- Page 1 PHONE SUPPORT WARRANTY Elia SMART CONNECTED VIDEOPHONE CONNECTED VIDEOPHONE CONNECTED VIDEOPHONE Ref. 112292 Ref. 112292 100m Connected 2-wire Range Weather- connection resistant Night Screen Touch-sensitive Number vision size keys of melodies www.avidsen.com...
- Page 2 CONTENTS...
-
Page 3: Table Of Contents
A - SAFETY INSTRUCTIONS 05 3 - OPENING AN ELECTRIC LOCK AND AN AUTOMATIC CONTROL SYSTEM (OPTIONAL) 1 - INTRODUCTION 4 - MONITOR SETTINGS 2 - MAINTENANCE AND CLEANING E. CONNECTED OPERATION 3 - RECYCLING B - PRODUCT DESCRIPTION 06 1 - INSTALLING THE MOBILE APP AND CREATING AN ACCOUNT 1 - KIT CONTENTS... -
Page 5: A - Safety Instructions
A - SAFETY INSTRUCTIONS • Unplug the device if it will not be used for an 1 - INTRODUCTION extended period of time. • Do plug device into national This video intercom system pairs two modules: a telecommunications installations. receiver-monitor and an easy-to-install and use •... -
Page 6: B - Product Description
B - PRODUCT DESCRIPTION 1 - CONTENTS OF THE KIT Monitor Screws (4 for the monitor, 3 for the intercom panel) Intercom panel Allen key Monitor wall bracket Mains adaptor Dowels (4 for the monitor, 3 for the intercom panel) Intercom panel snap-on terminal blocks 2 - MONITOR 7"... -
Page 7: Intercom Panel
B - PRODUCT DESCRIPTION 3 - INTERCOM PANEL Protective hood Microphone Lens Infrared lighting Loudspeaker Call button Name holder Removable connection terminal blocks 4 - WALL BRACKET The monitor is designed to be fixed to the wall. A wall bracket and the necessary fasteners are included. 5 - MAINS ADAPTER A 230 VAC 50 Hz/17 VDC 1.5 A mains adapter for powering the monitor is included in the kit. -
Page 8: C - Installation
C - INSTALLATION The recommended installation height for the intercom panel is about 160 cm from the ground and 150 cm from the floor for the indoor unit. 50cm 70° 160cm 150cm NOTE: For obvious safety reasons, the connections must only be made after shutting off the power supply. 1 - INTERCOM PANEL INSTALLATION Attach the intercom panel hood to your support using the screws and wall plugs suited to the support (the screws and plugs supplied are suitable for solid walls). - Page 9 C - INSTALLATION Then screw the intercom panel to the hood with the screw provided. Put on the name label.
-
Page 10: Installing The Monitor
C - INSTALLATION 2 - INSTALLING THE MONITOR Attach the wall mount to the wall using the screws and wall plugs suited to the support (the screws and plugs supplied are suitable for solid walls). After connecting the monitor (refer to the “connections” paragraph), fit the monitor onto its support. 3 - CONNECTIONS •... - Page 11 C - INSTALLATION Cable length Cross-section to use 0 to 50 m 0.75 mm 50 m to 100 m 1.5 mm Between the intercom panel and an electric strike plate (not included) Use a 12V/1.1A maximum electric strike plate with mechanical memory. For the connection between the intercom panel and the door release, use a cable of this kind: Cable length Cross-section to use...
-
Page 12: D - Using The Product
D - USING THE PRODUCT AUTOMATIC CONTROL SYSTEM (OPTIONAL) 1 - IDENTIFY AND SPEAK TO THE VISITOR The visitor presses the intercom panel’s call button: If the device is equipped with an electric lock and/ or an automatic control system (see “Connection” paragraph), press the button (for the lock) or the button (for the automatic control system) to let a... -
Page 13: Monitor Settings
D - USING THE PRODUCT 4 - MONITOR SETTINGS With the screen on, press the button to display the following screen: Browse the sub-menus by pressing the buttons CON . COL . CALL . INCOME . RING . Once in the RING sub-menu, press the button to exit. -
Page 14: Connected Operation
E. CONNECTED OPERATION Your videophone has Internet connectivity and uses After accepting the privacy policy, you can create an the free AvidsenHome app for Android and iOS, which account. allows you to receive incoming calls from the intercom panel, view visitors who show up, answer them and unlock the electric strike plate or gate if you want to grant them access. -
Page 15: Connecting The Videophone
E. CONNECTED OPERATION ended, press renvoyer (resend) and check the email address entered. Select the product you wish to pair, select the Elia Smart videophone. To complete your registration, set a password between 6 and 20 characters long with letters and numbers only, then press Terminé... - Page 16 E. CONNECTED OPERATION Select your 2.4 GHz WiFi network (note: your Please wait while the connection procedure takes smartphone must be connected to the same WiFi place. This step can take several minutes. network to which the videophone will be connected), enter your network password and press SUIVANT (NEXT).
-
Page 17: Using The Avidsenhome App With The Elia Smart Videophone
F. USING THE AVIDSENHOME APP WITH THE ELIA SMART VIDEOPHONE The AvidsenHome app allows you to remotely connected to the account to which your videophone is control your videophone and the one or more entries paired, and the monitor also rings at the same time. connected to it. -
Page 18: G - Faq
G. FAQ Symptoms Possible causes Solutions Please contact the technical support You have an out-of-date or incompatible of your device’s manufacturer in version of Android on your device order to obtain a recent Android version I can’t install the AvidsenHome app on Google Play checks all the key my Android device components needed to run the application... - Page 19 G. FAQ Re-pair your videophone. This will automatically delete it from your old account. If you want to share the videophone The videophone is already paired with with another smartphone, create a Pairing issues another user account new AvidsenHome account on the smartphone and use the “partage”...
-
Page 20: H - Technical And Legal Information
H. TECHNICAL AND LEGAL INFORMATION 1 - TECHNICAL CHARACTERISTICS MONITOR Screen Ultra-flat 7" colour LCD Video standard PAL/NTSC Resolution 800 x 480 Power supply Via included 230 VAC 50 Hz/17 VDC 1.5 A mains adapter Protection Short circuit and reverse polarity protection Connections Full 2-wire connection Connectivity... -
Page 21: Warranty
Avidsen undertakes to keep a stock of spare parts for this product throughout the contractual warranty period. 5. EU DECLARATION OF CONFORMITY... - Page 22 Elia SMART Avidsen 19 avenue Marcel Dassault - ZAC des Deux Lions 37200 Tours - France Photographs and illustrations non-binding/©AdobeStock.com/© Avidsen France 2023...
