Connecting the Micro4Pro

Simple TV Connection

1� Connect a HDMI cable from the Micro4Pro to the HDMI input on your TV�
2� Connect the included power supply to your wall outlet and to the Micro4Pro�
3� The Micro4Pro will automatically turn on
4� Make sure you turn on your TV and switch to the correct HDMI source�
Refer to your TVs manual for instructions�
Using the included IR
Extender
If you have the Micro4Pro hidden
behind your TV or in a cupboard,
out of sight, you can use the
included IR extender to allow it to
receive remote signals�
1� Connect the 3�5mm connector
to the IR input
2� Stick the IR receiver where it
can have a direct line sight with
the Micro4Pro remote

Connecting the Micro4Pro to your network

You can connect the Micro4Pro via either wirelessly over wi-fi or wired using the ethernet port located on the back�

Wireless

1� Boot up the Micro4Pro
2� Using the remote control, click on the settings icon on the top right (
3� Scroll down to network and find your existing wireless network from the Available Networks section
4� Put in your Wi-Fi password and click NEXT to confirm
5� If successful you will see a Connected Successfully message
6� To confirm, you can go back to the home screen, click on the network icon (
that gives you the FTP connection details� The IP should match your existing network setup�
Wintal Micro4Pro User Manual
AV IR SPDIF HD
DC
LAN
)
) and you should get a pop up
7 of 15
