aqprox! appLS21 User Manual

2d barcode scanner
Hide thumbs

Advertisement

Quick Links

Download this manual
2D Barcode
Scanner
appLS21
1
www.approxtpv.es

Advertisement

loading
Need help?

Need help?

Do you have a question about the appLS21 and is the answer not in the manual?

Questions and answers

Related Manuals for aqprox! appLS21

Summary of Contents for aqprox! appLS21

  • Page 1 2D Barcode Scanner appLS21 www.approxtpv.es...
  • Page 3 No desmonte el terminal ni rasgue el sello de seguridad. De lo contrario, no seremos responsables de su garantía o reemplazo. El appLS21 es un lector de códigos de barras de alto rendimiento. Puede decodificar rápida y prácticamente cualquier simbología de códigos de barras 1D y 2D, incluyendo códigos QR, desde papel o directamente...
  • Page 4 1.3. Mantenimiento · La ventana debe mantenerse limpia, el fabricante no asume la respon- sabilidad de la garantía debido a un mantenimiento inadecuado. · Evite que la ventana se desgaste o se rasgue con objetos duros. · Usa un cepillo para quitar manchas de la ventana. ·...
  • Page 5 * Más opciones de configuración en la página 7. 4. Instrucciones de seguridad, mantenimiento y reciclado - Atención: Nunca abra el dispositivo, las partes internas tienen peligro de descarga eléctrica. - No instale esta unidad cerca de agua, como, por ejemplo, en un sótano húmedo, en un exterior sin protección o en cualquier zona clasificada como húmeda.

  • Page 6: Product Introduction

    Otherwise, we will not be responsible for the warranty or replacement of the terminal. appLS21 is a high performance barcode reader. It can quickly decode any 1D and 2D barcode symbology, including QR codes, from paper or directly from the screen of any device, perfect for customer-facing appli- cations.
  • Page 7 1.3. Maintenance · The window must be kept clean, the supplier do not bear the guarantee responsibility due to the improper maintenance. · Avoid the window being wear and tear or scratched by hard object · Use the hairbrush to remove the stain on the window ·...

  • Page 8: Enable/Disable Symbologies

    3. Basic settings In this chapter, you can configure the function mode of the device, inclu- ding the working mode (such as image whitening), aimer setting, lighting configuration, LED indicator setting and speaker setting. You only need to scan the corresponding configuration code according to the requirements. 3.1.
  • Page 9 3.4. Beeper Beeper on (default) Beeper off 4. Output setting In this chapter, you can configure the output of the device, including ca- rriage return / line feed, add prefix / suffix, set the length of barcode, remove the number of digits of barcode (start / end removal) and switch settings of multi-national keyboard.
  • Page 10 Transmit non-visible character Don’t transmit non-visible character 4.3. Extra code setting Enable 2 extra code Disable 2 extra code (default) Enable 5 extra code Disable 5 extra code (default) 4.4. Language settings Belgium English French German Italian Spanish America Singapore...
  • Page 11 El Salvador Japan Sierra Leone Turkey Russia Hungary Russian (Russia) Thai 4.5. Data matrix code Enable (default) Disable Enable inverse DM code Disable inverse DM code (default) 4.6. EAN/UPC Enable (default) Disable...
  • Page 12 Normal barcode Normal and inverse 4.7. Micro QR code Enable Disable (default) Enable inverse micro QR Disable inverse micro QR (default) 5. Special function configuration 5.1. Prefix Enable Disable 5.2. Suffix Enable Disable 5.3. Programming mode Bar code length locking configuration (support up to 6 bar code type length locking).
  • Page 13 2. Scan “configure barcode type 1 length”. 3. Scan bytecode values “0”, “1”, “0” in turn. 4. Scan “configure barcode type 1 byte value”. 5. Scan byte code values “0”, “8” and “3” in turn. 6. Scan “enter / exit programming mode”. Add length lock for multiple barcode types: Example 2 1.
  • Page 14 Configure barcode type 4 length Configure barcode type 4 byte value Configure barcode type 5 length Configure barcode type 5 byte value Configure barcode type 6 length Configure barcode type 6 byte value Bytecode value (decimal)
  • Page 15 5.4. Bar code type table Barcode byte value Barcode Type UPC-E EAN-8 UPC-A EAN-13 CODE 39 CODABAR INTERLEAVED 2 OF 5 CODE 128 CODE 93 CODE 11 AIRLINE 2 OF 5 MATRIX 2 OF 5 TELEPEN UK PLESSEY AIRLINE(13 DIGITS) STANDARD 2 OF 5 TRIOPTIC RSS14...
  • Page 16 Add Prefix / Suffix (up to 10 characters can be added respectively) Add prefix process: Example 1: add a byte prefix, the character is “”, and the corresponding ASCII decimal number is 040. 1. Scan “enter / exit programming mode” barcode. 2.
  • Page 17 Clear all suffixes: Scan the clear all prefixes barcode. Enter / exit programming mode Configuration 1st prefix Configuration 2nd prefix Configuration 3rd prefix Configuration 4th prefix Configuration 5th prefix Configuration 6th prefix Configuration 7th prefix Configuration 8th prefix Configuration 9th prefix Configuration 10th prefix Clean all prefix Configuration 1st suffix...
  • Page 18 Configuration 3rd suffix Configuration 4th suffix Configuration 5th suffix Configuration 6th suffix Configuration 7th suffix Configuration 8th suffix Configuration 9th suffix Configuration 10th suffix Clear all suffix 5.5. Attached: ASCII code table Decimal Character Decimal Character Decimal Character Decimal Character ‘...
  • Page 19 Decimal Character Decimal Character Decimal Character Decimal Character < > 6. Safety, maintenance and recycling instructions - Caution: Never open the device, the internal parts are danger, electrical shock. - Do not install this unit near water, for example, in a wet basement, in an unprotected outdoor installation or in any area classified as a wet.
  • Page 20 7. Recycled AEEREI-RAE 558 - In this manual, the container (bien) symbol indica- tes that the product is subject to the European directive 2002/96/EC, electrical and electronic products, batteries, and other accesories must necessarily be subject to a selective collection. At the end of the life of the devise, make use of the recycling bins.
  • Page 21 Não desmonte o terminal nem rasgue o lacre de segurança. Caso contrário, não seremos responsáveis por sua garantia ou substituição. O appLS21 é um leitor de código de barras de alto desempenho. Você pode decodificar rapidamente praticamente qualquer simbologia de código de barras 1D e 2D, incluindo códigos QR, do papel ou diretamente da tela...
  • Page 22 1.3. Manutenção · A janela deve ser mantida limpa, o fornecedor não assume a responsa- bilidade pela garantia devido à manutenção inadequada. · Evite que a janela seja desgastada ou arranhada por objetos duros · Use a escova para remover a mancha na janela ·...
  • Page 23 Português * Mais opções de configuração na página 7. 3. Instruções de segurança, manutenção e reciclagem 1. Atenção: Nunca abra o aparelho, as partes internas estão em perigo de choque elétrico. 2. Não instale esta unidade perto de água, numa cave húmida, no exterior sem proteção ou em qualquer área classificada como húmida.
  • Page 24 Il peut rapidement décoder n’importe quelle symbologie de codes-barres 1D et 2D, y compris les codes QR, à partir du papier ou directement depuis l’écran de n’importe quel appareil, parfait pour les applications orientées...
  • Page 25 Français Redémarrer: si le scanner plante ou ne répond pas, veuillez l’éteindre et redémarrer. 1.3. Entretien · La fenêtre doit être maintenue propre, le fournisseur ne supporte pas la responsabilité de la garantie en raison d’un mauvais entretien. · Évitez que la fenêtre soit usée ou rayée par un objet dur. ·...
  • Page 26 3.2. Son Avec son (par défaut) Sans son * Plus d’options de configuration à la page 7. 4. Consignes de sécurité, d’entretien et de recyclage 1. Attention : N’ouvrez jamais l’appareil, les pièces internes présentent des risques d’électrocution. 2. N’installez pas cet appareil près d’un point d’eau, par exemple dans une zone mouillée, dans une zone extérieure non protégée ou dans toute zone classée comme humide.
  • Page 28 Importador por / Imported by: Distribuciones Mylar S.A.U. CIF: A91852061 Soporte técnico / Technical support: Tlf.: +34 954 323 886 E-mail: soporte@approxtpv.es MADE IN PRC El contenido de esta guía está sujeto a errores tipográficos The content of this guide is subject to typographical errors www.approxtpv.es...
