- Page 1 Pronomic C-Series, passive Art. No. 00090914, 00090915, 00090917, 00090918 Operating instructions Version 11/2022...
-
Page 2: Table Of Contents
Pronomic C-Series, passive These operating instructions are protected by copyright. Reproduction of these operating instructions, even in part, is only permitted with the consent of Musikhaus Kirstein GmbH. The same applies to the reproduction or copying of images, even in modified form. - Page 3 Pronomic C-Series, passive Thank you for choosing this product. To ensure that you are completely satisfied with this product, please read carefully and understand this instruction manual before using our product. Keep these operating instructions in a safe place. The operating instructions must be passed on to all subsequent users.
-
Page 4: Intended Use
Pronomic C-Series, passive Intended use • Only use the product in accordance with the instructions given here. In the event of damage caused by failure to observe these instructions for use, the warranty will be invalidated! Musikhaus Kirstein GmbH accepts no liability for any resulting damage. -
Page 5: Technical Specifications
Pronomic C-Series, passive Technical specifications Model C-208 MP C-210 MP C-212 MP C-215 MP Passive Speaker Passive Speaker Passive Speaker Type Passive Speaker Box Woofer 8" 10" 12" 15" Tweeter / Horn 1" Coil 1" Coil 1,75" Coil 1,75" Coil... -
Page 6: Connections Of The Loudspeaker Module
Pronomic C-Series, passive Connections of the loudspeaker module The passive loudspeakers of the Pronomic C-Series have 2-pole Speakon compatible parallel loudspeaker connectors. For optimum performance, it is important to use cables designed specifically for speakers. Do not use shielded "guitar" signal cables to connect these speakers. -
Page 7: Loop Through Loudspeakers
Connections of the loudspeaker module The two sockets on the back of the passive Pronomic C-Series are wired in parallel. This means that everything you connect to the input socket is simultaneously passed on to another speaker via the output socket. -
Page 8: Weee Declaration
Pronomic C-Series, passive WEEE Declaration (Waste of Electrical and Electronic Equipment) Your product has been designed and manufactured using high quality materials and components that are recyclable and reusable. The symbol means that your product must be disposed of separately from household waste at the end of its life.
