SPECIFICATION
Customer :
Cusomer No:
Applied To :
Product Name : Piezo Transducer
Model Name : KPT-G1040-3039
Drawing No. : OEM3039R
Compliance with RoHS
Signature of Approval
Signature of KEPO
Approved by
宁波凯普电子有限公司
Ningbo Kepo Electronics Co.,Ltd.
浙江京东方
Checked by
Issued by
Date
Advertisement
Related Manuals for KEPO KPT-G1040-3039
Summary of Contents for KEPO KPT-G1040-3039
- Page 1 SPECIFICATION 浙江京东方 Customer : Cusomer No: Applied To : Product Name : Piezo Transducer Model Name : KPT-G1040-3039 Drawing No. : OEM3039R Compliance with RoHS Signature of Approval Signature of KEPO Approved by Checked by Issued by Date 宁波凯普电子有限公司 Ningbo Kepo Electronics Co.,Ltd.
- Page 2 Model No. : KPT-G1040-3039 Drawing No. OEM3039R CONTENTS 1. Scope 范围 2. General 概要 3. Electrical and Acoustic Characteristics. 电声参数 4. Reliability Test 可靠性试验 5. Measurement Block Diagram &Response curve 测试图和曲线图 6. Dimensions 尺寸 7. Revision 履历表 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 3 壳体材质 / 颜色 : PBT/ 黑 3. 额定极限条件 Maximum Rating 项目 规 格 Item Specification 最高输入电压 15Vp-p Square Wave /max. Maximum input Voltage 工作温度范围 -20 ～ +70 ℃ Operating Temperature Range 储存温度范围 -40 ～ +85 ℃ Storage Temperature Range Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 4 ℃ , 湿度 45 ～ 85%R.H. 的范围内测试 . Part shall be measured under a condition (Temperature :+5 to +35 ℃ ,Humidity :45 to 85%R.H.)unless the standard condition (Temperature :+25 ± 3 ℃ ,Humidity :60 ± 10 %R.H.) is regulated measure. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 5 分别在每个插针的轴向施加 9.8 牛顿的静荷 插针没有断开和 重 10 秒 . 可见的损伤 插针强度 No visible Terminal The force 10 seconds of 9.8N is applied to damage and Strength Pulling each terminal in axial direction. cutting off Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 6 After 5 above cycles, sounder shall be measured after being placed in natural condition for 4 hours. 表 1 Table 1 项 目 试验后变化量 Specification after test Item 声压级 初始值± 10dB Sound Pressure Level Initial Value ± 10dB Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 7 Page Specification for Transducer Revision No. Model No. : KPT-G1040-3039 Drawing No. OEM3039R 6. Dimensions KEPO FIRST ANGLE PROJECTION UNIT ± 0.5 Tolerance : Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 8 控制在 3 秒内 . In case of using solder iron for soldering, the top of soldering iron's temperature should be kept less than +350 ℃ .Moreover the soldering time should be also kept with in 3seconds. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 9 Page Specification for Transducer Revision No. Model No. : KPT-G1040-3039 Drawing No. OEM3039R 7. Revision Rev. DATE PAGE DESCRIPTION SIGN primary 2008.07.04 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
