- Page 1 SPECIFICATION Customer : Customer NO.: 受 控 Product Name : Piezo Transducer Model Name : KPT-G2223P8 Drawing No. : OEM2336R Compliance with ROHS( 本品符合 ROHS 指令 ) Signature of Approval Signature of KEPO Approved by Checked by Issued by Date 宁波凯普电子有限公司...
-
Page 2: Table Of Contents
电性能 5. Measuring Method 测试方法 6. Physical Characteristics 机械性能 7. Environmental Characteristics 环境性能 8. Dimensions 尺寸 9. Packaging Standard 包装标准 10. 出货检查标准 11. Cautions 警告 12. Cautions for Use 注意事项 13. 4M设计变更通告 14 Revision 履历表 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 3: Maximum Rating
壳体材质 / 颜色 : PA/ 黑 3. 额定极限条件 Maximum Rating Item Specification 项目 规 格 最高输入电压 25Vp-p Square Wave Maximum input Voltage 工作温度范围 -20 ～ +70 ℃ Operating Temperature Range 储存温度范围 -30 ～ +80 ℃ Storage Temperature Range Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 4: Electrical Characteristics
℃ , 湿度 45 ～ 85%R.H. 的范围内测试 . Part shall be measured under a condition (Temperature :+5 to +35 ℃ ,Humidity :45 to 85%R.H.)unless the standard condition (Temperature :+25 ± 3 ℃ ,Humidity :60 ± 10 %R.H.) is regulated measure. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 5: Physical Characteristics
分别在每个插针的轴向施加 9.8 牛顿的静荷 插针没有断开和 重 10 秒 . 可见的损伤 插针强度 No visible Terminal The force 10 seconds of 9.8N is applied to damage and Strength Pulling each terminal in axial direction. cutting off Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 6: Environmental Characteristics
After 5 above cycles, sounder shall be measured after being placed in natural condition for 4 hours. 表 1 Table 1 项 目 试验后变化量 Specification after test Item 声压级 初始值± 10dB Sound Pressure Level Initial Value ± 10dB Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 7: Dimensions
7/10 Page Specification for Transducer Revision No. Model No. : KPT-G2223P8 Drawing No. OEM2336R 8. Dimensions 白色阻焊 透明环氧 KEPO Date Code 印字(红金色) FIRST ANGLE PROJECTION UNIT Tolerance : ± 0.5 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 8: Packaging Standard 包装标准
Each minimum package unit of products shall be in a carton box and it shall be clearly marked with Part Number, quantity and outgoing inspection number. There shall be no mechanical damage on products during transportation and/or in storage. Picture1(50PCS) Picture2(1000PCS) Picture3(3000PCS) Picture4(3000PCS) QTY: 3000Pcs SIZE:580 x350 x460mm Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 9: Cautions
控制在 3 秒内 . In case of using solder iron for soldering, the top of soldering iron's temperature should be kept less than +350 ℃ .Moreover the soldering time should be also kept with in 3seconds. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 10: Revision
Page 10/10 Specification for Transducer Revision No. Model No. : KPT-G2223P8 Drawing No. OEM2336R 12. Revision Rev. DATE PAGE DESCRIPTION SIGN primary 2009.04.07 Change Packing 2010.04.13 Change Packing 2010.05.21 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
