SPECIFICATION
Customer :
Applied To :
Product Name : Magnetic Transducer
Model Name : KPM-G1201A9-K9096
Drawing No. :
Compliance with ROHS( 本品符合 ROHS 指令 )
Signature of Approval
Signature of KEPO
Approved by
宁波凯普电子有限公司
Ningbo Kepo Electronics Co.,Ltd.
QUARTZ- 1
OEM9096R
Checked by
受
Issued by
2012. 05. 11
控
Date
Advertisement
Table of Contents
Related Manuals for KEPO KPM-G1201A9-K9096
Summary of Contents for KEPO KPM-G1201A9-K9096
- Page 1 SPECIFICATION Customer : QUARTZ- 1 受 控 Applied To : Product Name : Magnetic Transducer Model Name : KPM-G1201A9-K9096 Drawing No. : OEM9096R Compliance with ROHS( 本品符合 ROHS 指令 ) Signature of Approval Signature of KEPO Approved by Checked by...
-
Page 2: Table Of Contents
额定极限条件 4. Electrical Characteristics 电性能 5. Measuring Method 测试方法 6. Physical Characteristics 机械性能 7. Environmental Characteristics 环境性能 8. Dimensions 尺寸 9. Packaging Standard 包装标准 10. Cautions 警告 11. Cautions for Use 注意事项 12. Revision 履历表 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 3: Maximum Rating
3. 额定极限条件 Maximum Rating 项目 规 格 Item Specification 工作温度范围 -20 ～ +70 ℃ Operating Temperature Range 储存温度范围 -30 ～ +80 ℃ Storage Temperature Range 额定电压 1.5V Rated Voltage 工作电压 1 ～ 2V Operating Voltage Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 4: Electrical Characteristics
℃ , 湿度 45 ～ 85%R.H. 的范围内测试 . Part shall be measured under a condition (Temperature :+5 to +35 ℃ ,Humidity :45 to 85%R.H.)unless the standard condition (Temperature :+25 ± 3 ℃ ,Humidity :60 ± 10 %R.H.) is regulated measure. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 5: Physical Characteristics
分别在每个插针的轴向施加 9.8 牛顿的静荷 插针没有断开和 重 10 秒 . 可见的损伤 插针强度 No visible Terminal The force 10 seconds of 9.8N is applied to damage and Strength Pulling each terminal in axial direction. cutting off Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 6: Environmental Characteristics
压条件下恢复 1 小时，进行测量 20 Sec. +70 ℃ -20 ℃ 1 hour 1 hour 表 1 Table 1 项 目 试验后变化量 Specification after test Item 声压级 初始值 ± 10dB Sound Pressure Level Initial Value ± 10dB Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 7: Dimensions
KPM-G1201A9-K9096 Drawing No. OEM9096R 8. Dimensions 6.5± 0.2 蜂鸣器在 PCB 板中的布局图 (Layout of buzzer on PCB) minØ14 Ø12 -0.2 2-Ø0.8 KPM-G1201A9 喷码 2-Ø0.6± 0.05 waterproof seal Ø2.2 FIRST ANGLE PROJECTION UNIT Tolerance : ± 0.5 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 8: Packaging Standard
控制在 3 秒内 . In case of using solder iron for soldering, the top of soldering iron's temperature should be kept less than +350 ℃ .Moreover the soldering time should be also kept with in 3seconds. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... - Page 9 Page Specification for Magnetic Transducer Revision No. Model No. : KPM-G1201A9-K9096 Drawing No. OEM9096R 12. Revision Rev. DATE PAGE DESCRIPTION SIGN primary 2012.08.06 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
