Whirlpool FFT M22 8X3B SPT Quick Start Manual

Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register
PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.
CONTROL PANEL
(hold for Reset)
1 ON/OFF button
2 Programme selection Knob
3 Start/Pause
Options Buttons*
4 Cycle end
5 High heat
(hold for
6 Anti tangle Mute)
7 Dryness level
8 Start delay
9 Timed drying
(hold for
10 Rapid Key lock)
11 Gentle
12 FreshCare+
INDICATORS
Dryness level:
Iron dry -
Cycle phase:
Drying -
Empty water tank -
Refer to troubleshooting section:
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dryer is fixed correctly,
either to the dryer's water tank, or to your domestic drainage
system.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
Before you use your dryer ensure that it has been in a upright
position for at least 6 hours.
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying
cycle.
- remember to clean your filters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door filter. Do not load items that
are dripping wet. Do not tumble dry large, very bulky items. For
optimal drying result, garments should be loaded one by one.
3. Close the door.
4. Press the "On/Off" button.
5. Select the most suitable programme for the type of fabric in
that load.
6. Select the options, if necessary.
7. Press the "Start/Pause" button to begin drying.
8. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Turn the machine
off by pressing the "On/Off" button, open the door and pull the
clothing immediately out to prevent the formation of creases on
laundry.
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
If the machine is not switched off manually, after about a quarter
• Using QR code in your appliance
of an hour from the end of the cycle , the appliance turns off
• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com
automatically to save energy.
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Note that some models perform a final cool tumble phase, for this
Service, please state the codes provided on your product's identifi cation plate.
reason the fabrics may not feel hot.
In case of power failure, it is necessary to press the "Start/Pause"
button to restart the cycle
2
2
Hanger dry - Cupboard dry -
Cool down - End of cycle
Clean door filter - Clean bottom filter
Failure: Call after sales service
4
Before using the appliance carefully Before using the appliance carefully
read the Safety Instruction. read the Safety Instruction.
5
6
3"
7
4
5
6
3"
7
*Note: some models may have the wording in full instead of the icons.
Extra dry
Opening the door during the cycle
The tumble dryer door can be opened at any time during the cycle
to check progress and remove any garments already dry.
However, since opening the door can extend the drying time, the
recommendation is to keep the door closed throughout the cycle
process to save time and energy.
After closing the door, press the "Start/Pause" button within 15
minutes to resume the machine operation.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the fi rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
12
11
10
3"
h
8 9
12
11
10
3"
h
8 9
EN
1
3
1
3
