Whirlpool WED94HEA Dimensions And Installation

Whirlpool electric dryer dimensions and installation
Hide thumbs


Advertisement

PRODUCT MODEL NUMBERS
WED94HEA, WED96HEA
DRYER DIMENSIONS
Front view:
38
/
"
1
8
(968 mm)
/
"*
3
4
(18 mm)
Back view:
NOTE: Most
installations
require a minimum
of 5" (127 mm)
clearance behind
dryer for exhaust
vent with elbow.
See "Venting
Requirements".
3
/
"*
4
(18 mm)
* Approx. measurement.
Installation spacing for recessed area or closet installation
All dimensions show recommended and minimum spacing allowed.
■ Additional spacing should be considered for ease of
installation and servicing.
■ Additional clearances might be required for wall, door, floor moldings, and dryer venting.
■ Additional spacing should be considered on all sides of the dryer to reduce noise transfer.
■ For closet installation, with a door, minimum ventilation openings in the top and bottom of the door are required. Louvered doors
with equivalent ventilation openings are acceptable.
■ Companion appliance spacing should also be considered.
27"
(686 mm)
* Approx. measurement.
Power supply
cord/cable
Water inlet
(Steam
models
Vent
14
/
"
3
8
(365 mm)

Electric Dryer

Side view:
Recommended installation clearances (dryer only):
6
/
"
1
2
(165 mm)
29
"*
7
/
8
(759 mm)
3
/
"*
1
2
(89 mm)
5"
*
(127 mm)
6
/
"*
1
8
(156 mm)
* 0" (0 mm) spacing is allowed.
3"
(76 mm)
18" min.
(457 mm)
3"
(76 mm)
1"
1"
*
(25 mm)
(25 mm)
48 in.
min.
2
(310 cm
)
2
24 in.
min.
2
(155 cm
)
2
W10508904B
09/2012
