SPECIFICATION
Customer :
Applied To :
Product Name : Piezo Transducer
Model Name : KPR-G3530
Drawing No. :
Compliance with ROHS( 本品符合 ROHS 指令 )
Signature of Approval
Signature of KEPO
Approved by
宁波凯普电子有限公司
Ningbo Kepo Electronics Co.,Ltd.
KP3.840.377R
Checked by
Issued by
Date
Advertisement
Related Manuals for KEPO KPR-G3530
Summary of Contents for KEPO KPR-G3530
- Page 1 SPECIFICATION Customer : Applied To : Product Name : Piezo Transducer Model Name : KPR-G3530 Drawing No. : KP3.840.377R Compliance with ROHS( 本品符合 ROHS 指令 ) Signature of Approval Signature of KEPO Approved by Checked by Issued by Date 宁波凯普电子有限公司...
- Page 2 额定极限条件 4. Electrical Characteristics 电性能 5. Measuring Method 测试方法 6. Physical Characteristics 机械性能 7. Environmental Characteristics 环境性能 8. Dimensions 尺寸 9. Packaging Standard 包装标准 10. Cautions 警告 11. Cautions for Use 注意事项 12. Revision 履历表 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 3 4. 电性能 Electrical Characteristics 规 格 项目 Specification Item 声压 ≥ 82dB at 5VP-P/1.1KHZ/10CM Sound Pressure Level 频率 1.1± 0.5KHz Resonant Frequency 容量 5000± 30%pF Capacitance at 100Hz 测试条件参见下项 Refer to next item for measuring method. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 4 个方向各 2 小时试验后 , 测试声响器 . Table 1. 耐振动性 Sounder shall be measured after being applied Vibration vibration of amplitude of 1.5mm with 10 to55Hz band of vibration frequency to each of 3 perpendicular directions Resistant for 2 hours. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 5 After 5 above cycles, sounder shall be measured after being placed in natural condition for 4 hours. 表 1 Table 1 项 目 试验后变化量 Specification after test Item 声压级 初始值± 10dB Sound Pressure Level Initial Value ± 10dB Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 6 Page Specification for Transducer Revision No. Model No. : KPR-G3530 Drawing No. KP3.840.377R 8. Dimensions Ø34.8± 0.3 Ø28 UL1061 24# Red UL1061 24# Black FIRST ANGLE PROJECTION UNIT ± 0.5 Tolerance : Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 7 制在 3 秒内 . In case of using solder iron for soldering, the top of soldering iron's temperature should be kept less than +350 ℃ .Moreover the soldering time should be also kept with in 3seconds. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
- Page 8 Page Specification for Transducer Revision No. Model No. : KPR-G3530 Drawing No. KP3.840.377R 12. Revision Rev. DATE PAGE DESCRIPTION SIGN primary 2007.07.19 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
