plan: 1) From MFW Home, touch Flight Plan > Flight Plan Options . Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 105 1) From MFW Home, touch Flight Plan > Flight Plan Options . 2) Touch the Flight Plan Catalog Button to display the 'Flight Plan Catalog' Screen. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 106 6) Touch the OK Button to store the flight plan and return to the 'Active Flight Plan' Screen. Touch the Cancel Button to return to the 'Active Flight Plan' Screen. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 107: Procedures
5) Touch the Preview Button, then the Show on Map Button to show the preview of the procedure on the active display pane or touch the Show Chart Button to show the procedure chart instead. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 108: Departures
The procedure is removed. To cancel the request, touch the Cancel Button. DEPARTURES Loading a departure into the flight plan: 1) For the active flight plan: Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 109 Removing a departure from a flight plan: 1) For the active flight plan: a) From MFW Home, touch PROC . b) Touch the Departure Button to display the 'Departure Selection' Screen. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 110 Doing so will remove the holding pattern from the flight plan, and the aircraft will fly its current heading without flying the remainder of the flight plan. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 111: Arrivals
Scroll the list if needed and touch a Stored Flight Plan Button to display the 'Catalog Options' Window. c) Touch the Edit Button to display the 'Edit Stored Flight Plan' Screen. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 112 Touch the Arrival Button to display the 'Arrival Selection' Screen. c) Touch the Remove Button. A 'Remove Arrival – <arrival identifier> from flight plan?' Window is displayed. Or : Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 113 Options' Window. c) Touch the Edit Button to display the 'Edit Stored Flight Plan' Screen. 2) Display the 'Select Runway' Screen: Touch the Arrival Runway Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 114: Approaches
DA Approach Service Levels Approach Service Level Lateral Navigation Source Vertical Navigation Source LNAV LNAV+V (advisory only) LNAV/VNAV or Baro VNAV LP+V (advisory only) Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 115 See the following table for approach degradation behavior: 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 116 CDI is removed. VDI displays ‘NO LNAV+V and Baro GP’. VNAV Glidepath Acknowledge CDI is removed; At/after the ABORT APR message to VDI displays ‘NO GP’. redisplay CDI Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 117 1) For the active flight plan: From MFW Home, touch PROC . Or : For the standby flight plan: From MFW Home, touch Flight Plan > Standby Flight Plan > PROC . 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 118 Window. b) Touch the Baro Button to select barometric minimums and return to the ‘Minimums’ Screen. c) Use the keypad to select the minimums altitude. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 119 If needed, touch the Airport Button to display the keypad and use it to select the approach airport. b) Touch the Enter Button to accept the approach airport. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 120 3) Touch the Activate Approach Button to activate the approach. Activating a previously loaded approach with vectors to final: 1) From MFW Home, touch PROC . Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 121 Touch the Approach Header Button to display the 'Approach Options' Window. b) Touch the Remove Approach Button. A 'Remove Approach – <approach identifier> from flight plan?' Window is displayed. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 122 2) Touch the APPR WPT TEMP COMP Button to display the ‘Temp Compensation’ Screen. 3) Touch the Temp Compensation Annunciator Button to enable/disable temperature compensation. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 123: Weight And Balance
1) From MFW Home, touch PERF > Weight and Balance . 2) Touch the Aircraft Loading Tab to display the aircraft load weight buttons. 3) Touch an aircraft load weight button to display the keypad. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 124: General Performance And Trip Planning
Touch the button for the desired datalink source. TRIP PLANNING Selecting the Stored Flight Plan – Cumulative trip route mode: 1) From MFW Home, touch Utilities > Trip Planning. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 125 2) Touch the Trip Route Button to display the 'Input Selection' Window. 3) Touch the Select Starting and Ending Waypoints Button to display the 'Select Starting and Ending Locations' Window. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 126: Takeoff And Landing Assistant (Tola)
5) Touch the Runway Button to display the 'Select Runway' Screen. 6) Touch the desired Runway Selection Button, and return to the 'Takeoff Data' Screen. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 127 5) Touch the Enter Button to accept the entry, and return to the Runway Tab. 6) Repeat Steps 3 through 5 until all runway values are entered as desired. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 128 2) Touch the Speed Bugs Tab. 3) Touch the Restore All Defaults Button. The system restores all default takeoff Vspeed values and disables all takeoff Vspeed bugs. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 129 1) From MFW Home, touch PERF > Takeoff Data . 2) Touch the EMER Return Tab to display the runway data. 3) Touch the Reload from Database Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 130: Landing Data
Each button displays the name of the intersecting runway and LAHSO designation (if available), and the landing distance available before that intersection/ LAHSO point. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 131 Gradient Button to display the keypad. 4) Use the keypad to enter the value. 5) Touch the Enter Button to accept the entry, and return to the 'Landing Data' Screen. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 132: Raim (Receiver Autonomous Integrity Monitoring) Prediction
Reference the RAIM/Fault Detection and Exclusion (FDE) Prediction Tool at flygarmin.com, as required. Predicting RAIM availability: 1) From MFW Home, touch Utilities > FMS Sensors. 2) Touch the Position Sensors Tab. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 133 • ‘Not Available’—RAIM is predicted to be unavailable for the specified waypoint, time, and date • ‘--------’—RAIM has not been computed for the specified waypoint, time, and date combination 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 134 Flight Management Blank Page Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 135: Hazard Avoidance
4) Scroll as necessary and touch the Register Button 5) Use the keypad or large and small upper knobs to supply the access code provided from Garmin Connext customer service. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 136: Accessing Fis-B Weather Information
Hazard Avoidance 6) Touch the Enter Button or push the upper knob. The system contacts the Garmin Connext Weather service. Registration is complete when the Registration Information Window displays the name of the airframe, tail number, and the serial numbers for the airframe and Iridium unit.
Page 137 Product Symbol Time Product Symbol Time (Minutes) (Minutes) NEXRAD Composite Temporary Flight (US) Restriction (TFR) NEXRAD Composite Pilot Weather (Regional) Report (PIREP) Cloud Tops SIGMETs 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 138 FIS-B Weather Product Symbols and Data Timing Expiration Garmin Connext Weather Product Symbol Time Product (Minutes) Connext Radar Cloud Tops Connext Lightning SIGMETs AIRMETs Meteorological Aerodrome Report (METARs) Winds Aloft Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 139: Displaying Data Link Weather Products
Selecting a Data Link Weather Source for Navigation Map Panes: 1) From MFW Home, touch Map > Map Selection > Map Settings . 2) If not selected, touch the Sensor Tab. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 140 Viewing legends for weather products enabled on the ‘Data Link’ (SiriusXM, Connext, or FIS-B) Weather Pane: 1) From MFW Home, touch Weather > Weather Selection > ‘Data Link’ Weather > ‘Data Link’ Weather Settings Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 141 MFD Backlight Level will cause the display to remain in Night Mode longer. Adjusting the Data link Radar Opacity setting lower than the MFD Backlight Level will cause the display to change to Day Mode sooner. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 142: Connext Weather Data Requests
1) From MFW Home, touch Weather > Weather Selection > Connext Weather > Connext Settings . 2) Touch the Send Immediate Request Button. The system contacts Garmin Connext services and displays the status in the ‘Data Request’ Window. System displays ‘Completed’...
Page 143: Weather Product Overview
3) Scroll as needed and touch the NEXRAD Settings Button. 4) Touch the NEXRAD Type coverage Button (displaying either ‘Composite Reflectivity’ or ‘Base Reflectivity’ in cyan). 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 144 2) If not selected, touch the Sensor Tab. 3) Scroll if necessary and touch the NEXRAD Settings Button. 4) Touch the NEXRAD Animation Button to enable/disable the animated NEXRAD information. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 145 2) From PFW Home, touch PFD Map Settings. 3) Scroll in the Overlays Tab and touch the NEXRAD Button. 1) Press the PFD Map Settings Softkey. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 146 1) From MFW Home, touch Weather > Weather Selection > SiriusXM Weather > SiriusXM Settings . 2) Touch the Echo Tops Button in the ‘Background’ window. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 147 1) From PFW Home, touch PFD Map Settings . 2) Scroll and touch the Graphical METARs Button. METAR flags appear on the map. Or : 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 148 1) If necessary, enable the HSI Map or PFD Inset Map to access ‘Data Link’ softkeys. 2) Press the PFD Map Settings Softkey. 3) Press the Datalink Lightning Softkey. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 149 Storm Cell Movement with the NEXRAD weather product on navigation map panes. When button annunciator is gray, system will not show the Storm Cell Movement weather product on navigation map panes. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 150 1) From MFW Home, touch Weather > Weather Selection > SiriusXM Weather > SiriusXM Settings . 2) Scroll as needed in the ‘Overlays’ Window and touch the Freezing Level Button. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 151 SIGMETs and AIRMETs Enabling/Disabling AIRMET and SIGMET information: 1) From MFW Home, touch Weather > Weather Selection > Data Link Weather > Data Link Settings . 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 152 4) Touch the Info Button to show the ‘Center Weather Advisory’ Screen for the selected Center Weather Advisory. 5) Scroll as needed to view full text of the report, then touch the Back Button or the Home Button. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 153: Stormscope Lightning Detection System
Refer to documentation from the lightning detection system manufacturer for detailed information about the system. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 154: Using The Stormscope Pane
3) Scroll if necessary, and touch the Stormscope Lightning button to enable/disable Stormscope information. 1) With either the Inset Map or HSI Map shown, press the PFD Map Settings Softkey. 2) Press the Stormscope Softkey. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 155 1) From MFW Home, touch Map > Map Selection > Map Settings . 2) If not selected, touch the Sensor Tab. 3) Scroll as needed and touch the Stormscope Lightning Settings Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 156: Vertical Situation Display Terrain
Changing the Vertical Situation Display Mode: 1) From MFW Home, touch Map > Map Selection > Map Settings . 2) Touch the Inset Window Tab. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 157: Terrain Displays
Garmin obtains terrain and obstacle data from third party sources and cannot independently verify the accuracy of the information. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 158: Displaying Relative Terrain Information
HSI Map. 3) Touch the Terrain Button. 4) Touch the Relative Button to enable Relative Terrain, or Off to remove terrain information. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 159 3) Touch the Terrain Button. 4) Touch the Absolute + Relative Button to enable Absolute + Relative Terrain feature, or Off to remove terrain information. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 160: Terrain-Svt And Taws-B Terrain And Obstacle Alerts
2) Touch the Terrain Inhibit Button. When the annunciator on the button is green, Terrain SVT alerting is inhibited. When the annunciator is gray, Terrain SVT alerting is enabled. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 161: Tas Traffic
Due to lack of equip- ment, poor signal reception, and/or inaccurate information from other aircraft, traffic may be present but not represented on the display. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 162: Traffic Display Symbology
TAS Traffic with ADS-B Symbology (GTX 335 Transponder) Symbol Description Traffic Advisory with ADS-B directional information. Arrow points in the direction of the intruder aircraft track. Traffic Advisory without directional information. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 163: System Test
TAS Traffic with ADS-B Traffic Symbology (GTX 345R Transponder) SySTEM TEST NOTE: Traffic surveillance is not available during the system test. Use caution when performing a system test during flight. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 164: Operation
From MFW Home, touch Traffic > Traffic Settings . 1) From MFW Home, touch Map > Map Selection > Map Settings > Traffic Settings Button. 2) Touch the Altitude Range Button: Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 165 (such as, touch the Labels range button, then scroll to and touch to select a map range above which the system removes traffic labels from the display. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 166: Ads-B Traffic
1) From MFW Home, touch Traffic > Traffic Settings . a) From MFW Home, touch Map > Map Selection > Map Settings . b) Touch the Traffic Settings Button on the Sensor Tab. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 167 (such as, touch the Labels range button, then scroll to and touch to select a map range above which the system removes traffic labels from the display. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 168 1) From MFD Home, touch Utilities > Setup > ADS-B Status . 2) View the status of the traffic applications, then touch the Back Button or the Home Button when finished. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 169: Automatic Flight Control System
The AFCS Preflight Test is initiated upon system startup. Evidence of this test is indicated by a white ‘PFT’ annunciation. NOTE: During system PFT an “Autopilot” aural alert may be observed with the autopilot servos circuit breaker pulled. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 170: Flight Director Operation
The selected navigation receiver must have a valid VOR or LOC signal or active GPS course before Key press activates flight director. Flight Director Activation Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 171: Afcs Modes
LATERAL MODES Lateral Mode Description Control Annunciation Roll Hold Holds the current aircraft roll attitude (default) Captures and tracks the Selected Heading Select HDG Key Heading 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 172: Combination Modes
LOC Approach Mode Captures and tracks the LOC LOC Arm/Capture/Track navigation source APR Key Captures and tracks the ILS Glideslope glideslope on approach Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 173 3) Press the VNAV Direct To Button. The TOD is recalculated to be just in front of the aircraft and the descent can begin. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 174: Approach Mode
2) Ensure that GPS is the selected navigation source (press the Active NAV Softkey to cycle through navigation sources if necessary). 3) Press the APR Key. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 175 NOTE: When making a backcourse approach, set the Selected Course to the localizer front course. NOTE: The NAV Key must be used to arm Backcourse Mode; the APR Key will not arm the approach. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 176 2) Ensure that LOC is the selected navigation source (press the Active NAV Softkey to cycle through navigation sources if necessary). 3) Set the Selected Course to the localizer front course. 4) Press the NAV Key. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 177: Additional Features
NOTAM information. NOTE: To view the SafeTaxi feature, ‘Airports’ must be enabled on the ‘Map Settings’ Page through the Aviation Tab on the Touchscreen Controller and Garmin SVT™ must be active. NOTE: When obstacles are displayed on the ‘Navigation Map’ Page in the vicinity of an airport being viewed with SafeTaxi, the obstacle symbols may be obscured by SafeTaxi feature labels.
Page 178: Surfacewatch (Optional)
1) From MFW Home, touch Flight Plan > Destination > Select Arrival Runway . 2) On the ‘Select Runway’ Screen, scroll down as required and select the appropriate runway. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 179 Functionality will automatically reset on a system restart. (SurfaceWatch inhibited) SURFACEWATCH Issued when the aircraft is positioned north of N 87° latitude or south of S 87° DISABLED latitude. (Too far north/south) 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 180: Electronic Charts
NOTE: Do not rely solely upon datalink services to provide Temporary Flight Restric- tion (TFR) information. Always confirm TFR information through official sources such as Flight Service Stations or Air Traffic Control. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 181: Chartview (Optional)
3) Push the lower knob. The ‘Charts Pan/Zoom Control’ Screen is displayed on the Touchscreen Controller. 4) Turn the lower knob, or use the pinch-and-zoom feature on the Touchpad to adjust the chart zoom. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 182 Current MFD Backlight Level will cause the Day/Night view to switch at the current backlight setting. Adjusting the Threshold Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 183: Flitecharts (Optional)
3) Touch the Airport Chart Button. The Info Tab selections are displayed on the Touchscreen Controller and the Airport Diagram is displayed on the selected display pane. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 184: Ifr/Vfr Charts
4) Touch the Day , Night , or Auto Button. When Auto is selected, the display will change to the appropriate day or night setting, dependent on ambient lighting. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 185: Satellite Telephone & Datalink Services (Optional)
Flight Service Stations or Air Traffic Control. NOTE: Separate accounts must be established to access the Iridium Satellite Network for voice and Garmin Connext for data transmission of maintenance reports. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 186: Connext Registration
8) Touch the Enter Button. BLUETOOTH ENHANCEMENTS When the GMA 36B Audio Controller is installed, the system supports a Bluetooth link for audio to a Portable Electronic Device (PED) (e.g., a personal cell phone, Garmin VIRB ® , etc.). See the Connext Section in Additional Features for PED pairing instructions. This link enables a two-way telephone call between the system and the PED.
Page 187: Contacts
2) Touch the contact you desire to edit. 3) Touch the information field that you would like to edit. 4) When changes are complete, touch the Save Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 188: Telephone Communication
Phone is ringing Phone has a dial tone (off hook) or connected to another phone Phone dialed is busy Phone is dialing another phone Phone has failed Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 189 2) Touch the Cockpit Phone Button. The ‘Satellite Phone - Cockpit’ Screen is displayed. 3) Touch the Dial Button. The phone number entry screen is displayed. 4) Using the number keys, enter the phone number. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 190 1) From MFW Home, touch Services > Satellite Phone . 2) With a call already connected, touch the Cockpit Phone Button. The ‘Satellite Phone - Cockpit’ Screen is displayed. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 191: Text Messaging (Sms)
3) Touch the To Window. A selection screen is displayed. If the text message is to be sent to an SMS compatible telephone, touch the Phone Button. If the message is to be sent to an email address, touch the Email Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 192 7) Touch the Send Button. The ‘Satellite SMS Text Message Replied To’ Screen is displayed. 8) If desired, touch the Reply Again Button to send another reply. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 193 Saved text message, draft not sent System is sending text message Text message has been sent System failed to send text message Text Message Symbols 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 194: Position Reporting (Optional)
4) Touch the OK Button. Touch the Cancel Button to return to the Inbox. POSITION REPORTING (OPTIONAL) NOTE: An account must be established with Garmin Connext to make full use of the Position Reporting feature. Enabling/disabling position reporting: 1) From MFW Home, touch Services > Position Reports .
Page 195: Connext (Optional)
– Samsung Galaxy™, running Android OS version 4.4 (KitKat) and above – Garmin Pilot for iPhone/iPad version 8.4 and above, running on a supported iPhone/iPad model listed above – Garmin Pilot for Android version 5.4 and above, running on a supported Android OS device listed above – ForeFlight Mobile version 7.3 and above, running on a supported iPhone/iPad model...
Page 196 Bluetooth connection to this device. Connect to this device on your PED. NOTE: The flight crew shall reject a Bluetooth pairing request if the PINs on the PED and Garmin display are not identical or the request originates from any unknown or suspicious device.
Page 197: Recording Mode
Name and Status’ List to allow headset audio to be recorded over the GMA-1 Bluetooth connection to the PED. 8) A green annunciator indicates the device has been enabled for recording. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 198: Siriusxm Satellite Radio (Optional)
(gray) text. NOTE: It may take 45 - 60 minutes before activation is complete and all subscribed-to weather products become available. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 199: Using Siriusxm Radio
4) Touch the Favorites Button to view the ‘Favorites’ Channel List. 5) Touch the desired channel in the list. The channel is now displayed in the ‘Now Playing’ Field. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 200: Electronic Checklists
5) Touch the Back Button to return to the ‘Music’ Screen. ELECTRONIC CHECKLISTS NOTE: Garmin is not responsible for the content of checklists. Checklists are created by the aircraft manufacturer. Modifications or updates to the checklists are coordinated through the aircraft manufacturer.
Page 201 1) From MFW Home, touch Checklist . 2) Touch the desired checklist to reset. 3) Touch the Checklist Options Button. 4) Touch the Reset Checklist Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 202: Electronic Documents
2) The Page Select Button shows the number of pages contained in the document and the page currently being displayed. Touch the Page Select Button to jump to a specific page number. The ‘Enter Page Number’ Screen is displayed. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 203 4) After naming the bookmark, touch the Enter Button. A confirmation screen is displayed. 5) Touch the OK Button. The newly created bookmark is displayed. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 204: Auxiliary Video (Evs)
3) Touch the Stabilized APPR Inhibit Button to enable or disable Stabilized Approach Alerts. A green annunciation in the button indicates Stabilized Approach Alerts are inhibited. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 205: Electronic Stability & Protection (Esp) (Optional)
SD card or through the Wireless Transceiver (Flight Stream 510): Airport Directories, Basemap, Navigation, Obstacles, SafeTaxi, Terrain, ChartView, FliteCharts, and IFR/VFR. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 206: Scheduled Messages
Additional Features NOTE: If the pilot/operator wants or needs to adjust the database, contact Garmin Product Support. NOTE: Garmin requests the flight crew report any observed discrepancies related to database information. These discrepancies could come in the form of an incorrect procedure, incorrectly identified terrain, obstacles and fixes, or any other displayed item used for navigation or communication in the air or on the ground.
Page 207: Crew Profiles
Crew profiles may be up to 16 characters long and cannot share the exact name of another crew profile. 4) Touch the Enter Button or push the upper knob. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 208 2) From MFW Home, touch Utilities > Crew Profile . 3) Touch the Import Button. 4) Scroll if necessary, and touch the button for the crew profile to be imported. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 209 2) From MFW Home, touch Utilities > Crew Profile . 3) Scroll if necessary, and touch the button for the crew profile to be exported from the list. 4) Touch the Export Button. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 210 Additional Features Blank Page Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 211: Abnormal Operation
Refer to the Audio and CNS Section for more information on NAV/COM failure modes. ABNORMAL GPS CONDITIONS The annunciations listed in the following table can appear on or near the HSI when abnor- mal GPS conditions occur. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 212 – Distances to bearing sources displayed in the NAV/DME Information Bar. – GPS bearing pointers. These items should be verified when operating in Dead Reckoning Mode and they become increasingly inaccurate over time. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 213: Garmin Svt Troubleshooting
Abnormal Operation GARMIN SVT TROUBLESHOOTING Garmin SVT™ is intended to be used with traditional attitude, heading, obstacle, terrain, and traffic inputs. SVT is disabled when valid attitude or heading data is not available for the display. In case of invalid SVT data, the PFD display reverts to the standard blue-over-brown attitude display.
Page 214: Svt Unusual Attitudes
STANDBy FLIGHT DISPLAy Selecting the Altimeter Barometric Pressure Setting on the Standby Flight Display: Turn the lower knob on Touchscreen Controller to select the desired setting. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 215: Abnormal Cns Operation
In case of a NAV system failure, an amber X may appear on the frequency display and PFD. ‘Audio & CNS’ Screen NAV Tuning Failure Indications 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 216: Audio Controller Fail-Safe Operation
HSI, and on top of the aircraft symbol on map displays. The CDI deviation bar will be displayed in amber, and the "UNABLE RNP" annunciation will also be displayed on the Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 217: Connext Weather Abnormal Operations
Temporarily Inop expected to return to service in less than 30 minutes. Connext Server Inop The Garmin Connext weather data server will be out of service for at least 30 minutes. Invalid Coverage Area The Connext Data Request does not sufficiently define a coverage area on which to retrieve weather data.
Page 218: Afcs Abnormal Operations
SUSPECTED AUTOPILOT MALFUNCTION NOTE: Consult the aircraft documentation for the location of circuit breakers as well as specifics that may supplement or amplify this procedure. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 219: Overpowering Autopilot Servos
» Ensure the installed hardware has an active subscription or account (e.g., Iridium sub- scription, XM subscription) » Perform a quick check of the circuit breakers to ensure that power is applied to the ap- plicable hardware 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 220 Missing channel information (Touchscreen Controller) ‘XM Information’ Screen (Touchscreen Controller) SiriusXM subscription is not activated ACTIVATION REQUIRED Weather Datalink Display (selected display pane) SiriusXM Datalink Receiver Messages Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 221: Annunciations And Alerts
Note that ADAHRS utilizes GPS inputs during normal operation. ADAHRS operation may be degraded if GPS signals are not present (see the current version of the flight manual). 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 222: Crew Profile Import/Export Messages
Export Results ‘No crew profile plan files Displayed if the SD card does not have one or more valid crew found to import.’ profile filenames. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 223: Comparator Annunciations
If either airspeed sensor detects > 80 knots, and the difference in sensors is ≥ 7 knots. Difference in heading sensors is > 6 degrees. Difference in pitch sensors is > 5 degrees. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 224: Reversionary Sensor Annunciations
10 minutes. less than 10 minutes. ARSPC NEAR – Airspace near Special use airspace is near and ahead of the aircraft position. and ahead. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 225: Vertical Situation Display Messages
These waypoints have been saved to the imported successfully. No system user waypoints. No flight plans stored in the system stored flight plan data was have been modified. modified.’ 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 226 The stored flight plan was not successfully exported to the SD card. The SD card may not have sufficient available memory or the card may have been removed prematurely. Flight Plan Import/Export Messages Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 227: Takeoff And Landing Assistant (Tola)
FIS-B WEATHER UNAVAILABLE Coverage area. 345R is currently off-line or not receiving ™ NOT RECEIVING WEATHER DATA FIS-B Weather data from the antenna. FIS-B Weather Status Annunciation 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 228: Terrain And Obstacle Annunciations
Yellow obstacle is between 100 ft and 1000 ft below the aircraft altitude. White obstacle is more than 1000 ft below aircraft altitude. Wind Turbine Obstacles and Colors Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 229: Terrain Annunciations
Terrain” Imminent Line Impact “Caution; Wire, TERRAIN CAUTION - WIRE Caution (ILI) Wire” Imminent Terrain Impact “Caution; Terrain, TERRAIN CAUTION - TERRAIN Caution (ITI) Terrain” 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 230 OBSTACLE AHEAD - PULL-UP Pull Up; Obstacle Impact Warning (IOI) Ahead, Pull Up” Reduced Required “Caution, Terrain; TERRAIN CAUTION - TERRAIN Terrain Clearance Caution, Terrain” Caution (RTC) Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 231 System Test Pass. None None OK” TER INH Terrain Alerting Inhibited. None None “Terrain System Not TER N/A NO GPS POSITION No GPS position. Available” 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 232 None progress. TAWS System Test None None “TAWS System Test OK” pass. TAWS PDA/FLTA TAWS INH None None Alerting Inhibited. TAWS-B System Test Status Annunciations Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 233: Traffic Annunciations
(also shown in white in center of ‘Traffic Map’ Pane) TAS: FAILED Failed TAS Modes ‘Traffic Map’ Pane Description Center Annunciation NO DATA System is not receiving any data from the traffic unit. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 234 Data is being received from the traffic unit, but the unit is self-reporting a DATA FAILED failure. FAILED Incorrect data format received from the traffic unit. Traffic Failure Annunciations Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 235: Afcs Annunciations
- May indicate a failure of the pitch-trim adapter or trim Elevator Mistrim Up £ELE system Aileron Mistrim AILñ Right Roll servo providing sustained force in the indicated direction Aileron Mistrim Left œAIL 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 236: Surfacewatch Alerts
Issued when the aircraft is taking off from or landing on a CHECK RUNWAY runway” runway different than that entered into the system. SurfaceWatch Alert Annunciations Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 237: Stabilized Approach Alerts
Automatic descent to 14,000FT in 60 seconds. AUTO DESCENT Aircraft descending to 14,000FT. AUTO DESCENT Aircraft descending to 12,500FT. Optional TKS FIKI (optional) SR22T only 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 238 Stall warning. STALL WARNING FAIL Stall warning is inoperative. STARTER ENGAGED Starter is engaged. Turbine inlet temperature is high. Optional TKS FIKI (optional) SR22T only Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 239: Caution Messages
IPS fluid quantity imbalance has been detected. IPS PRESSURE HIGH IPS pressure is high. IPS PRESSURE LOW IPS tail pressure is low. Optional SR22T TKS FIKI (optional) 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 240: Alerts Messages
NOTE: The ice protection system (optional) must be operated in accordance with the current version of the pertinent flight manual limitations. This option is only available on SR22 and SR22T models. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 241 SFD comparison data missing. VNAV ALT SEL VNAV needs lower ALT SEL to capture VPATH. VNAV NOT ARMED Press VNV to arm VPATH capture. Optional TKS FIKI (optional) 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 242: System Messages
ADC2 AS EC – ADC ADC2 / GDC2 is reporting the airspeed error correction is unavailable. airspeed error correction is unavailable. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 243 The GSA servo is inoperative due to an AFCS 1 and/or 2 pre-flight test PFT – AFCS [1-2] Pre-Flight failure. The system should be serviced. Test Fail: ROL Servo 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 244 AHRS1 GPS – AHRS1 AHRS1 is using the backup GPS path. Primary GPS path has failed. The using backup GPS source. system should be serviced when practical. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 245 AHRS2 GPS – AHRS2 AHRS2 is using the backup GPS path. Primary GPS path has failed. The using backup GPS source. system should be serviced when practical. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 246 Abnormal AP disconnect due to flight director receiving invalid required – Flight Director parameters parameter. AP DISC: INVALID DATA Abnormal AP disconnect due to loss of servo communication. – Servo comm failure Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 247 Reset altitude preselect to arm descent. AUDIO MANIFEST – The GIA has incorrect software installed. The system should be serviced. Audio software mismatch, communication halted. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 248 COM 2 current is low. Check COM current. Check COM Current. COM #2 INOP: INTRL – COM 2 has an internal fault. COM Internal Fault. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 249 DATABASES Databases are downloading to the system. Go to the ‘Database Status’ DOWNLOADING – See Screen to monitor status. databases page for more information. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 250 CLIMB – Press NAV to enable VNAV track change. DISABLE GS TO ARM Disable AFCS APPR mode to enable VNAV. CLIMB – Press NAV to enable VNAV track change. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 251 The system should be serviced. GDL69 MANIFEST – The 69A SXM has incorrect software installed. The system should be GDL69 software mismatch, serviced. communication halted. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 252 GIA #1 fan failure. Monitor GIA #1 temperature. Fan fault, check GIA temperature. GIA #1 INOP - CRNT – GIA 1 current is low. The current should be checked. Check GIA Current. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 253 The GMA is inoperative due to a CRC fault. – GMA CRC Fault. GMA 1 INOP: VOLTAGE The GMA is inoperative due to a voltage fault. – Voltage outside standard range. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 254 Factory GPS Calibration Lost GPS calibration. Or Corrupted. GPS #1 BATT LOW GPS 2 Battery is low. The battery should be checked. – GPS 2 Batt Check Recommended. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 255 GTC1 card 1 was removed. system should be serviced. Reinsert card. GTC1 CHK REQD: FAN GTC1 fan failure. Monitor GTC temperature. FAIL – Monitor GTC Temperature 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 256 GTC2 CONFIG – GTC2 Touchscreen Controller configuration settings do not match those of config error. Config service backup configuration memory. The system should be serviced. REQ’D. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 257 – Datalink: ADS-B 1090 receiver has failed. GTX 3X5 1 ADS-B IN The transponder is unable to receive ADS-B IN information. – Datalink: ADS-B in has failed. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 258 The system has detected an under temperature condition in GTX 1 / – <XPDR OR DLK 1>: datalink. The transmitter operates at reduced power. If the problem Under temperature. persists, the system should be serviced. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 259 The SD card was removed from the top card slot of the MFD. The SD card MFD1 card 1 was removed. needs to be reinserted. Reinsert card. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 260 MFD1 INOP: DISABLE The specified GDU has insufficient voltage. The system should be serviced. DSPL – Check Disable Display Input Wiring Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 261 NAV 1 serial communication fault. Check NAV serial communication. – Internal NAV Serial Communication Fault. NAV #1 INOP: SyNTH – NAV 1 has a synthesizer lock fault. NAV Synthesizer Lock Fault. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 262 There is a mismatch in the position sensed by the PFDs. Check position DIFFERENT – PFD sensor settings. If message persists the system should be serviced. positions mismatch. Check position sensors. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 263 LRU. PFD1 DB ERR – PFD1 The terrain database is present on another LRU, but is missing on the terrain database missing. specified LRU. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 264 The GSA servo is inoperative due to a loss of communication path to a Check PIT servo wiring to GIA. The system should be serviced. GIA2 Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 265 The system notifies the pilot to load the approach frequency for the appropriate frequency for appropriate NAV receiver. Select the correct frequency for the approach. approach. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 266 / corrupted. SySTEM INOP: FLEET ID The system configuration has changed unexpectedly. The system should be – System configuration lost serviced. or corrupted. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 267 A vertical discontinuity exists ahead of the aircraft in the flight plan. AHEAD – Discontinuity after [waypoint]. VNAV CONFIG – VNAV VNAV configuration error. The system should be serviced. config error Config service REQD. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 268: Airframe System Messages
ESP is inoperative. ESP OFF ESP selected off. MIXTURE POSITION Mixture position sensor requires service. SERVICE REQD THROTTLE POSITION Throttle position sensor requires service. SERVICE REQD Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 269: Appendices
See descriptions and procedures in this Appendix for more information. In some cases it may be necessary to obtain an unlock code from Garmin in order to make the database product functional. It may also be necessary to have the system configured by a Garmin authorized service facility in order to use some database features.
Page 270 Appendix NOTE: The FAA has asked Garmin to remind pilots who fly with Garmin database- dependent avionics of the following: • It is the pilot’s responsibility to remain familiar with all FAA regulatory and advisory guidance and information related to the use of databases in the National Airspace System.
Page 271: Databases And Cycles
O r : From MFW Home, touch Utilities > Setup > Database Status. 9) Verify the standby databases transferred and are now in the ‘Active’ Column. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 272: Database Auto Swap
A 32 GB SD (or FS 510 card as a storage device) card can be used to perform database updates. Only cards provided by Garmin or the OEM should be used. In the event there is a file corruption problem with the SD card, it may be necessary to reformat the card. This can cause an issue when formatting using Mac OS, where the newly formatted device will not be recognized by the avionics system.
Page 273: Seamless Database Activation
10) Press the right most softkey on the MFD to acknowledge the power-on screen. 11) From H ome, touch Utilities > Initialization > Database Status. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 274: Updating Databases When The System Is Powered On
UPDATING DATABASES WHEN THE SySTEM IS POWERED ON The following instructions cover updating databases after system power-on for using an SD Card. (For instructions to update databases after system power-on using Garmin Pilot and a PED, see ‘Updating Databases Using Garmin Pilot’). Databases will update automatically after power-on when enabled on the system.
Page 275 Appendix Databases can be updated using a PED with Garmin Pilot in combination with the Wireless Transceiver. A PED with Garmin Pilot™ must be paired with the Wireless Transceiver over Bluetooth. The system preferred PED may be selected on the Touchscreen Controller ‘Data- base Status’...
Page 276 Appendix On the PED, start Garmin Pilot™ and touch Home > Connext > Database Concierge . 7) On the PED, connect with Bluetooth to the Wireless Transceiver. (Refer to the Additional Features section for more information on connecting to Bluetooth) 8) From MFW Home on the Touchscreen Controller, touch Utilities >...
Page 277: Deleting Databases
AHRS (GRS1 and GRS2). When a new navigation database is loaded, the system may ascertain the newly loaded MV DB within the navigation database is newer than that residing in each 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 278: Touchscreen Controller Screens
Displays the Telephone ‘Notifications’ Screen on Touchscreen Controller. Scrolls up in a list Flashes when a new telephone call is received. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 279 Displays the Connext ‘Notifications’ Screen on the Touchscreen Controller. Opens ‘Direct To’ Screen on Flashes when a new Connext the Touchscreen Controller message is received. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 280: Mfw Mode Touchscreen Controller Screens
Shows ‘Traffic Map’ Pane in the selected Display Pane. When the ‘Traffic Map’ Pane is displayed, the button becomes the Traffic Settings Button. Touch the Traffic Settings Button to access the ‘Traffic Settings’ Screen on the Touchscreen Controller. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 281 Accesses the ‘Services’ Screen on Touchscreen Controller. Includes optional Iridium phone, and text messaging services, Networks and Pairing, Bluetooth Phone, Music, Position Reports, Connext Setup, and Contacts. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 282 User Waypoints. Provides information about the nearest Airports, Intersections, VORs, NDBs, VRPs, User Waypoints, Airspace, ARTCC facilities, Flight Service Stations, and Weather reporting stations. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 283 ‘IFR Low Settings’ or ‘IFR High Settings’ respectively. Touching either settings button again opens the ‘IFR/VFR Charts Settings’ Screen which is discussed in the Additional Features Section. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 284 ‘Settings’ syntax. Touching any of these ‘settings’ buttons will open a settings screen discussed in the Hazard Avoidance Section. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 285 OAT, and pitot and AOA heat. When the Ice Protection Button is touched, the IPS Left, IPS Auto, and IPS Right buttons will be displayed on the ‘Aircraft Systems’ Screen. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 286 Accesses the optional ‘Contacts’ Screen for management of contact information including phone and email addresses. Also provides quick access to stored contacts using phone, SMS, or email. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 287 Provides settings for automated database downloads, Personal Electronic Device (PED), Aircraft Report Intervals, Connext Registration (REG Tab), and time and dates for past and future automated database downloads (Events Tab). ‘Utilities’ Screen 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 288 Displays the ‘Setup’ Screen, which provides controls for avionics settings and status, SiriusXM Info, ADS-B Status and for displaying the status of avionics databases. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 289 SiriusXM Satellite Radio and to verify subscriptions of SiriusXM Weather products. Provides access to the ‘Database Status’ Screen for checking database cycle information. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 290 NOTE: SurfaceWatch option required for ‘PERF’ Screen to be shown. Aircraft takeoff, landing, and performance related functions, settings, and processes for the buttons within the ‘PERF’ Screen are discussed in the Flight Management Section. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 291 Appendix ‘Waypoint Info’ Screen Functions, settings, and processes for the buttons within the ‘Waypoint Info’ Screen are discussed in the Flight Management Section. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 292 Appendix ‘Nearest’ Screen Functions, settings, and processes for the buttons within the ‘Nearest’ Screen are discussed in the Flight Management Section. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 293: Pfw Touchscreen Controller Screens
NAV1, NAV2, GPS, ADF, BEST GLIDE, and WPT. Displays pop-up window with selection buttons for Bearing 2 Pointer selections Off, NAV1, NAV2, GPS, ADF, BEST GLIDE, and WPT. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 294 Format, SVT, Flight Path Marker, AOA, Horizon Heading, Wind, Meters Overlay, Baro Select Units, Time Format, Time Offset, COM Channel Spacing, and Screen Cleaning function. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 295 Enables/disables display of compass heading along the Zero-Pitch line. When Enabled, the annunciator is green. Button is subdued when synthetic terrain is disabled. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 296 Selects the Time Format: Local 12hr, Local 24hr, or UTC. Displays the Local and UTC time offset. Selects the COM Channel Spacing: 25 kHz or 8.33 kHz. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 297 Accesses buttons to select SBAS and SBAS settings, select GPS1 and GPS2 sensors, Sensors Tab check sensor status and RAIM. Displays the ‘GPS1...’ or ‘GPS2 Status’ Pane. Refer to content later in this section for more information. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 298: Pfd Softkeys
Adds or removes the display of traffic on the PFD Map. The softkey annunciator is green when the traffic function is on. When the traffic function is off, the annunciator is gray. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 299 PFD Map (optional): Connext: Selects Garmin Connext as the weather source. SiriusXM: Selects SiriusXM as the weather source. FIS-B: Selects FIS-B as the weather source. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 300 HSI Map. The softkey annunciator is green when the function is on. When the function is off, the annunciator is subdued. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 301 When the PFD Map is on, the softkey annunciator is gray. Displays the PFD settings softkeys. Settings 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 302 PFW display occupies the full screen. Split: Display Pane is enabled. The PFD / PFW screen is split between the PFD / PFW display and the Display Pane. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 303 ‘SUSP’ will replace ‘OBS’ when waypoint sequencing is suspended. Active Cycles through GPS, NAV1, and NAV2 navigation modes on the CDI. Sensors Displays the sensor selection softkeys. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 304 SVT mode off. The softkey annunciator is green when the function is off. Displays additional SVT overlay Settings softkeys (optional). Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 305 Cycles the Bearing 1 Information Window through NAV1, NAV2, GPS, ADF1, and Off. Bearing 2 Cycles the Bearing 2 Information Window through NAV1, NAV2, GPS, ADF1, and Off. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 306 Selects the number 1 ADC. The softkey annunciator is green when selected. ADC 2 Selects the number 2 ADC. The softkey annunciator is green when selected. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 307 Displays HSI Map overlay softkeys Overlays (only available if HSI Map is enabled). Terrain Selects the display of terrain Settings information on the HSI Map: 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 308 Selects type of NEXRAD coverage when SiriusXM is the selected data link source: COMP: Displays composite reflectivity image. Displays base reflectivity Base: image. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 309 Map. The softkey annunciator is green when the lightning function is on. When the lightning function is off, the annunciator is gray. More Displays more map overlay softkeys. 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 310 Stormscope information on the scope HSI Map (optional). The softkey annunciator is green when the function is on. When the function is off, the annunciator is subdued. Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 311: Screen Cleaning
Screen. See the Hazard Avoidance Section for more information on Obstacles. Default Maximum Land Symbols Symbol Range Range (nm) (nm) Obstacles (Point and Wire) See Hazard Avoidance Section Roads see below 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 312: Aviation Symbols
The following items are configured on the Aviation Tab of the 'Map Settings' Screen. Default Maximum Aviation Symbols Symbol Range Range (nm) (nm) Low Altitude Airways (V and T Routes) High Altitude Airways (J and Q Routes) Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 313 Class A (CL A) - Class D - Aerodrome Traffic Zone (ATZ) - Traffic Information Zone (TIZ) Restricted and Prohibited Areas (Restricted) Military Operations Areas (MOA (Military)) 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 314 5000 ft with control tower) Small Airport (Longest Runway < 5000 ft without control tower) Heliport VOR Waypoint - VOR Compass Rose On/Off INT Waypoint NDB Waypoint VRP Waypoint Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 315: Additional Map Display Items
Dead reckoning ‘DR’ text displayed over the aircraft icon when the GPS solution is aircraft icon invalid Miscellaneous Map Symbols 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 316: Flight Planning
Top of Descent When vertically navigating, the system will (TOD) and display where the aircraft will begin complete Bottom of the descent. Descent (BOD) Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 317 Roll Steering Path transitions between two disconnected legs (i.e. holding), some procedure turn segments, parallel offset segments, or after some fly-over waypoints. Flight Plan Symbols 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin...
Page 318 Appendix Blank Page Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin 190-02954-01 Rev. A...
Page 319 Garmin Connext Abnormal Operations Arrivals Loading 85 Weather Product Overview Removing 86 NEXRAD (SiriusXM) Attitude and Heading Reference System NEXRAD Animation 118 (AHRS) 226 Precipitation (Garmin Connext) 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin Index-1...
Page 320 Flight Path Angle (FPA) 69 Magnetic Field Variation Database 251 Flight Plan Activating a Flight Plan 76 Orientation 33 Active Flight Plan Leg Data 49 Panning 34 Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin Index-2 190-02954-01 Rev. A...
Page 321 Required Obstacle Clearance (ROC) Reversionary Mode 185 Underspeed Protection 210 Route Entry 53 Unusual Attitudes 187 User Airport 42 User-Defined Holding Pattern 74 , 75 SafeTaxi 151 190-02954-01 Rev. A Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin Index-3...
Page 322 Vertical Speed (VS) Target 70 Visual Approach 93 Warning Messages 211 Waypoints Abeam Crossing Waypoints 53 Weight and Balance Display 97 Wind Data 6 Wireless Transceiver 250 Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin Index-4 190-02954-01 Rev. A...
Page 324 2345 Turner Road SE No. 68, Zhangshu 2nd Road Salem, OR 97302, U.S.A. Xizhi District, New Taipei City, Taiwan Contact Garmin Product Support or view warranty information at flygarmin.com. © 2022, 2023 Garmin Ltd. or its subsidiaries 190-02954-01 Rev. A...

Garmin CIRRUS PERSPECTIVE TOUCH+ Cockpit Reference Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Garmin CIRRUS PERSPECTIVE TOUCH+

Summary of Contents for Garmin CIRRUS PERSPECTIVE TOUCH+

Table of Contents
